PHARMACOGRAPHIA.

RADIX HELLEBORI NIGRI.

Botanical Origin—Helleborus niger L., a low perennial herb, native of sub-alpine woods in Southern and Eastern Europe. It is found in Provence, Northern Italy, Salzburg, Bavaria, Austria, Bohemia, and Silesia, as well as, according to Boissier,[4] in Continental Greece.

Under the name of Christmas Rose, it is often grown in English gardens on account of its handsome white flowers, which are put forth in midwinter.

History—The story of the daughters of Prœtus, king of Argos, being cured of madness by the soothsayer and physician Melampus, who administered to them hellebore, has imparted great celebrity to the plant under notice.[5]

But admitting that the medicine of Melampus was really the root of a species of Helleborus, its identity with that of the present plant is extremely improbable. Several other species grow in Greece and Asia Minor, and Schroff[6] has endeavoured to show that of these, H. orientalis Lam. possesses medicinal powers agreeing better with the ancient accounts than those of H. niger L. He has also pointed out that the ancients employed not the entire root but only the bark separated from the woody column; and that in H. niger and H. viridis the peeling of the rhizome is impossible, but that in H. orientalis it may be easily effected.

According to the same authority the hellebores differ extremely in their medicinal activity. The most potent is H. orientalis Lam.; then follow H. viridis L. and H. fœtidus L. (natives of Britain), and H. purpurascens Waldst. et Kit., a Hungarian species, while H. niger is the weakest of all.[7]

Description—Black Hellebore produces a knotty, fleshy, brittle rhizome which creeps and branches slowly, forming in the course of years an intangled, interlacing mass, throwing out an abundance of stout, straight roots. Both rhizome and roots are of a blackish brown, but the younger roots are of lighter tint and are covered with a short woolly tomentum.

In commerce the rhizome is found with the roots more or less broken off and detached. It is in very knotty irregular pieces, 1 to 2 or 3 inches long and about ²/₁₀ to ³/₁₀ of an inch in diameter, internally whitish and of a horny texture. If cut transversely (especially after maceration), it shows a circle of white woody wedges, 8 to 12 in number, surrounded by a thick bark. The roots are unbranched, scarcely ⅒ of an inch in diameter. The younger, when broken across, exhibit a thick bark encircling a simple woody cord; in the older this cord tends to divide into converging wedges which present a stellate appearance, though not so distinctly as in Actæa. The drug when cut or broken has a slight odour like that of senega. Its taste is bitterish and slightly acrid.

Microscopic Structure—The cortical part both of the rhizome and the rootlets exhibits no distinct medullary rays. In the rootlets the woody centre is comparatively small and enclosed by a narrow zone somewhat as in sarsaparilla. A distinct pith occurs in the rhizome but not always in the rootlets, their woody column forming one solid bundle or being divided into several. The tissue contains small starch granules and drops of fatty oil.

Chemical Composition—The earlier investigations of Black Hellebore by Gmelin, and Feneuille and Capron, and of Riegel indicated only the presence of the more usual constituents of plants.

Bastick, on the other hand, in 1852 obtained from the root a peculiar, non-volatile, crystalline, chemically-indifferent substance which he named Helleborin. It is stated to have a bitter taste and to produce in addition a tingling sensation on the tongue; to be slightly soluble in water, more so in ether, and to dissolve freely in alcohol.

Marmé and A. Husemann extracted helleborin (1864) by treating with hot water the green fatty matter which is dissolved out of the root by boiling alcohol. After recrystallization from alcohol, it is obtainable in shining, colourless needles, having the composition C₃₆H₄₂O₆. It is stated to be highly narcotic. Helleborin appears to be more abundant in H. viridis (especially in the older roots) than in H. niger, and yet to be obtainable only to the extent of 0·4 per mille. When it is boiled with dilute sulphuric acid, or still better with solution of zinc chloride, it is converted into sugar and Helleboresin, C₃₀H₃₈O₄.

Marmé and Husemann succeeded in isolating other crystallized principles from the leaves and roots of H. niger and H. viridis, by precipitation with phospho-molybdic acid. They obtained firstly a slightly acid glucoside which they named Helleboreïn. It occurs only in very small proportion, but is rather more abundant in H. niger than in H. viridis. When boiled with a dilute acid, helleboreïn, C₂₆H₄₄O₁₅, is resolved into Helleboretin, C₁₄H₂₀O₃, of a fine violet colour, and sugar, C₁₂H₂₄O₁₂. It is remarkable that helleboretin has no physiological action, though helleboreïn is stated to be poisonous.

An organic acid accompanying helleborin was regarded by Bastick as probably aconitic (equisetic) acid. There is no tannin in hellebore.

Uses—Black Hellebore is reputed to be a drastic purgative. In British medicine its employment is nearly obsolete, but the drug is still imported from Germany and sold for the use of domestic animals.

Adulteration—Black Hellebore root as found in the market is not always to be relied on, and without good engravings it is not easy to point out characters by which its genuineness can be made certain. In fact to ensure its recognition, some pharmacopœias required that it should be supplied with leaves attached.

The roots with which it is chiefly liable to be confounded are the following:—

1. Helleborus viridis L.—Although a careful comparison of authenticated specimens reveals certain small differences between the roots and rhizomes of this species and of H. niger, there are no striking characters by which they can be discriminated. The root of H. viridis is far more bitter and acrid than that of H. niger, and it exhibits more numerous drops of fatty oil. In German trade the two drugs are supplied separately, both being in use; but as H. viridis is apparently the rarer plant and its root is valued at 3 to 5 times the price of that of H. niger, it is not likely to be used for sophisticating the latter.

2. Actœa spicata L.—In this plant the rhizome is much thicker; the rootlets broken transversely display a cross or star, as figured in Flückiger’s “Grundlagen” see p. vii.), fig. 64, p. 76. The drug has but little odour; as it contains tannin its infusion is blackened by a persalt of iron, which is not the case with an infusion of Black Hellebore.

RHIZOMA COPTIDIS.

Botanical Origin—Coptis Teeta Wallich, a small herbaceous plant, still but imperfectly known, indigenous to the Mishmi mountains, eastward of Assam. It was first described in 1836 by Wallich.[8]

History—This drug under the name of Mahmira is used in Sind for inflammation of the eyes, a circumstance which enabled Pereira[9] to identify it with a substance bearing a nearly similar designation, mentioned by the early writers on medicine, and previously regarded as the root of Chelidonium majus L.

Thus we find that Paulus Ægineta in the 7th century was acquainted with a knotty root named Μαηιρά.[10] Rhazes, who according to Choulant died in a.d. 923 or 932, mentions Mamiran, and it is also noticed by Avicenna a little later as a drug useful in diseases of the eye. Μαμιρὰϛ likewise occurs in exactly the same way in the writings of Leo, “Philosophus et Medicus.”[11] Ibn Baytar called the drug Mamiran and Uruk, and described it as a small yellow root like turmeric, coming from China. Other writers of the middle ages allude to it under the name of Memeren.

Hajji Mahomed, in the account of Cathay which he gave to Ramusio (circa a.d. 1550) says that the Mambroni chini, by which we understand the root in question, is found in the mountains of Succuir (Suh-cheu) where rhubarb grows, and that it is a wonderful remedy for diseases of the eye.[12] In an official report published at Lahore in 1862,[13] Mamiran-i-chini is said to be brought from China to Yarkand.

The rhizome of Coptis is used by the Chinese under the names Hwang-lien and Chuen-lien.[14] It is enumerated by Cleyer[15] (1682) as “radix pretiosa amara,” and was described in 1778 by Bergius[16] who received it from Canton.

More recently it was the subject of an interesting notice by Guibourt[17] who thought it to be derived from Ophioxylon serpentinum L., an apocyneous plant widely removed from Coptis. Its root was recommended in India by MacIsaac[18] in 1827 and has been subsequently employed with success by many practitioners.

There is a rude figure of the plant in the Chinese herbal Pun-tsao.

Description—Tita, as the drug is called in the Mishmi country, whence it is sent by way of Sudiya on the Bramaputra to Bengal, is a rhizome about the thickness of a quill occurring in pieces an inch or two in length. It often branches at the crown into two or three heads, and bears the remains of leafstalks and thin wiry rootlets, the stumps of which latter give it a rough and spiny appearance. It is nearly cylindrical, often contorted, and of a yellowish-brown colour. The fracture is short, exhibiting a loose structure, with large bright yellow radiating woody bundles. The rhizome is intensely bitter,[19] but not aromatic even when fresh.

It is found in the Indian bazaars in neat little open-work bags formed of narrow strips of rattan, each containing about half an ounce. We have once seen it in bulk in the London market.[20]

Microscopic Structure—Cut transversely the rhizome exhibits an inner cortical tissue, through which sclerenchymatous groups of cells are scattered. The latter are most obvious on account of their bright yellow colour. In the woody central column a somewhat concentric arrangement is found, corresponding to two or three periods of annual growth. The pith, not the medullary rays, begins to be obliterated at an early period. The structure of the drug is, on the whole, very irregular, on account of the branches and numerous rootlets arising from it.

The medullary rays contain small starch granules, while the bark, as well as the pith, are richer in albuminous or mucilaginous matters.

Chemical Composition—The colouring matter in which the rhizome of Coptis abounds, is quickly dissolved by water. If the yellow solution obtained by macerating it in water is duly concentrated, nitric acid will produce an abundant heavy precipitate of minute yellow crystals, which if redissolved in a little boiling water will separate again in stellate groups. Solution of iodine also precipitates a cold infusion of the root.

These reactions as well as the bitterness of the drug are due to a large proportion of Berberine, as proved by J. D. Perrins.[21] The rhizome yielded not less than 8½ per cent., which is more than has been met with in any other of the numerous plants containing that alkaloid.

As pure berberine is scarcely dissolved by water, it must be combined in Coptis with an acid forming a soluble salt. Further researches are requisite to determine the nature of this acid. In some plants berberine is accompanied by a second basic principle: whether in the present instance such is the case, has not been ascertained.

Uses—The drug has been introduced into the Pharmacopœia of India as a pure, bitter tonic.

Substitutes—Thalictrum foliolosum DC., a tall plant common at Mussooree and throughout the temperate Himalaya at 5000-8000 feet, as well as on the Khasia Hills, affords a yellow root which is exported from Kumaon under the name Momiri. From the description in the Pharmacopœia of India, it would appear to much resemble the Mishmi Tita, and it is not impossible that some of the observations made under the head History (p. 3) may apply to Thalictrum as well as to Coptis.

In the United States the rhizome of Coptis trifolia Salisb., a small herb indigenous to the United States and Arctic America, and also found in European and Asiatic Russia, is employed for the same purposes as the Indian drug. It contains berberine and another crystalline principle.[22]

SEMEN STAPHISAGRIÆ.

Botanical Origin—Delphinium Staphisagria L., a stout, erect, biennial herb growing 3 to 4 feet high, with palmate, 5-to 9-lobed leaves, which as well as the rest of the plant are softly pubescent.

It is a native of Italy, Greece, the Greek Islands and Asia Minor, growing in waste and shady places; it is now also found throughout the greater part of the Mediterranean regions and in the Canary Islands, but whether in all instances truly indigenous is questionable. It is cultivated to some extent in Puglia, very little now near Montpellier.

History—Stavesacre was well known to the ancients. It is the ἀγροτἔρη σταϕὶς of Nicander,[23] the σταϕὶς ἀγρία of Dioscorides,[24] and Alexander Trallianus,[25] the Staphisagria or Herba pedicularia of Scribonius Largus,[26] the Astaphis agria or Staphis of Pliny.[27] The last named author mentions the use of the powdered seeds for destroying vermin on the head and other parts of the body.

The drug continued in use during the middle ages. Pietro Crescenzio,[28] who lived in the 13th century, mentions the collection of the seeds in Italy; and Simon Januensis,[29] physician to Pope Nicolas IV. (a.d. 1288-1292), describes them—“propter excellentem operationem in caputpurgio.”

Description—The fruit consists of three downy follicles, in each of which about 12 seeds are closely packed in two rows. The seeds (which alone are found in commerce) are about 3 lines in length and rather less in width; they have the form of a very irregular 4-sided pyramid, of which one side, much broader than the others, is distinctly vaulted. They are sharp-angled, a little flattened, and very rough, the testa being both wrinkled and deeply pitted. The latter is blackish-brown, dull and earthy-looking, rather brittle, yet not hard. It encloses a soft, whitish, oily albumen with a minute embryo at its sharper end.

The seeds have a bitter taste and occasion a tingling sensation when chewed. Ten of them weigh about 6 grains.

Microscopic Structure—The epidermis of the seed consists of one layer of large cells, either nearly cubical or longitudinally extended: hence the wrinkles of the surface. The brown walls of these cells are moderately thickened by secondary deposits, which may be made very obvious by macerating thin sections in a solution of chromic acid, 1 p. in 100 p. of water. By this treatment numerous crystals after a short time make their appearance,—without doubt the chromate of one of the alkaloids of staphisagria.

The outer layer of the testa is made up of thin-walled narrow cells, which become larger near the edges of the seed and in the superficial wrinkles. They contain a small number of minute starch granules and are not altered on addition of a salt of iron. The interior layer exhibits a single row of small, densely packed cells. The albumen is composed of the usual tissue loaded with granules of albuminoid matter and drops of fatty oil.

Chemical Composition—Brandes (1819) and Lassaigne and Feneulle (1819) have shown this drug to contain a basic principle. Erdmann in 1864 assigned it the formula C₂₄H₃₅NO₂; he obtained it to the extent of 1 per mille in crystals, soluble in ether, alcohol, chloroform, or benzol. The alkaloid has an extremely burning and acrid taste, and is highly poisonous.

Couerbe[30] in 1833 pointed out the presence in stavesacre of a second alkaloid separable from delphinine by ether in which it is insoluble.

The treatment of the shell of the seed with chromic acid, detailed above, shows that this part of the drug is the principal seat of the alkaloids; and the albumen indeed furnishes no crystals of any chromate. In confirmation of this view we exhausted about 400 grammes of the entire seeds with warm spirit of wine acidulated with a little acetic acid. The liquid was allowed to evaporate and the residue mixed with warm water. The solution thus obtained, separated from the resin, yielded on addition of chromic acid an abundant precipitate of chromate. The same solution likewise furnished copious precipitates when bichloride of platinum,[31] iodohydrargyrate of potassium, or bichromate of potassium were added. By repeating the above treatment on a larger scale we obtained crystals of delphinine of considerable size, and also a second alkaloid not soluble in ether.

In the laboratory of Dragendorff, Marquis in 1877 succeeded in isolating the following alkaloids:—1. Delphinine, C₂₂H₃₅NO₆, yielding crystals one inch in length, belonging to the rhombic System. They are soluble in 11 parts of ether, 15 parts of chloroform, and 20 of absolute alcohol. 2. Staphisagrine, C₂₂H₃₃NO₅, is amorphous, soluble in less than 1 part of ether, also in 200 parts of water at 150°. This alkaloid, although it would appear to be the anhydride of the former, is in every respect widely different from delphinine. 3. Delphinoidine (formula not quite settled), amorphous, soluble in three parts of ether, more abundantly occurring in the seed than the two former alkaloids. In its physiological action delphinoidine agrees with delphinine, not with staphisagrine. 4. Delphisine (formula doubtful) forms crystalline tufts, occurs in but small amount, is sparingly soluble in alcohol, chloroform, or ether.—The total amount of alkaloids afforded by stavesacre is about 1 per cent.

By exhausting the seeds with boiling ether, we get 27 per cent. of a greenish, fatty oil, which continued fluid even at -5° C. It concreted by means of hyponitric acid, and is therefore to be reckoned among the non-drying oils; it contained a large part of the alkaloids.

The drug air-dry contains 8 per cent. of hygroscopic water. Dried at 100° C. and incinerated it left 8·7 per cent. of ash.

Nothing exact is known of the Delphinic acid of Hofschläger (about 1820) said to be crystalline and volatile.

Commerce—The seeds are imported from Trieste and from the south of France, especially from Nismes, near which city as well as in Italy (Puglia) the plant is cultivated.

Uses—Stavesacre seeds are still employed as in old times for the destruction of pediculi in the human subject, for which purpose they are reduced to powder which is dusted among the hair. Dr. Balmanno Squire[32] having ascertained that prurigo senilis is dependent on the presence of pediculus, has recommended an ointment of which the essential ingredients is the fatty oil of stavesacre seeds extracted by ether. It is plain that such a preparation would contain delphinine. Delphinine itself has been used externally in neuralgic affections. Stavesacre seeds are largely consumed for destroying the pediculi that infest cattle.

RADIX ACONITI.

Botanical Origin—Aconitum Napellus L.—This widely diffused and most variable species grows chiefly in the mountainous districts of the temperate parts of the northern hemisphere.

It is of frequent occurrence throughout the chain of the Alps up to more than 6500 feet, the Pyrenees, the mountains of Germany and Austria, and is also found in Denmark and Sweden. It has become naturalized in a few spots in the west of England and in South Wales. Eastward it grows throughout the whole of Siberia, extending to the mountain ranges of the Pacific coast of North America. It occurs in company with other species on the Himalaya at 10,000 to 16,000 feet above the sea-level.

The plant is cultivated for medicinal use, and also for ornament. The Abbé Armand David[34] saw in northern Sz-chuen (Setchuan) fields planted with Aconite (A. Napellus?).

History—The Ἀκόνιτον of the Greeks and the Aconitum of the Romans are held to refer to the genus under notice, if not precisely to A. Napellus. The ancients were well aware of the poisonous properties of the aconites, though the plants were not more exactly distinguished until the close of the middle ages. The Greek name is supposed to refer to the same source as that of Conium. (See article on Fructus Conii.)

Aconite has been widely employed as an arrow-poison. It was used by the ancient Chinese,[35] and is still in requisition among the less civilized of the hill tribes of India. Something of the same kind was in vogue among the aborigines of ancient Gaul.[36] Aconite was pointed out in the thirteenth century, in “The Physicians of Myddvai,”[37] as one of the plants which every physician is to grow.

Störck of Vienna introduced aconite into regular practice about the year 1762[38]; the root and the herb occur in the German pharmaceutical tariff of the seventeenth century.

Description—The herbaceous annual stem of aconite starts from an elongated conical tuberous root 2 to 4 inches long and sometimes as much as an inch in thickness. This root tapers off in a long tail, while numerous branching rootlets spring from its sides. If dug up in the summer it will be found that a second and younger root (occasionally a third) is attached to it near its summit by a very short branch and is growing out of it on one side. This second root has a bud at the top which is destined to produce the stem of the next season. It attains its maximum development at the latter part of the year, the parent root meanwhile becoming shrivelled and decayed. This form of growth is therefore analogous to that of an orchis.

The dried root is more or less conical or tapering, enlarged and knotty at the summit which is crowned with the base of the stem. It is from 2 to 3 or 4 inches long and at the top from ½ to 1 inch thick. The tuber-like portion of the root is more slender, much shrivelled longitudinally, and beset with the prominent bases of rootlets. The drug is of a dark brown; when dry it breaks with a short fracture exhibiting a white and farinaceous, or brownish, or grey inner substance sometimes hollow in the centre. A transverse section of a sound root shows a pure white central portion (pith) which is many-sided and has at each of its projecting angles a thin fibro-vascular bundle.

In the fresh state the root of aconite has a sharp odour of radish which disappears on drying. Its taste which is at first sweetish soon becomes alarmingly acrid, accompanied with sensations of tingling and numbness.

Microscopic Structure—The tuberous root as seen in a transverse section, consists of a central part enclosed by a delicate cambial zone. The outer part of this central portion exhibits a thin brownish layer made up of a single row of cells (Kernscheide of the Germans). This is more distinctly obvious in the rootlets, which also show numerous, scattered, thick-walled cells of a yellow colour.

The fibro-vascular bundles of aconite root are devoid of true ligneous cells; its tissue is for the largest part built up of uniform parenchymatous cells loaded with starch granules.

Chemical Composition—Aconite contains chemical principles which are of great interest on account of their virulent effects on the animal economy.

The first to be mentioned is Aconitine, a highly active crystallizable alkaloid, furnishing readily crystallizable salts. It is accompanied by another active alkaloid, Pseudaconitine, which is crystallizable, but yields mostly amorphous salts. According to the admirable researches of Wright and Luff,[39] aconitine may be decomposed according to the following equation:—

C₃₃H₄₃NO₁₂	· OH₂ =	C₇H₆O₂	· C₂₆H₃₉NO₁₁,
Aconitine.		Benzoic acid.	Aconine.

and pseudaconitine breaks up in accordance with the equation:

C₃₆H₄₉NO₁₁	· OH₂ =	C₉H₁₀O₄	· C₂₇H₄₁NO₈
Pseudaconitine.		Dimethyl- protocatechnic acid.	Pseudaconine.

The decomposition of aconitine, as well as of pseudaconitine, may be performed by means of mineral acids, alkaline solutions, or also by heating the bases with water in sealed tubes. The two alkaloids, Aconine and Pseudaconine, appear to be present already in the roots of Aconitum; they, moreover, contain two other alkaloids of less physiological potency. One of them, Picraconitine, C₃₁H₄₅NO₁₀, is merely bitter, producing no lip-tingling; it gives well crystallized salts, although it is itself amorphous. Commercial aconitine is a mixture of the above alkaloids. The total yield of basic substances afforded by aconite root is not more than about 0·07 per cent.

The other constituents of aconite root are but imperfectly known. In the preparation of the alkaloids, a dark green mixture of resin and fat is obtained; it is much more abundant in European than in Nepal aconite (Groves). The root contains Mannite, as proved by T. and H. Smith (1850), together with cane-sugar, and another sugar which reduces cupric oxide even in the cold. Tannin is absent, or is limited to the corky coat. The absence of a volatile alkaloid in the root was proved by Groves in 1866.

Uses—Prescribed in the form of tincture as an anodyne liniment; occasionally given internally in rheumatism.

Adulteration and Substitution—Aconite root, though offered in abundance in the market, is by no means always obtained of good quality. Collected in the mountainous parts of Europe by peasants occupied in the pasturing of sheep and cattle, it is often dug up without due regard to the proper season or even to the proper species,—a carelessness not surprising when regard is had to the miserable price which the drug realizes in the market.[40]

One of the species not unfrequent in the Alps, of which the roots are doubtless sometimes collected, is A. Störckeanum Reichenb. In this plant the tuberous roots are developed to the number of three or four, and have an anatomical structure slightly different from that of A. Napellus.[41] A. variegatum L., A. Cammarum Jacq., and A. paniculatum Lam. are blue-flowered species having tuberous roots resembling those of A. Napellus, but according to Schroff somewhat less active.

The yellow-flowered A. Anthora L. and A. Lycoctonum L. produce roots which cannot be confounded with those of A. Napellus L.

The root of A. japonicum Thunb. has been noticed in Europe by Christison as early as 1859[42]; it is now imported occasionally from the East. It forms grey or almost blackish tubers from ⁶/₁₀ of an inch to upwards of 1 inch in length, and from ²/₁₀ to ⁴/₁₀ of an inch in diameter, oblong or ovoid, either tapering or rounded at their extremities. They are of plump, scarcely shrivelled appearance.[43]

Japanese aconite afforded to Wright and Luff a crystallized active alkaloid different from both aconitine and pseudaconitine.

Holmes[44] states that the aromatic roots of Imperatoria Ostruthium L. have been found mixed with aconite.

FOLIA ACONITI.

Botanical Origin—Aconitum Napellus L., see preceding article.

History—Aconite herb was introduced into medicine in 1762 by Störck of Vienna; and was admitted into the London Pharmacopœia in 1788.

Description—The plant produces a stiff, upright, herbaceous, simple stem, 3 to 4 feet high, clothed as to its upper half with spreading, dark green leaves, which are paler on their under side. The leaves are from 3 to 5 or more inches in length, nearly half consisting of the channelled petiole. The blade, which has a roundish outline, is divided down to the petiole into three principal segments, of which the lateral are subdivided into two or even three, the lowest being smaller and less regular than the others. The segments, which are trifid, are finally cut into 2 to 5 strap-shaped pointed lobes. The leaves are usually glabrous, and are deeply impressed on their upper side by veins which run with but few branchings to the tip of every lobe. The uppermost leaves are more simple than the lower, and gradually pass into the bracts of the beautiful raceme of dull-blue helmet-shaped flowers which crowns the stem.

The leaves have when bruised a herby smell; their taste is at first mawkish but afterwards persistently burning.

Chemical Composition—The leaves contain aconitine in small proportion and also aconitic acid,—the latter in combination with lime.

Aconitic Acid, C₁₆H₆O₆, discovered by Peschier in 1820 in somewhat considerable quantity in the leaves of aconite, occurs also in those of larkspur, and is identical with the Equisetic Acid of Braconnot and the Citridic Acid of Baup.[45] It has been stated to be present likewise in Adonis vernalis L. (Linderos, 1876,—10 per cent. of dried leaves!) and in the sugar cane (Behr, 1877).

Schoonbroodt[46] (1867) on treating the extract with a mixture of alcohol and ether, obtained acicular crystals, which he thought were the so-called Aconella of Smith. He further found that the distillate of the plant was devoid of odour, but was acid, and had a burning taste. By saturation with an alkali he obtained from it a crystalline substance, soluble in water, and having a very acrid taste. Experiments made about the same time by Groves,[47] a careful observer, led to opposite results. He distilled on different occasions both fresh herb and fresh roots, and obtained a neutral distillate, smelling and tasting strongly of the plant, but entirely devoid of acridity. Hence he concluded that A. Napellus contains no volatile acrid principle.

In an extract of aconite that has been long kept, the microscope reveals crystals of aconitate of calcium, as well as of sal-ammoniac.

The leaves contain a small proportion of sugar, and a tannin striking green with iron. When dried they yield on incineration 16·6 per cent. of ash.

Uses—In Britain the leaves and small shoots are only used in the fresh state, the flowering herb being purchased by the druggist in order to prepare an inspissated juice,—Extractum Aconiti. This preparation, which is considered rather uncertain in its action, is occasionally prescribed for the relief of rheumatism, inflammatory and febrile affections, neuralgia, and heart diseases.

RADIX ACONITI INDICA.

Botanical Origin—The poisonous root known in India as Bish, Bis, or Bikh[48] is chiefly derived from Aconitum ferox Wallich, a plant growing 3 to 6 feet high and bearing large, dull-blue flowers, native of the temperate and sub-alpine regions of the Himalaya at an elevation of 10,000 to 14,000 feet in Garhwal, Kumaon, Nepal and Sikkim.[49] In the greater part of these districts, other closely allied and equally poisonous species occur, viz. A. uncinatum L., A. luridum, H. f. et Th., A. palmatum Don, and also abundantly A. Napellus L., which last, as already mentioned, grows throughout Europe as well as in Northern Asia and America. The roots of these plants are collected indiscriminately according to Hooker and Thomson[50] under the name of Bish or Bikh.

History—The Sanskrit name of this potent drug, Visha, signifies simply poison, and Ativisha, a name which it also bears, is equivalent to “summum venenum.” Bish is mentioned by the Persian physician Alhervi[51] in the 10th century as well as by Avicenna[52] and many other Arabian writers on medicine,—one of whom, Isa Ben Ali, calls it the most rapid of deadly poisons, and describes the symptoms it produces with tolerable correctness.[53]

Upon the extinction of the Arabian school of medicine this virulent drug seems to have fallen into oblivion. It is just named by Acosta (1578) as one of the ingredients of a pill which the Brahmin physicians give in fever and dysentery.[54] There is also a very strange reference to it as “Bisch” in the Persian Pharmacopœia of Father Ange, where it is stated[55] that the root, though most poisonous when fresh, is perfectly innocuous when dried, and that it is imported into Persia from India, and mixed with food and condiments as a restorative! Ange was aware that it was the root of an aconite.

The poisonous properties of Bish were particularly noticed by Hamilton (late Buchanan)[56] who passed several months in Nepal in 1802-3: but nothing was known of the plant until it was gathered by Wallich and a description of it as A. ferox communicated by Seringe to the Société de physique de Genève in 1822.[57] Wallich himself afterwards gave a lengthened account of it in his Plantæ Asiaticæ Rariores (1830).[58]

Description—Balfour, who also figures A. ferox,[59] describes the plant from a specimen that flowered in the Botanical Garden of Edinburgh as—“having 2—3 fasciculated, fusiform, attenuated tubers, some of the recent ones being nearly 5 inches long, and 1½ inches in circumference, dark brown externally, white within, sending off sparse, longish branching fibres.”

Aconite root has of late been imported into London from India in considerable quantity, and been offered by the wholesale druggists as Nepal Aconite.[60] It is of very uniform appearance, and seems derived from a single species, which we suppose to be A. ferox. The drug consists of simple tuberous roots of an elongated conical form, 3 to 4 inches long, and ½ to 1¾ inches in greatest diameter. Very often the roots have been broken in being dug up and are wanting in the lower extremity: some are nearly as broad at one end as at the other. They are mostly flattened and not quite cylindrical, often arched, much shrivelled chiefly in a longitudinal direction, and marked rather sparsely with the scars of rootlets. The aerial stem has been closely cut away, and is represented only by a few short scaly rudiments.[61]

The roots are of a blackish brown, the prominent portions being often whitened by friction. In their normal state they are white and farinaceous within, but as they are dried by fire-heat and often even scorched, their interior is generally horny, translucent, and extremely compact and hard. The largest root we have met with weighed 555 grains.

In the Indian Bazaars, Bish is found in another form, the tuberous roots having been steeped in cow’s urine to preserve them from insects.[62] These roots which in our specimen[63] are mostly plump and cylindrical, are flexible and moist when fresh, but become hard and brittle by keeping. They are externally of very dark colour, black and horny within, with an offensive odour resembling that of hyraceum or castor. Immersed in water, though only for a few moments, they afford a deep brown solution. Such a drug is wholly unfit for use in medicine, though not unsuitable, perhaps, for the poisoning of wild beasts, a purpose to which it is often applied in India.[64]

Microscopic Structure—Most of the roots fail to display any characteristic structure by reason of the heat to which they have been subjected. A living root sent to us from the Botanical Garden of Edinburgh exhibited the thin brownish layer which encloses the central part in A. Napellus, replaced by a zone of stone-cells,—a feature discernible in the imported root.

Chemical Composition—According to Wright and Luff (see previous article) the roots of Aconitum ferox contain comparatively large quantities of pseudaconitine with a little aconitine and an alkaloid, apparently non-crystalline, which would appear not to agree with the analogous body from A. Napellus.

Uses—The drug has been imported and used as a source of aconitine. It is commonly believed to be much more potent than the aconite root of Europe.

RADIX ACONITI HETEROPHYLLI.

Atís or Atees.

Botanical Origin—Aconitum heterophyllum Wallich, a plant of 1 to 3 feet high with a raceme of large flowers of a dull yellow veined with purple, or altogether blue, and reniform or cordate, obscurely 5-lobed, radical leaves.[65] It grows at elevations of 8000 to 13,000 feet in the temperate regions of the Western Himalaya, as in Simla, Kumaon and Kashmír.

History—We have not met with any ancient account of this drug, which however is stated by O’Shaughnessy[66] to have been long celebrated in Indian medicine as a tonic and aphrodisiac. It has recently attracted some attention on account of its powers as an antiperiodic in fevers, and has been extensively prescribed by European physicians in India.

Description—The tuberous roots of A. heterophyllum are ovoid, oblong, and downward-tapering or obconical; they vary in length from ½ to 1½ inches and in diameter from ³/₁₀ to ⁶/₁₀ of an inch, and weigh from 5 to 45 grains. They are of a light ash colour, wrinkled and marked with scars of rootlets, and have scaly rudiments of leaves at the summit. Internally they are pure white and farinaceous. A transverse section shows a homogeneous tissue with 4 to 7 yellowish vascular bundles. In a longitudinal section these bundles are seen to traverse the root from the scar of the stem to the opposite pointed end, here and there giving off a rootlet. The taste of the root is simply bitter with no acridity.

Microscopic Structure—The tissue is formed of large angular thin-walled cells loaded with starch which is either in the form of isolated or compound granules. The vascular bundles contain numerous spiroid vessels which seen in transverse section appear arranged so as to form about four rays. The outer coat of the root is made up of about six rows of compressed, tabular cells with faintly brownish walls.

Chemical Composition—The root contains Atisine, an amorphous alkaloid of intensely bitter taste discovered by Broughton,[67] who assigns to it the formula C₄₆H₇₄N₂O₅, obtained from concurrent analysis of a platinum salt. The alkaloid is readily soluble in bisulphide of carbon or in benzol, also to some extent in water. It is of decidedly alkaline reaction, devoid of any acridity. Atisine has also been prepared (1877) by Dunin[68] from the root in the laboratory of one of us. We have before us its hydroiodate, forming colourless crystallized scales, which we find to be very sparingly soluble in cold alcohol or water. At boiling temperature the hydroiodate of atisine is readily dissolved; the aqueous solution on cooling yields beautiful crystals. They agree, according to Dunin, with the formula C₄₆H₇₄N₂O₄. HI + OH₂; this chemist has also shown atisine not to be poisonous. The absence in the drug of aconitine is proved by medical experience,[69] and fully confirmed by the absence of any acridity in the root.

Uses—The drug is stated to have proved a valuable remedy in intermittent and other paroxysmal fevers. In ordinary intermittents it may be given in powder in 20-grain doses. As a simple tonic the dose is 5 to 10 grains thrice a day.

Substitutes—The native name Atís applied in India to several other drugs, one of which is an inert tasteless root commonly referred to Asparagus sarmentosus L. In Kunawar the tubers of Aconitum Napellus L. are dug up and eaten as a tonic, the name atís being applied to them as well as to those of A. heterophyllum.[70]

RADIX CIMICIFUGÆ.

Botanical Origin—Cimicifuga racemosa Elliott (Actæa racemosa L.), a perennial herb 3 to 8 feet high, abundant in rich woods in Canada and the United States, extending southward to Florida.[71] It much resembles Actæa spicata L., a plant widely spread over the northern parts of Europe, Asia, and America, occurring also in Britain; but it differs in having an elongated raceme of 3 to 8 inches in length and dry dehiscent capsules. A. spicata has a short raceme and juicy berries, usually red.

History—The plant was first made known by Plukenet in 1696 as Christophoriana Canadensis racemosa. It was recommended in 1743 by Colden[72] and named in 1749 by Linnæus in his Materia Medica as Actæa racemis longissimis. In 1823 it was introduced into medical practice in America by Garden; it began to be used in England about the year 1860.[73]

Description—The drug consists of a very short, knotty, branching rhizome, ½ an inch or more thick, having, in one direction, the remains of several stout aerial stems, and in the other, numerous brittle, wiry roots, ¹/₂₀ to ⅒ of an inch in diameter, emitting rootlets still smaller. The rhizome is of somewhat flattened cylindrical form, distinctly marked at intervals with the scars of fallen leaves. A transverse section exhibits in the centre a horny whitish pith, round which are a number of rather coarse, irregular woody rays, and outside them a hard, thickish bark. The larger roots when broken display a thick cortical layer, the space within which contains converging wedges of open woody tissue 3 to 5 in number forming a star or cross,—a beautiful and characteristic structure easily observed with a lens. The drug is of a dark blackish brown; it has a bitter, rather acrid and astringent taste, and a heavy narcotic smell.

Microscopic Structure—The most striking character is afforded by the rootlets, which on a transverse section display a central woody column, traversed usually by 4 wide medullary rays and often enclosing a pith. The woody column is surrounded by a parenchymatous layer separated from the cortical portion by one row of densely packed small cells constituting a boundary analogous to the nucleus-sheath (Kernscheide) met with in many roots of monocotyledons, as for instance in sarsaparilla. The parenchyme of cimicifuga root contains small starch granules. The structure of the drug is, on the whole, the same as that of the closely allied European Actæa spicata L.

Chemical Composition—Tilghmann[74] in 1834 analysed the drug, obtaining from it gum, sugar, resin, starch and tannic acid, but no peculiar principal.

Conard[75] extracted from it a neutral crystalline substance of intensely acrid taste, soluble in dilute alcohol, chloroform, or ether, but not in benzol, oil of turpentine, or bisulphide of carbon. The composition of this body has not been ascertained. The same chemist showed the drug not to afford a volatile principle, even in its fresh state.

The American practitioners called Eclectics prepare with Black Snake-root in the same manner as they prepare podophyllin, an impure resin which they term Cimicifugin or Macrotin. The drug yields, according to Parrish, 3¾ per cent. of this substance, which is sold in the form of scales or as a dark brown powder.

Uses—Cimicifuga usually prescribed in the form of tincture (called Tinctura Actæa racemosæ) has been employed chiefly in rheumatic affections. It is also used in dropsy, the early stages of phthisis, and in chronic bronchial disease. A strong tincture has been lately recommended in America as an external application for reducing inflammation.[76]

---

CORTEX BERBERIDIS INDICUS.

Indian Barberry Bark.

Botanical Origin—This drug is allowed in the Pharmacopœia of India to be taken indifferently from three Indian species of Berberis[153] which are the following:—

1. Berberis aristata DC., a variable species occurring in the temperate regions of the Himalaya at 6000 to 10,000 feet elevation, also found in the Nilgiri mountains and Ceylon.[154]

2. B. Lycium, Royle, an erect, rigid shrub found in dry, hot situations of the western part of the Himalaya range at 3000 to 9000 feet above the sea-level.

3. B. asiatica Roxb.—This species has a wider distribution than the last, being found in the dry valleys of Bhutan and Nepal whence it stretches westward along the Himalaya to Garhwal, and occurs again in Afghanistan.

History—The medical practitioners of ancient Greece and Italy made use of a substance called Lycium, (λύκιον) of which the best kind was brought from India. It was regarded as a remedy of great value in restraining inflammatory and other discharges; but of all the uses to which it was applied the most important was the treatment of various forms of ophthalmic inflammation.

Lycium is mentioned by Dioscorides, Pliny, Celsus, Galen, and Scribonius Largus; by such later Greek writers as Paulus Ægineta, Ætius, and Oribasius, as well as by the Arabian physicians.

The author of the Periplus of the Erythrean Sea who probably lived in the 1st century, enumerates λύκιον as one of the exports of Barbarike at the mouth of the Indus, and also names it along with Bdellium and Costus among the commodities brought to Barygaza:—and further, lycium is mentioned among the Indian drugs on which duty was levied at the Roman custom-house of Alexandria about a.d. 176-180.[155]

An interesting proof of the esteem in which it was held is afforded by some singular little vases or jars of which a few specimens are preserved in collections of Greek antiquities.[156] These vases were made to contain lycium, and in them it was probably sold; for an inscription on the vessel not only gives the name of the drug but also that of a person who, we may presume, was either the seller or the inventor of the composition. Thus we have the Lycium of Jason, of Musæus, and of Heracleus. The vases bearing the name of Jason were found at Tarentum, and there is reason to believe that that marked Heracleus was from the same locality. Whether it was so or not, we know that a certain Heraclides of Tarentum is mentioned by Celsus[157] on account of his method of treating certain diseases of the eye; and that Galen gives formulæ for ophthalmic medicines[158] on the authority of the same person.

Innumerable conjectures were put forth during at least three centuries as to the origin and nature of lycium, and especially of that highly esteemed kind that was brought from India.

In the year 1833, Royle[159] communicated to the Linnean Society of London a paper proving that the Indian Lycium of the ancients was identical with an extract prepared from the wood or root of several species of Berberis growing in Northern India, and that this extract, well known in the bazaars as Rusot or Rasot, was in common use among the natives in various forms of eye disease.[160] This substance attracted considerable notice in India, and though its efficacy per se[161] seemed questionable, it was administered with benefit as a tonic and febrifuge.[162] But the rusot of the natives being often badly prepared or adulterated, the bark of the root has of late been used in its place, and in consequence of its acknowledged efficacy has been admitted to the Pharmacopœia of India.

Description.—In B. asiatica (the only species we have examined) the roots which are thick and woody, and internally of a bright yellow, are covered with a thin, brittle bark. The bark has a light-brown corky layer, beneath which it appears of a darker and greenish yellow hue, and composed of coarse fibres running longitudinally. The inner surface has a glistening appearance by reason of fine longitudinal striæ. The bark is inodorous and very bitter.

Chemical Composition.—Solly[163] pointed out in 1843 that the root-bark of the Ceylon barberry [B. aristata] contains the same yellow colouring matter as the barberry of Europe. L. W. Stewart[164] extracted Berberine in abundance from the barberry of theNilgiri Hills and Northern India, and presented specimens of it to one of us in 1865.

The root-bark of Berberis vulgaris L. was found by Polex (1836) to contain another alkaloid named Oxyacanthine, which forms with acids colourless crystallizable salts of bitter taste.[165]

Uses.—The root-bark of the Indian barberries administered as a tincture has been found extremely useful in India in the treatment of fevers of all types. It has also been given with advantage in diarrhœa and dyspepsia, and as a tonic for general debility. In the collection of the Chinese customs at Paris, in 1878, the root-barks of Berberis Lycium and B. chinensis, from the province of Shensi, were likewise exhibited (No. 1,823) as a tonic.

RHIZOMA PODOPHYLLI.

Radix podophylli; Podophyllum Root.

Botanical Origin—Podophyllum peltatum L., a perennial herb growing in moist shady situations throughout the eastern side of the North American continent from Hudson’s Bay to New Orleans and Florida.

The stem about a foot high, bears a large, solitary, white flower, rising from between two leaves of the size of the hand composed of 5 to 7 wedge-shaped divisions, somewhat lobed and toothed at the apex. The yellowish pulpy fruit of the size of a pigeon’s egg is slightly acid and is sometimes eaten under the name of May Apple. The leaves partake of the active properties of the root.

History—The virtues of the rhizome as an anthelminthic and emetic have been long known to the Indians of North America. The plant was figured in 1731 by Catesby[166] who remarks that its root is an excellent emetic. Its cathartic properties were noticed by Schöpf[167] and Barton[168] and have been commented upon by many subsequent writers. In 1820, podophyllum was introduced into the United States Pharmacopœia, and in 1864 into the British Pharmacopœia. Hodgson published in 1832 in the Journal of the Philadelphia College of Pharmacy[169] the first attempt of a chemical examination of the rhizome, which now furnishes one of the most popular purgatives, the so-called Podophyllin, manufactured on a large scale at Cincinnati and in other places in America, as well as in England.

Description—The drug consists of the rhizome and rootlets. The former creeps to a length of several feet, but as imported is mostly in somewhat flattened pieces of 1 to 8 inches in length and 2 to 4 lines in longest diameter: it is marked by knotty joints showing a depressed scar at intervals of a few inches which marks the place of a fallen stem. Each joint is in fact the growth of one year, the terminal bud being enclosed in papery brownish sheaths. Sometimes the knots produce one, two, or even three lateral buds and the rhizome is bi- or tri-furcate. The reddish-brown or grey surface is obscurely marked at intervals by oblique wrinkles indicating the former attachment of rudimentary leaves. The rootlets are about ½ a line thick and arise from below the knots and adjacent parts of the rhizome, the internodal space being bare. They are brittle, easily detached, and commonly of a paler colour. The rhizome is mostly smooth, but some of the branched pieces are deeply furrowed. Both rootstock and rootlets have a short, smooth, mealy fracture; the transverse section is white, exhibiting only an extremely small corky layer and a thin simple circle of about 20 to 40 yellow, vascular bundles, enclosing a central pith which in the larger pieces is often 2 lines in diameter.

The drug has a heavy narcotic, disagreeable odour, and a bitter, acrid, nauseous taste.

Microscopic Structure—The vascular bundles are composed of spiral and scalariform vessels intermixed with cambial tissue. From each bundle a narrow-tissued, wedge-or crescent-shaped liber-bundle projects a little into the cortical layer. This, as well as the pith, exhibits large thin-walled cells. The rootlets are as usual of a different structure, their central part consisting of one group of vascular bundles more or less scattered.[170] The parenchymatous cells of the drug are loaded with starch granules; some also contain stellate tufts of oxalate of calcium.

Chemical Composition—The active principles of podophyllum exist in the resin, which according to Squibb[171] is best prepared by the process termed re-percolation. The powdered drug is exhausted by alcohol which is made to percolate through successive portions. The strong tincture thus obtained is slowly poured into a large quantity of water acidulated with hydrochloric acid (one measure of acid to 70 of water), and the precipitated resin dried at a temperature not exceeding 32° C. The acid is used to facilitate the subsidence of the pulverulent resin which according to Maisch settles down but very slowly if precipitated by cold water simply, and if thrown down by hot water fuses into a dark brown cake. The resin redissolved in alcohol and again precipitated by acidulated water, after thorough washing with distilled water and finally drying over sulphuric acid, amounts to about 2 per cent.

Resin of podophyllum is a light, brownish-yellow powder with a tinge of green, devoid of crystalline appearance, becoming darker if exposed to a heat above 32° C., and having an acrid, bitter taste; it is very incorrectly called Podophyllin. The product is the same whether the rhizome or the rootlets are exclusively employed.[172] It is soluble in caustic, less freely in carbonated alkalis, even in ammonia, and is precipitated, apparently without alteration, on addition of an acid. Ether separates it into two nearly equal portions, the one soluble in the menstruum, the other not, but both energetically purgative. From the statements of Credner[173] it appears that if caustic lye is shaken with the ethereal solution, about half the resin combines with the potash, while the other half remains dissolved in the ether. If an acid is added to the potassic solution a red-brown precipitate is produced which is no longer soluble in ether nor possessed of purgative power. According to Credner, the body of greatest purgative activity was precipitated by ether from an alcoholic solution of crude podophyllin.

By exhausting the resin with boiling water, Power found that finally not more than 20 per cent. of the resin remained undissolved. By melting the crude resin with caustic soda, a little protocatechuic acid was obtained.

F. F. Mayer[174] of New York stated podophyllum to contain, beside the resin already mentioned, a large proportion of Berberine, a colourless alkaloid, an odoriferous principle which might be obtained by sublimation in colourless scales, and finally Saponin. From all these bodies the resin as prepared by Power,[175] was ascertained by him to be destitute; he especially proved the absence of berberine in Podophyllum.

Uses—Podophyllum is only employed for the preparation of the resin (Resina Podophylli) which is now much prescribed as a purgative.

---

SEMEN SINAPIS NIGRÆ.

Black, Brown or Red Mustard; F. Moutarde noire ou grise; G. Schwarzer Senf.

Botanical Origin—Brassica nigra Koch (Sinapis nigra L.). Black Mustard is found wild over the whole of Europe excepting the extreme north. It also occurs in Northern Africa, Asia Minor, Mesopotamia, the Caucasian region, Western India, as well as in Southern Siberia and China. By cultivation, which is conducted on a large scale in many countries (as Alsace, Bohemia, Holland, England and Italy), it has doubtless been diffused through regions where it did not anciently exist. It has now become naturalized both in North and South America.

History—Mustard was well known to the ancients. Theophrastus mentions it as Νάπμ,—Dioscorides as Νάπμ or Σίνηπι. Pliny notices three kinds which have been referred by Fée[280] to Brassica nigra Koch, B. alba Hook. f. et Th., and to a South European species, Diplotaxis erucoides DC. (Sinapis erucoides L.). The use of mustard seems up to this period to have been more medicinal than dietetic. But from an edict of Diocletian, a.d. 301[281] in which it is mentioned along with alimentary substances, we must suppose it was then regarded as a condiment at least in the eastern parts of the Roman Empire.

In Europe during the middle ages mustard was a valued accompaniment to food, especially to the salted meat which constituted a large portion of the diet of our ancestors during the winter.[282] In the Welsh “Meddygon Myddvai,” of the 13th century, a paragraph is devoted to the “Virtues of Mustard.” In household accounts of the 13th and 14th centuries, mustard under the name of Senapium is of constant occurrence.

Mustard was then cultivated in England, but not as it would seem very extensively. The price of the seed between a.d. 1285 and 1395 varied from 1s. 3d. to 6s. 8d. per quarter, but in 1347 and 1376 it was as high as 15s. and 16s.[283] In the accounts of the abbey of St. Germain-des-Prés in Paris, commencing a.d. 800, mustard is specifically mentioned as a regular part of the revenue of the convent lands.[284]

The essential oil of mustard was, apparently, noticed about the year 1660 by Nicolas Le Febvre (see in the article Rad. Inulae), more distinctly in 1732 by Boerhaave. Its acridity and high specific gravity were pointed out by Murray.[285] Thibierge in 1819 observed that sulphur was one of the constituents of the oil, and Guibourt[286] stated that it is not pre-existing in the seed.

Production—Mustard is grown in England only on the richest alluvial soils, and chiefly in the counties of Lincolnshire and Yorkshire. Very good seed is produced in Holland.

Description—The pod of Brassica nigra is smooth, erect, and closely pressed against the axis of the long slender raceme. It has a strong nerve on each of its two valves and contains in each cell from 4 to 6 spherical or slightly oval seeds. The seeds are about ¹/₂₅ of an inch in diameter and ¹/₅₀ of a grain in weight; they are of a dark reddish-brown. The surface is reticulated with minute pits, and often more or less covered with a whitish pellicle which gives to some seeds a grey colour.[287] The testa which is thin, brittle and translucent encloses an exalbuminous embryo having two short cotyledons folded together longitudinally and forming a sort of trough in which the radicle lies bent up. The embryo thus coiled into a ball completely fills the testa; the outer cotyledon is thicker than the inner, which viewed in transverse section seems to hold the radicle as a pair of forceps. The seeds when pulverized have a greenish yellow hue. Masticated they have for an instant a bitterish taste which however quickly becomes pungent. When triturated with water they afford a yellowish emulsion emitting a pungent acrid vapour which affects the eyes, and has a strong acid reaction. The seeds powdered dry have no such pungency. When the seeds are triturated with solution of potash, the pungent odour is not evolved; nor when they are boiled in water. Neither is the acridity developed on triturating them with alcohol, dilute mineral acids, or solution of tannin, or even with water when they have been kept in powder for a long time.

Microscopic Structure—The whitish pellicle already mentioned, which covers the seed, is made up of hexagonal tabular cells. The epidermis consists of one row of densely packed brown cells, radially elongated and having strong lateral and inner walls. Their outer walls on the other hand are thin and not coloured; they are not clearly obvious when seen under oil, but swell up very considerably in presence of water, emitting mucilage.[288] Seeds immersed in water become therefore covered with a glossy envelope, levelling down the superficial inequalities, so that the wet seed appears smooth. The tissue of the cotyledons exhibits large drops of fatty oil and granules of albumin.

Chemical Composition—By distilling brown mustard with water, the seed having been previously macerated, the pungent principle, Essential Oil of Mustard, is obtained.

The oil, which has the composition SCN(C₃H⁵), (allyl isosulphocyanate), boils at 148° C.; it has a sp. gr. of 1·017, no rotatory power, and is soluble without coloration or turbidity in three times its weight or more of cold strong sulphuric acid. To this oil is due the pungent smell and taste of mustard and its inflammatory action on the skin. As already pointed out, mustard oil is not present in the dry seeds, but is produced only after they have been comminuted and mixed with water, the temperature of which should not exceed 50° C.

The remarkable reaction which gives rise to the formation of mustard oil was explained by Will and Körner in 1863. They obtained from mustard a crystallizable substance, then termed Myronate of potassium, now called Sinigrin. It is to be regarded, according to the admirable investigations of these chemists, as a compound of

Isosulphocyanate of allyl or mustard oil	C₄	H₆	NS
Bisulphate of potassium		H	KS	O₄
Sugar (dextro-glucose)	C₆	H₁₂		O₆
so that the formula	C₁₀	H₁₈	KNS₂	O₁₀

is that of sinigrin. It does in fact split into the above-mentioned three substances when dissolved in water and brought into contact with Myrosin.

This albuminous body discovered by Bussy in 1839, but the composition of which has not been made out, likewise undergoes a certain decomposition under these circumstances. Sinigrin may likewise be decomposed by alkalis and, according to Ludwig and Lange, by silver nitrate. These chemists obtained sinigrin from the seeds in the proportion of 0·5 per cent.; Will and Körner got 0·5 to 0·6 per cent. The extraction of the substance is therefore attended with great loss, as the minimum yield of volatile oil, 0·42 per cent. indicates 2·36 of potassium myronate.

The aqueous solution of myrosin coagulates at 60° C. and then becomes inactive: hence mustard seed which has been heated to 100° C. or has been roasted yields no volatile oil, nor does it yield any if powdered and introduced at once into boiling water. The proportion of myrosin in mustard has not been exactly determined. The total amount of nitrogen in the seed is 2·9 per cent. (Hoffmann) which would correspond to 18 per cent. of myrosin, supposing the proportion of nitrogen in that substance to be the same as in albumin, and the total quantity of nitrogen to belong to it. Sometimes black mustard contains so little of it, that an emulsion of white mustard requires to be added in order to develop all the volatile oil it is capable of yielding.

An emulsion of mustard or a solution of pure sinigrin brought into contact with myrosin, frequently deposits sulphur by decomposition of the allyl sulphocyanide, hence crude oil of mustard sometimes contains a considerable proportion (even half) of Allyl cyanide, C₄H₅N, distinguished by its lower sp. gr. (0·839) and lower boiling point (118° C.).

The seeds, roots, or herbaceous part of many other plants of the order Cruciferæ yield a volatile oil composed in part of mustard oil and in part of allyl sulphide

C₆H₁₀S =	C₂H₅		S,
	C₃H₅

which latter is likewise obtainable from the bulbs of garlic. Many Cruciferæ afford from their roots or seeds chiefly or solely oil of mustard, and from their leaves oil of garlic. As to other plants, the roots of Reseda lutea L. and R. luteola L. have been shown by Volhard (1871) to afford oil of mustard.[289] The strong smell given off by the crushed seeds or roots of several Mimoseæ, as for instance, Albizzia lophantha Benth. (Acacia Willd.) is perhaps due to some allied compound.

The artificial preparation of mustard oil was discovered in 1855 by Zinin, and at the same time also by Berthelot and De Luca. It may be obtained in decomposing bromide of allyl by means of sulphocyanate of ammonium:—

C₃H₅Br · SCN(NH₄) = NH₄Br · C₃H₅SCN.

The liquid C₃H₅SCN, boiling at 161°, is sulphocyanate of allyl; if it is gently warmed with a little alcoholic potash, and then acidulated, the red coloration of ferric sulphocyanate is produced on addition of perchloride of iron, but by submitting the sulphocyanate of allyl to distillation it is at once transformed in the isosulphocyanate, i.e. in mustard oil; the latter is not coloured by ferric salts, but it would appear that in the cold emulsion of mustard, even at 0°, a little sulphocyanate makes also its appearance.

Mustard submitted to pressure affords about 23 per cent.[290] of a mild-tasting, inodorous, non-drying oil, solidifying when cooled to -17·5° C., and consisting of the glycerin compounds of stearic, oleic and Erucic or Brassic Acid. The last named acid, C₂₂H₄₂O₂, occurs also in the fixed oil of white mustard and of rape, and is homologous with oleic acid. Darby (1849) has pointed out the existence of another body, Sinapoleic Acid, C₂₀H₃⁸O₂, which occurs in the fixed oil of both black and white mustard. Goldschmiedt, in 1874, ascertained the presence also of Behenic Acid, C₂₂H₄₄O₂ in black mustard. Sinigrin being not altered by the extraction of the fatty oil, either by pressure or by means of bisulphide of carbon, the powdered seed, deprived of fatty oil, still yields the whole amount of the irritating “essential” oil. This important fact has been ingeniously used by Rigollot[291] for the preparation of his mustard paper.

Mustard seed when ripe is devoid of starch; the mucilage which its epidermis affords amounts to 19 per cent. of the seed (Hoffmann). The ash constituents amounting to 4 per cent. consist chiefly of the phosphates of calcium, magnesium, and potassium.

Uses—Black mustard is employed in the form of poultice as a powerful external stimulant; but it is rarely used in its pure state, as the Flour of Mustard prepared for the table, which contains in addition white mustard, answers perfectly well and is at hand in every house.[292]

The essential oil of mustard dissolved in spirit of wine is occasionally prescribed as a liniment.

Substitute—Brassica juncea Hook. f. et Th. (Sinapis juncea L.) is extensively cultivated throughout India (where B. nigra is rarely grown), Central Africa, and generally in warm countries where it replaces B. nigra and is applied to the same uses. Its seeds constitute a portion of the mustard of Europe, as we may infer from the fact that British India exported in the year 1871-72, of “Mustard seed” 1418 tons, of which 790 tons were shipped to the United Kingdom, and 516 tons to France.[293] B. juncea is largely grown in the south of Russia and in the steppes north-east of the Caspian where it appears to flourish particularly well in the saline soil. At Sarepta in the Government of Saratov, an establishment has existed since the beginning of the present century where this sort of mustard is prepared for use to the extent of 800 tons of seed annually. The seeds make a fine yellow powder employed both for culinary and medicinal purposes. By pressure they yield more than 20 per cent. of fixed oil which is used in Russia like the best olive oil. The seeds closely resemble those of B. nigra and afford when distilled the same essential oil; it is largely made at Kiew.

SEMEN SINAPIS ALBÆ.

Botanical Origin—Brassica alba Hook. f. et Th. (Sinapis alba L.) This plant appears to belong to the more southern countries of Europe and Western Asia. According to Chinese authors[294] it was introduced into China from the latter region. Its cultivation in England is of recent introduction, but is rapidly extending.[295] The plant is not uncommon as a weed on cultivated land.

History—White mustard was used in former times indiscriminately with the brown. In the materia medica of the London Pharmacopœia of 1720 the two sorts are separately prescribed. The important chemical distinction between them was first made known in 1831 by Boutron-Charlard and Robiquet.[296]

Production—White mustard is grown as an agricultural crop in Essex and Cambridgeshire.

Description—Brassica alba differs from B. nigra in having the pods bristly and spreading. They are about an inch long, half the length being occupied by a flat veiny beak. Each pod contains 4 to 6 yellowish seeds about ¹/₁₂ of an inch in diameter and ⅒ of a grain in weight. The brittle, nearly transparent and colourless testa encloses an embryo of a bright pure yellow and of the same structure as that of black mustard. The surface of the testa is likewise pitted in a reticulate manner, but so finely that it appears smooth except under a high magnifying power.

When triturated with water the seeds form a yellowish emulsion of very pungent taste, but it is inodorous and does not under any circumstances yield a volatile oil. The powdered seeds made into a paste with cold water act as a highly stimulating cataplasm. The entire seeds yield to cold water an abundance of mucilage.

Microscopic Structure—The epidermal cells of white mustard afford a good illustration of a mucilage-yielding layer such as is met with, under many variations, in the seeds of numerous plants. The cuticle consists of large vaulted cells, exhibiting very regular hexagonal outlines when cut across.[297] The inner layer of the epidermis is made up of thin-walled cells, which when moistened swell and give off the mucilage. In the dry state or seen under oil, the outlines of the single cells of this layer are not distinguishable. The tissue of the cotyledons is loaded with drops of fatty oil and with granular albuminoid matter; starch which is present in the seed while young, is altogether absent when the latter reaches maturity.

Chemical Composition—White mustard deprived of fatty oil yields to boiling alcohol colourless crystals of Sinalbin, an indifferent substance, readily soluble in cold water, but sparingly in cold alcohol. From the able investigations of Will (1870) it follows, that it is to be regarded as composed of three bodies, namely:

Sulphocyanate of Acrinyl	C⁸	H₇	N	S	O
Sulphate of Sinapine	C₁₆	H₂₅	N	S	O₉
Sugar	C₆	H₁₂			O₆
so that the formula	C₃₀	H₄₄	N₂	S₂	O₁₆

represents according to Will the composition of sinalbin. It is actually resolved into these three substances when placed at ordinary temperatures, in contact with water and Myrosin, the latter of which is a constituent of white mustard as well as of brown (p. 66). The liquid becomes turbid, the first of the above-named substances separates (together with coagulated albumin) as an oily liquid, not soluble in water, but dissolving in alcohol or ether. This Sulphocyanate of Acrinyl is the rubefacient and vesicating principle of white mustard. It does not pre-exist, as shown by Will, in the seed, and cannot be obtained by distillation. By treating it with a salt of silver, Will obtained crystals of cyanide of acrinyl, C₈H₇NO: by warming it (or sinalbin itself, or an alcoholic extract of the seed) with caustic potash, sulphocyanide of potassium is produced. The presence of the latter may be indicated by adding a drop of perchloride of iron, when a blood-red coloration will be produced.[298]

Sulphate of Sinapine imparts to the emulsion of white mustard, in which it is formed, an acid reaction. Sinapine is itself an alkaloid, which has not yet been isolated, as it is very liable to change. Thus its solution on addition of a trace of alkali immediately assumes a bright yellow colour indicating decomposition, and a similar colour is produced in an aqueous extract of the seed.

The above statements show, that the chemical properties of sinalbin and its derivatives correspond closely with those of sinigrin (p. 66) and the substances which make their appearance in an emulsion of black mustard.

The other constituents of white mustard seed are nearly the same as those of black. The fat oil appears to yield in addition to the acids mentioned at p. 67, Benic or Behenic Acid, C₂₂H₄₄O₂. White mustard is said to be richer than black in myrosin, so that, as explained in the previous article, the pungency of the latter may be often increased by an addition of white mustard. By burning white mustard dried at 100° C., with soda-lime, we obtained from 4·20 to 4·30 per cent. of nitrogen, answering to about 28 per cent. of protein substances.[299] The fixed oil of the seed amounts to 22 per cent. The mucilage as yielded by the epidermis is precipitable by alcohol, neutral lead acetate, or ferric chloride, and is soluble in water after drying.

Erucin and Sinapic Acid, mentioned by Simon (1838)[300] as peculiar constituents of white mustard, are altogether doubtful, yet may deserve further investigation. The sinapic acid of Von Babo and Hirschbrunn[301] (1852) is a product of the decomposition of sinapine.

Uses—White Mustard seed reduced to powder and made into a paste with cold water act as a powerful stimulant when applied to the skin, notwithstanding that such paste is entirely wanting in essential oil. But for sinapisms they are actually used only in the form of the Flour of Mustard which is prepared for the table and which contains also Brown Mustard seed.

RADIX ARMORACIÆ.

Botanical Origin—Cochlearia Armoracia L., a common perennial with a stout tapering root, large coarse oblong leaves with long stalks, and erect flowering racemes 2 to 3 feet high. It is indigenous to the eastern parts of Europe, from the Caspian through Russia and Poland to Finland. In Britain and in other parts of Europe from Sicily to the polar circle, it occurs cultivated or semi-wild; in the opinion of Schübeler[302] it is not truly indigenous to Norway.

History—The vernacular name Armon is stated by Pliny[303] to be used in the Pontic regions to designate the Armoracia of the Romans, the Wild Radish (ῤαϕανὶς ἀγρία) of the Greeks, a plant which cannot be positively identified with that under notice.

Horse-radish is called in the Russian language Chren, in Lithuanian Krenai, in Illyrian Kren, a name which has passed into several German dialects, and as Cran or Cranson into French.

From these and similar facts, De Candolle[304] has drawn the conclusion that the propagation of the plant has travelled from Eastern to Western Europe.

Both the root and leaves of horse-radish were used as a medicine and also eaten with food in Germany and Denmark during the middle ages.[305] But the use of the former was not common in England until a much later period. The plant is mentioned in the Meddygon Myddfai and was known in England as Red-cole in the time of Turner, 1568, but is not quoted by him[306] as used in food, nor is it noticed by Boorde,[307] 1542, in his chapter on edible roots. Gerarde[308] at the end of the 16th century remarks that horse-radish—“is commonly used among the Germans for sauce to eat fish with, and such like meats, as we do mustard.” Half a century later the taste for horse-radish had begun to prevail in England. Coles[309] (1657) states that the root sliced thin and mixed with vinegar is eaten as a sauce with meat as among the Germans. That the use of horse-radish in France had the same origin is proved by its old French name Moutarde des Allemands.

The root to which certain medicinal properties had always been assigned, was included in the materia medica of the London Pharmacopœias of the last century under the name of Raphanus rusticanus.

Description—The root which in good ground often attains a length of 3 feet and nearly an inch in diameter, is enlarged in its upper part into a crown, usually dividing into a few short branches each surmounted by a tuft of leaves, and annulated by the scars of fallen foliage; below the crown it tapers slightly, and then for some distance is often almost cylindrical, throwing off here and there filiform and long slender cylindrical roots, and finally dividing into two or three branches. The root is of a light yellowish-brown; internally it is fleshy and perfectly white, and has a short non-fibrous fracture. Before it is broken it is inodorous, but when comminuted it immediately exhales its characteristic pungent smell. Its well-known pungent taste is not lost in the root carefully dried and not kept too long.

A transverse section of the fresh root displays a large central column with a radiate and concentric arrangement of its tissues, which are separated by a small greyish circle from the bark, whose breadth is from ½ to 2 lines. In the root branches there is neither a well-defined liber nor a true pith. The short leaf-bearing branches include a large pith surrounded by a circle of woody bundles. The bark adheres strongly to the central portion, in which zones of annual growth are easily perceptible, at least in older specimens.

Microscopic Structure—The corky layer is made up of small tabular cells as usual in suberous coats. In the succeeding zone of the middle bark, thick-walled yellow cells are scattered through the parenchyme, chiefly at the boundary line of the corky layer. In the root the cellular envelope is not strikingly separated from the liber, whilst in its leafy branches this separation is well marked by wedge-shaped liber bundles, which are accompanied by a group of the yellow longitudinally-elongated stone-cells. The woody bundles contain a few short yellow vessels, accompanied by bundles of prosenchymatous, not properly woody cells. The centre, in the root, shows these woody bundles to be separated by the medullary parenchyma; in the branches the central column consists of an uniform pith without woody bundles, the latter forming a circle close to the cambium. The parenchyma of the whole root collected in spring is loaded with small starch granules.

Chemical Composition—Among the constituents of horse-radish root (the chemical history of which is however far from perfect) the volatile oil is the most interesting. The fresh root submitted to distillation with water in a glass retort, yields about ½ per mille of oil which is identical with that of Black Mustard as proved in 1843 by Hubatka. He combined it with ammonia and obtained crystals of thiosinammine, the composition of which agreed with the thiosinammine from mustard oil.

An alcoholic extract of the root is devoid of the odour of the oil, but this is quickly evolved on addition of an emulsion of White Mustard. The essential oil does not therefore pre-exist, but only sinigrin (myronate of potassium) and an albuminoid matter (myrosin) by whose mutual reaction in the presence of water it is formed (p. 66). This process does not go on in the growing root, perhaps because the two principles in question are not contained in the same cells, or else exist together in some condition that does not allow of their acting on each other,—a state of things analogous to that occurring in the leaves of Lauro-cerasus.

By exhausting the root with water either cold or hot, the sinigrin is decomposed and a considerable proportion of bisulphate is found in the concentrated decoction. Alcohol removes from the root some fatty matter and sugar (Winckler 1849). Salts of iron do not alter thin slices of it, tannic matters being absent. The presence of myrosin, which at present has been inferred rather than proved, ought to be further investigated. The root dried at 100° C afforded 11·15 per cent. of ash to Mutschler (1878).

Uses—An infusion or a distilled spirit of horse-radish is reputed stimulant, diaphoretic, and diuretic, but is not often employed.

Substitute—In India the root of Moringa pterygosperma Gärtn. is considered a substitute for horse-radish. It yields by distillation an essential oil of disgusting odour which Broughton, who obtained it in minute quantity, has assured us is not identical with that of mustard or of garlic.

---

CORTEX CANELLÆ ALBÆ.

Botanical Origin—Canella alba Murray,[310] a tree, 20 to 30 or even 50 feet in height, found in the south of Florida, the Bahama Islands (whence alone its bark is exported), Cuba, Jamaica, Ste. Broix, Guadaloupe, Martinique, Barbadoes and Trinidad.

History—The drug was first mentioned in 1605 by Clusius,[311] who remarks that it had been then newly brought to Europe and had received the name of Canella alba (White Cinnamon). It was afterwards known as Costus Corticosus, Costus dulcis, Cassia alba, Cassia lignea Jamaicensis or Jamaica Winter’s Bark. Dale[312] writing in 1693 notices it as not unfrequently sold for Winter’s Bark. Pomet[313] (1694) describes it as synonymous with Winter’s Bark, and observes that it is common, yet but little employed.

The drug is mentioned by most subsequent writers, some of whom like Pomet probably confounded it with the bark of Cinnamodendron (p. 19). It is usually described as produced in Jamaica or Guadaloupe, from which islands no Canella alba is now exported. On the other hand, New Providence, one of the Bahamas whence the Canella alba of the present day is shipped, is not named. Nor do we find any allusion to the drug in the records of the Company (1630-50) which was formed for the colonization of New Providence and the other islands of the group, though their staple productions are frequently enumerated.[314]

Canella alba Murr. was described and figured by Sloane (1707) and still better by Patrick Brown in 1789, and Olaf Swartz in 1791.[315]

Collection—In the Bahamas, where the drug is known as White-Wood Bark or Cinnamon Bark, it is collected thus:—preparatory to being stripped from the wood, the bark is gently beaten with a stick, which removes the suberous layer. By a further beating, the remaining bark is separated, and having been peeled off and dried, is exported without further preparation.[316]

Description—Canella bark occurs in the form of quills, more or less crooked and irregular, or in channelled pieces from 2 or 3 up to 6, 8, or more inches in length, ½ an inch to 1 or 2 inches in width, and a line or two in thickness. The suberous layer which here and there has escaped removal is silvery grey, and dotted with minute lichens. Commonly, the external surface consists of inner cellular layers (mesophlœum) of a bright buff, or light orange-brown tint, often a little wrinkled transversely, and dotted (but not always) with round scars. The inner surface is whitish or cinnamon-coloured, either smooth or with slight longitudinal striæ. Some parcels of canella show the bark much bruised and longitudinally fissured by the above-mentioned process of beating. The bark breaks transversely with a short granular fracture, which distinctly shows the three, or in uncoated specimens the two, cortical layers, that of the liber being the largest, and projecting by undulated rays or bundles into the middle layer, which presents numerous large and unevenly scattered oil-cells of a yellow colour.

Canella has an agreeable cinnamon-like odour, and a bitter, pungent acrid taste.[317] Even the corky coat is somewhat aromatic.

Microscopical Structure—The spongy suberous coat consists of very numerous layers of large cells with thin walls, showing an undulated rather than rectangular outline. The next small zone is constituted of sclerenchymatous cells in a single, double, or triple row, or forming dense but not very extensive groups. This tissue is sometimes (in unpeeled specimens) a continuous envelope, marking the boundary between the corky layer and the middle portion of the cellular layer; but an interruption in this thick-walled tissue often takes place when portions of it are enveloped and separated by the suberous layer.

The proper cellular envelope shows a narrow tissue with numerous very large cells filled with yellow essential oil. The liber forming the chief portion of the whole bark, exhibits thin prosenchymatous cells, which on traverse section form small bands of a peculiar horny or cartilaginous appearance, on which account they have been distinguished as horny liber (Hornbast of German writers).[318] The liber-fibres show reticulated marks due to the peculiar character of the secondary deposits on their cell-walls. The oil-cells in the liber are less numerous and smaller; the medullary rays are not very obvious unless on account of the crystalline tufts of oxalate of calcium deposited in the latter. This crystalline oxalate retains air obstinately, and has a striking dark appearance.

Chemical Composition—The most interesting body in canella is the volatile oil, examined in 1843 under Wöhler’s direction by Meyer and von Reiche, who obtained it in the proportion of 0·94 from 100 parts of bark. They found it to consist of four different oils, the first being identical with the Eugenol or Eugenic Acid of oil of cloves; the second is closely allied to the chief constituent of cajuput oil. The other oils require further examination.[319]

The bark, of which we distilled 20 lb., afforded 0·74 per cent. of oil. This when distilled with caustic potash in excess was found to be composed of 2 parts of the acid portion and 1 part of the neutral hydrocarbon; the latter has an odour suggesting a mixture of peppermint and cajuput.

Meyer and von Reiche evaporated the aqueous decoction of canella, and removed from the bitter extract by alcohol 8 per cent. of mannite, which they ascertained to be the so-called Canellin described in 1822 by Petroz and Robinet.

The bark yielded the German chemists 6 per cent. of ash, chiefly carbonate of calcium. The bitter principle has not yet been isolated. An aqueous infusion is not blackened by a persalt of iron.

Commerce—Canella alba is collected in the Bahama Islands and shipped to Europe from Nassau in New Providence, the chief seat of trade in the group. In 1876 the export of the bark amounted to 125 cwt.

Uses—The bark is an aromatic stimulant, now but seldom employed. It is used by the West Indian negroes as a condiment.

---

SEMEN GYNOCARDIÆ.

Chaulmugra Seed.

Botanical Origin—Gynocardia odorata R. Br. (Chaulmoogra Roxb., Hydnocarpus Lindl.), a large tree[320] with a globular fruit of the size of a shaddock, containing numerous seeds immersed in pulp. It grows in the forests of the Malayan peninsula and Eastern India as far north as Assam, extending thence along the base of the Himalaya westward to Sikkim.

History—The inhabitants of the south-eastern countries of Asia have long been acquainted with the seeds of certain trees of the tribe Pangieæ (ord. Bixineæ) as a remedy for maladies of the skin. In China a seed called Ta-fung-tsze is imported from Siam[321] where it is known as Lukrabo and used in a variety of cutaneous complaints. The tree affording it, which is figured in the Pun-tasao (circa a.d. 1596) has not been recognised by botanists, but from the structure of the seed it is obviously closely related to Gynocardia.[322]

The properties of G. odorata were known to Roxburgh who, Latinizing the Indian name of the tree, called it (1814) Chaulmoogra odorata. Of late years the seeds have attracted the notice of Europeans in India, and having been found useful in certain skin diseases, they have been admitted a place in the Pharmacopœia of India.

Description—The seeds, 1 to 1¼ inches long and about half as much in diameter, are of irregular ovoid form, and more or less angular or flattened by mutual pressure; they weigh on an average about 35 grains each. The testa is thin (about ¹/₅₀ of an inch), brittle, smooth, dull grey; within there is a brown oily kernel, marked with a darker colour at its basal end. The weight of the kernel is, on an average, twice that of the testa. The former encloses in its copious, soft albumen a pair of large, plain, leafy, heart-shaped cotyledons with a stout radicle. The taste of the kernel is simply oily.

Microscopic Structure—The testa is chiefly formed of cylindrical thick-walled cells. The albumen exhibits large angular cells containing fatty oil, masses of albuminous matter and tufted crystals of calcium oxalate. Starch is not present.

Chemical Composition—The kernels afforded us by means of ether 51·5 per cent. of fatty oil, which is almost colourless or somewhat brownish if the seeds are not fresh. Either extracted or expressed it is of no peculiar taste. The pressed oil concretes at 17° C.; that extracted by ether or bisulphide of carbon requires for solidification a lower temperature. The expressed oil is slightly fluorescent, less so that extracted by means of bisulphide of carbon. If the oil, either pressed or extracted, is diluted with the bisulphide, and then concentrated sulphuric or nitric acid is added, no peculiar coloration is produced.

From the powdered kernels deprived of oil, water removes the usual constituents, glucose, mucilage and albumin.

Uses—The seeds are said to have been advantageously used as an alternative tonic in scrofula, skin diseases and rheumatism. They should be freed from the testa, powdered, and given in the dose of 6 grains gradually increased. Reduced to a paste and mixed with Simple Ointment, they constitute the Unguentum Gynocardiæ of the Indian Pharmacopœia, which, as well as an expressed oil of the seeds may be employed externally in herpes, tinea, &c.[323]

Substitute—It has been suggested that the seeds of Hydnocarpus Wightiana Bl., a tree of Western India, and of H. venenata Gärtn., native of Ceylon, might be tried where those of Gynocardia are not procurable. The seeds of both species of Hydnocarpus (formerly confounded together as H. inebrians Vahl) afford a fatty oil which the natives use in cutaneous diseases.[324]

---

RADIX SENEGÆ.

Botanical Origin—Polygala Senega L., a perennial plant with slender ascending stems 6 to 12 inches high, and spikes of dull white flowers resembling in form those of the Common Milkwort of Britain. It is found in British America as far north as the river Saskatchewan, and in the United States from New England to Wisconsin, Kentucky, Tennessee, Virginia and the upper parts of North Carolina, as well as in Georgia and Texas, not in the Rocky Mountains.

The plant, which frequents rocky open woods and plains, has become somewhat scarce in the Atlantic states, and as a drug is now chiefly collected in the west, the plant growing profusely in Iowa and Minnesota, west of New York.

History—The employment of this root among the Seneca Indians as a remedy for the bite of the rattlesnake attracted the notice of Tennent, a Scotch physician in Virginia; and from the good effects he witnessed he concluded that it might be administered with advantage in pleurisy and peripneumonia. The result of numerous trials made in the years 1734 and 1735 proved the utility of the drug in these complaints, and Tennent communicated his observations to the celebrated Dr. Mead of London in the form of an epistle, afterwards published together with an engraving of the plant, then called the Seneca Rattlesnake Root.[325] Tennent’s practice was to administer the root in powder or as a strong decoction, or more often infused in wine. The new drug was favourably received in Europe, and its virtues discussed in numerous theses and dissertations, one written in 1749 being by Linnæus.[326]

Description—Senega root is developed at its upper end into a knotty crown, in old roots as much as an inch in diameter, from which spring the numerous wiry aerial stems, beset at the base with scaly rudimentary leaves often of a purplish hue. Below the crown is a simple tap-root ²/₁₀ to ³/₁₀ of an inch thick, of contorted or somewhat spiral form, which usually soon divides into 2 or 3 spreading branches and smaller filiform rootlets.

The bark is light yellowish-grey, translucent, horny, shrivelled, knotted and partially annulated. Very frequently a keel-shaped ridge occurs, running like a shrunken sinew through the principal root; it has no connexion with the wood, but originates in a one-sided development of the liber-tissue. The bark encloses a pure, white woody column about as thick as itself. After the root has been macerated in water the bark is easily peeled off, and the peculiar structure of the wood can then be studied. The latter immediately below the crown is a cylindrical cord, cleft however by numerous, fine, longitudinal fissures. Lower down these fissures increase in an irregular manner, causing a very abnormal development of the wood. Transverse sections of a root therefore differ greatly, the circular wood portion being either penetrated by clefts or wide notches, or one-half or even more is altogether wanting, the space where wood should exist being in each case filled up by uniform parenchymatous tissue.

Senega root has a short brittle fracture, a peculiar rancid odour, and a very acrid and sourish taste. When handled it disperses in irritating dust.

Microscopic Structure—The woody part is built up of dotted vessels surrounded by short porous ligneous cells; the medullary rays consist of one or two rows of the usual small cells. There is no pith in the centre of the root. The clefts and notches are filled up with an uniform tissue passing into the primary cortical tissue without a distinct liber; the large cells of this tissue are spirally striated. In the keel-shaped rider the proper liber rays may be distinguished from the medullary rays. The former are made up of a soft tissue, hence the cortical part of the root breaks short together with the wood.

Neither starch granules nor crystals of oxalate of calcium are present in this root; the chief contents of its tissue are albuminoid granules and drops of fatty oil.

Chemical Composition—The substance to which the drug owes its irritating taste was distinguished by the name of Senegin by Gehlen as early as 1804, and is probably the same as the Polygalic Acid of Quevenne (1836) and of Procter (1859). Christophsohn (1874) extracted it by means of boiling water, evaporated the solution and exhausted the residue with boiling alcohol (0·853 sp. gr.). The liquid after a day or two, deposits the crude senegin, which is to be washed with alcohol (0·813 sp. gr.), and again dissolved in water, from which it is precipitated by a large excess of hydrate of baryum. The barytic compound, dissolved in water, is decomposed by carbonic acid, by which carbonate of baryum is separated, senegin remaining in solution. It is lastly to be precipitated by alcohol. It is amorphous, insoluble in ether and in cold water; it forms with boiling water a frothing solution. Like saponin, to which it is very closely allied, it excites violent sneezing.

Dilute inorganic acids added to a warm solution of senegin throw down a flocculent jelly of Sapogenin, the liquid retaining in solution uncrystallizable sugar. Alkalis give rise to the same decomposition; but it is difficult to split up the senegin completely, and hence the formulas given for this process are doubtful. Even the formula of senegin itself is not definitely settled. According to Christophsohn, the root yields about 2 per cent. of this substance; according to earlier authorities, who doubtless had it less pure, a much larger proportion. From Schneider’s investigations (1875) it would appear that the rootlets are richest in senegin.

Senega root contains a little volatile oil, traces of resin, also gum, salts of malic acid, yellow colouring matter, and sugar (7 per cent. according to Rebling, 1855). The Virginic Acid said by Quevenne to be contained in it, and the bitter substance Isolusin mentioned by Peschier, are doubtful bodies.

Uses—Senega is prescribed as a stimulating expectorant and diuretic, useful in pneumonia, asthma and rheumatism. It is much esteemed in America.

Adulteration—The drug is not liable to be wilfully falsified, but through careless collecting there is occasionally a slight admixture of other roots. One of these is American Ginseng (Panax quinquefolium L.) a spindle-shaped root which may be found here and there both in senega and serpentaria. The rhizome of Cypripedium pubescens Willd. has also been noticed; it cannot be confounded with that of Polygala Senega. The same may be said with regard to the rhizome of Cynanchum Vincetoxicum R. Brown (Asclepias L., Vincetoxicum officinale Mönch).

RADIX KRAMERIÆ.

Botanical Origin—Krameriæ triandra Ruiz et Pav., a small woody shrub with an upright stem scarcely a foot high and thick decumbent branches 2 to 3 feet long.[328] It delights in the barren sandy declivities of the Bolivian and Peruvian Cordilleras at 3000 to 8000 feet above the sea-level, often occurring in great abundance and adorning the ground with its red star-like flowers and silver-grey foliage.

The root is gathered chiefly to the north, north-east, and east of Lima, as at Caxatambo, Huanuco, Tarma, Jauja, Huarochiri and Canta; occasionally on the high lands about lake Titicaca. It appears likewise to be collected in the northern part of Peru, since the drug is now frequently shipped from Payta.

History—Hipolito Ruiz,[329] the Spanish botanist, observed in 1784 that the women of Huanuco and Lima were in the habit of using for the preservation of their teeth a root which he recognized as that of Krameria triandra, a plant discovered by himself in 1779. On his return to Europe he obtained admission for this root into Spain in 1796, whence it was gradually introduced into other countries of Europe.

The first supplies which reached England formed part of the cargo of a Spanish prize, and were sold in the London drug sales at the commencement of the present century. Some fell into the hands of Dr. Reece who recommended it to the profession.[330]

About 20 years ago there appeared in the European market some other kinds of rhatany previously unknown: of these the more important are noticed at pp. 81, 82.

Description—The root which attains a considerable size in proportion to the aerial part of the shrub, consists of a short thick crown, sometimes much knotted and as large as a man’s fist. This ramifies beneath the soil even more than above, throwing out an abundance of branching, woody roots (frequently horizontal) some feet long and ¼ to ½ an inch thick. These long roots used formerly to be found in commerce; but of late years rhatany has consisted in large proportion of the more woody central part of the root with short stumpy branches, which from their broken and bruised appearance have evidently been extracted with difficulty from a hard soil.

The bark which is scaly and rugged, and ⅒ to ¹/₂₀ of an inch in thickness, is of a dark reddish-brown. It consists of a loose cracked cork-layer, mostly smooth in the smaller roots, covering a bright brown-red inner bark, which adheres though not very firmly to a brownish yellow wood. The bark is rather tough, breaking with a fibrous fracture. The wood is dense, without pith, but marked with thin vessels arranged in concentric rings, and with still thinner, dark medullary rays. The taste of the bark is purely astringent; the wood is almost tasteless; neither possesses any distinctive odour.

Kr. cistoidea Hook, a plant scarcely to be distinguished from Kr. triandra, affords in Chili a rhatany very much like that of Peru. Its root was contributed to the Paris Exhibition of 1867.

Microscopic Structure—The chief portion of the bark is formed of liber, which in transverse section exhibits numerous bundles of yellow fibres separated by parenchymatous tissue and traversed by narrow brown medullary rays. The small layer of the primary bark is made up of large cells, the surface of the root of large suberous cells imbued with red matter. The latter also occurs in the inner cortical tissue, and ought to be removed by means of ammonia in order to get a clear idea of the structure. Many of the parenchymatous cells are loaded with starch granules; oxalate of calcium occurs in the neighbourhood of the liber bundles. The woody portion exhibits no structure of particular interest.

Chemical Composition—Wittstein (1854) found in the bark of rhatany (the only part of the drug having active properties) about 20 per cent. of a form of tannin called Ratanhia-tannic Acid, closely related to catechu-tannic acid. It is an amorphous powder, the solution of which is not affected by emetic tartar, but yields with ferric chloride a dark greenish precipitate. By distillation Eissfeldt (1854) obtained pyrocatechin as a product of the decomposition of ratanhia-tannic acid. The latter is also decomposed by dilute acids which convert it into crystallizable sugar and Ratanhia-red, a substance nearly insoluble in water, also occurring in abundance ready formed in the bark.

Grabowski (1867) showed that by fusing ratanhia-red with caustic potash, protocatechuic acid and phloroglucin[331] are obtained. Ratanhia-red has the composition C₂₆H₂₂O₁₁, the same, according to Grabowski, as an analogous product of the decomposition of the peculiar tannic acid occurring (as shown by Rochleder in 1866) in the horse-chestnut. The same red substance may also be obtained, as stated by Rembold (1868), from the tannic acid of the root of tormentil (Potentilla Tormentilla L.).

As to rhatany root, Wittstein also found it to contain wax, gum and uncrystallizable sugar (even in the wood! according to Cotton[332]). Cotton further pointed out the presence in very minute quantity of an odorous, volatile, solid body, obtainable by means of ether or bisulphide of carbon; it occurs in a somewhat more considerable amount in the other sorts of rhatany. The root contains no gallic acid.

A dry extract of rhatany resembling kino used formerly to be imported from South America, but how and where manufactured we know not. It is however of some interest as containing a crystalline body which Wittstein who discovered it (1854) regards as Tyrosin, C₉H₁₁O₃, previously supposed to be exclusively of animal origin.[333] Städeler and Ruge (1862) assigned to it a slightly different composition, C₁₀H₁₃NO₃, and gave it the name of Ratanhin. It dissolves in hot water which is acidulated by a little nitric acid; the solution on boiling turns red, blue, and lastly green, and becomes at the same time fluorescent. Kreitmair (1875) extracted 0·7 per cent, of ratanhin from an old specimen of commercial extract of rhatany; but he did not succeed in obtaining it from other specimens. He also showed that ratanhin is not a constituent of the roots of Krameria. The same substance has been abundantly found by Gintl (1868) in the natural exudation called Resina d’Angelim pedra[334] which is met with in the alburnum of Ferreirea spectabilis Allem., a large Brazilian tree of the order Leguminosæ (tribe Sophoreæ). Peckolt, who first extracted it, named it Angelin; it forms colourless, neutral crystals yielding compounds both with alkalis and acids, which have been investigated by Gintl in 1869 and 1870.

Uses—Rhatany is a valuable astringent, but is not much employed in Great Britain.

Other sorts of Rhatany—Of the 20 to 25 other species of Krameria, all of them belonging to America, several have astringent roots which have been collected and used in the place of the rhatany of Peru. The most important of these drugs is that known as—

Para Rhatany,—so called from having been shipped from Pará in Brazil. Berg who described it in 1865 termed it Brazilian Rhatany, Cotton in 1868, Ratanhia des Antilles. It is a drug nearly resembling the following, but of a darker and less purple hue; it is also in longer sticks which are remarkably flexible, and covered with a thick bark having numerous transverse cracks.[335] It is apparently derived from the Krameria argentea of Martius,[336] the root of which is collected in the dry districts of the provinces of Bahia and Minas Geraes, that plant growing throughout north-eastern Brazil. It is also called Rhatany from Ceará.

Savanilla or New Granada Rhatany. The plant yielding it is Krameria tomentosa St. Hil. (Kr. Ixina var. β granatensis Triana, Kr. grandifolia Berg), a shrub 4 to 6 feet high covering large arid tracts in the valley of Jiron between Pamplona and the Magdalena in New Granada, in which locality the collection of the root was observed by Weir in 1864.[337] According to Triana it also grows at Socorro, south of Jiron. The same plant is found near Santa Marta and Rio Hacha in north-eastern New Granada, in British Guiana, and in the Brazilian provinces of Pernambuco and Goyaz.

The stem or root-crown of Savanilla rhatany is never so knotty and irregular as that of the Peruvian drug, nor are the roots so long or so thick. Separate pieces of root of sinuous form, 4 to 6 inches long and ²/₁₀ to ³/₁₀ of an inch thick are most frequent. The drug is moreover well distinguished by its dull purplish brown colour, its thick smooth bark marked with longitudinal furrows, and here and there with deep transverse cracks, and by the bark not easily splitting off as it does in common rhatany.

The anatomical difference depends chiefly upon the more abundant development of the bark which in thickness is ⅓ to ¼ the diameter of the wood. In Peruvian rhatany the cortical layer attains only ⅙ to ⅛ of the diameter of the woody column. The greater firmness of the suberous coat in Savanilla rhatany is due to its cells being densely filled with colouring matter.

Savanilla rhatany differs from the Peruvian root in its tannic matter. This becomes evident by shaking the powdered root (or bark) with water and iron reduced by hydrogen. The liquid filtered from the Savanilla sort and diluted with distilled water exhibits an intense violet colour, that from Peruvian rhatany a dingy brown; the latter turns light red by alkalis. Thin sections of the Peruvian root assume a greyish hue when moistened with a ferrous salt; Savanilla root by a similar treatment displays the above violet colour. The Savanilla root is richer in soluble matter and from the greater development of its bark may deserve to be preferred for medicinal use.

In the English market, Savanilla root is of less frequent occurrence than that of Pará.

A kind of rhatany attributed to Krameria secundiflora DC., a herbaceous plant of Mexico, Texas and Arkansas, was furnished to Berg in 1854, but has not been in commerce. Its anatomical structure has been described by Berg.[338]

---

BALSAMUM DIPTEROCARPI.

Balsamun Gurjunæ; Gurjun Balsam, Wood Oil.

Botanical Origin—This drug is yielded by several trees of the genus Dipterocarpus, namely—

D. turbinatus Gärtn. f. (D. lævis Ham., D. indicus Bedd), a native of Eastern Bengal, Chittagong and Pegu to Singapore, and French Cochin China.

D. incanus Roxb., a tree of Chittagong and Pegu.

D. alatus Roxb., growing in Chittagong, Burma, Tenasserim, the Andaman Islands, Siam, and French Cochin China.

D. zeylanicus Thw. and D. hispidus Thw., indigenous to Ceylon.

D. crispalatus ... abounding, together with D. turbinatus and D. alatus, in French Cochin China.

D. trinervis Bl., a native of Java and the Philippines, and D. gracilis Bl., D. littoralis Bl., D. retusus Bl. (D. Spanoghei Bl.), trees of Java supply a similar useful product which as yet appears to be of less commercial importance.[360]

The Gurjun trees are said by Hooker[361] to be among the most magnificent of the forests of Chittagong. They are conspicuous for their gigantic size, and for the straightness and graceful form of their tall unbranched trunk, and small symmetrical crown of broad glossy leaves. Many individuals are upwards of 200 feet high and 15 feet in girth.

History—Gurjun balsam was enumerated as one of the productions of Ava by Francklin[362] in 1811, and in 1813 it was briefly noticed by Ainslie.[363] Its botanical origin was first made known by Roxburgh, who also described the method by which it is extracted.

The medicinal properties of Gurjun balsam were pointed out by O’Shaughnessy[364] as entirely analogous to those of copaiba; and his observations were confirmed by many practitioners in India. This has obtained for the drug a place in the Pharmacopœia of India (1868).

Extraction—A recent account of the production of this drug is found in the Reports of the Jury of the Madras Exhibition of 1855. It is there stated that Wood Oil, as the balsam is commonly called, is obtained for the most part from the coast of Burma and the Straits, and is procured by tapping the trees about the end of the dry season. Several deep incisions are made with an axe into the trunk of the tree and a good-sized cavity scooped out. In this, fire is placed, and kept burning until the wood is somewhat scorched, when the balsam begins to exude, and is then led away into a vessel of bamboo. It is afterwards allowed to settle, when a clear liquid separates from a thick portion called the “guad.” The oil is extracted year after year, and sometimes there are two or three holes in the same tree. It is produced in extraordinary abundance; from 30 to 40 gallons according to Roxburgh may sometimes be obtained from a single tree in the course of a season, during which it is necessary to remove from time to time the old charred surface of the wood and burn afresh.

If a growing tree is felled and cut into piece, the oleo-resin exudes and concretes on the wood, very much, it is said, resembling camphor (?) and having an aromatic smell.

Description—As Gurjun balsam is the produce of different trees as well as of different countries, it is not surprising to find that it varies considerably in its properties.

The following observations refer to a balsam of which 400 lb. were recently imported from Moulmein for a London drug firm. It is a thick and viscid fluid, exhibiting a remarkable fluorescence, so that when seen by reflected light it appears opaque and of dingy greenish grey; yet when placed between the observer and strong daylight it is seen to be perfectly transparent and of a dark reddish-brown.[365] It has a weak aromatic copaiba-like odour and a bitterish aromatic taste without the persistent acridity of copaiba. Its sp. gr. at 16·9° C. is 0·964.

With the following liquids Gurjun affords perfectly clear solutions which are more or less fluorescent, namely pure benzol (from benzoate of calcium), cumol, chloroform, sulphide of carbon, essential oils. On the other hand, it is not entirely soluble in methylic, ethylic, or amylic alcohol; in ether, acetic ether, glacial acetic acid, acetone, phenol (carbolic acid), or in caustic potash dissolved in absolute alcohol. Many samples of commercial benzin also are not capable of dissolving the oleo-resin perfectly, but we have not ascertained on what constituent of such benzin this depends. We have further noticed that that portion of petroleum which is known as Petroleum Ether, containing the most volatile hydrocarbons, does not wholly dissolve the oleo-resin. One hundred parts of the balsam warmed and shaken with 1000 parts of absolute alcohol yielded on cooling a precipitate of resin amounting when dried to 18·5 parts. All concentrated solutions of the balsam are precipitated by amylic alcohol.

If the balsam is kept for a long time in a stoppered vessel at 100° C. it simply becomes a little turbid; but about 130° C. it is transformed into a jelly, and on cooling does not resume its former fluidity. Balsam of copaiba heated in a closed glass tube to 220° C. does not at all lose its fluidity, whereas Gurjun balsam becomes an almost solid mass.

Chemical Composition—Of the balsam 6·99 grammes dissolved in benzol and kept in a water bath until the residue ceased to lose weight, yielded 3·80 grammes of a dry, transparent, semi-fluid resin, corresponding to 54·44 per cent., and 45·56 of volatile matters expelled by evaporation. But another sample afforded us much less residue. By submitting larger quantities of the above balsam to the usual process of distillation with water in a large copper still, 37 per cent. of volatile oil were easily obtained. The water passing over at the same time did not redden litmus paper. A dark, viscid, liquid resin remained in the still.

The essential oil is of a pale straw-colour and less odorous than most other volatile oils. Treated with chloride of calcium and again distilled, it begins to boil at 210° C. and passes over at 255°-260° C., acquiring a somewhat empyreumatic smell and light yellowish tint. The purified oil has a sp. gr. of 0·915;[366] it is but sparingly soluble in absolute alcohol or glacial acetic acid, but mixes readily with amylic alcohol.

According to Werner (1862) this oil has the composition C₂₀H₃₂ like that of copaiba. He says it deviates the ray of polarized light to the left, but that prepared by one of us deviated strongly to the right, the residual resin dissolved in benzol being wholly inactive. The oil does not form a crystalline compound with dry hydrochloric acid, which colours it of a beautiful blue.[367] De Vry[368] states that the essential oil after this treatment deviates the ray to the right.

The resin contains, like that of copaiba, a small proportion of a crystallizable acid which may be removed by warming it with ammonia in weak alcohol. That part of the resin which is insoluble even in absolute alcohol,[369] we found to be uncrystallizable. The Gurgunic Acid, as the crystallized resinous acid is called by Werner,[370] but which it is more correct to write Gurjunic, may consequently be prepared by extracting the resin with alcohol (·838) and mixing the solution with ammonia. From the ammoniacal solution gurjunic acid is precipitated on addition of a mineral acid, and if it is again dissolved in ether and alcohol it may be procured in the form of small crystalline crusts. From the specimen under examination we were not successful in obtaining indubitable crystals.

Gurjunic acid, C₄₄H₆₈O₈ according to Werner, melts at 220° C., and concretes again at 180° C.; it begins to boil at 260° C., yet at the same time decomposition takes place. By assigning to this acid the formula C₄₄H₆₄O₅ + 3H₂O, which agrees well with Werner’s analytical results, we may regard it as a hydrate of abietinic acid, the chemical behaviour of which is perfectly analogous. Gurjunic acid is soluble in alcohol 0·838, but not in weak alcohol; it is dissolved also by ether, benzol, or sulphide of carbon (Werner).

In copaiba from Maracaibo, Strauss (1865) discovered Metacopaivic Acid which is probably identical with gurjunic; the former, however, fuses at 206° C.

The amorphous resin forming the chief bulk of the residue of the distillation of the balsam, has not yet been submitted to exact analysis. We find that after complete desiccation it is not soluble in absolute alcohol. A crystallized constituent of Gurjun, which we obtained from a balsam of unknown origin, has been shown[371] to answer to the formula C₂₈H₄₆O₂. Its crystals, belonging to the asymmetric system, melt at 126°-130°C.; they are entirely devoid of acid character. A comparative examination of the product of each of the above named species of Dipterocarpus would be highly desirable.

Commerce—Gurjun balsam is exported from Singapore, Moulmein, Akyab and the Malayan Peninsula, and is a common article of trade in Siam. It is likewise produced in Canara in Southern India. It is occasionally shipped to Europe. More than 2000 lb. were offered for sale in London under the name of East India Balsam Capivi, 4th October 1855; and in October 1858, a no less quantity than 45 casks appeared in the catalogue of a London drug-broker. It is now not unfrequent in the London drug sales.

Uses—In medicine it has hitherto been employed only as a substitute for copaiba, and chiefly in the hospitals of India.

In the East its great use is as a natural varnish, either alone or combined with pigments; and also as a substitute for tar as an application to the seams of boats, and for preserving timber from the attacks of the white ant. To the first application it is often made better appropriated[372] by boiling it, so that the essential oil is evaporated.

Wood Oil of China—The oleo-resin of Dipterocarpus must not be confounded with the so-called Wood Oil of China, which is of a totally different nature. The latter is a fatty oil expressed from the seeds of Aleurites cordata Müll. Arg. (Dryandra cordata Thunb. Elaeococca Vernicia Sprgl. Prodromus xv. part 2, p. 724), the well-known Tung tree of the Chinese. It is a large tree of the order Euphorbiaceæ, found in China and Japan. The oil is an article of enormous consumption among the Chinese, who use it in the caulking and painting of junks and boats, for preserving woodwork, varnishing furniture, and also in medicine. In the commercial reports of H.M. Consuls in China (No. 5, 1875, p. 3, 26) we find that this oil is largely exported from Hankow: 199·654 peculs in 1874, and forms an article of import at Ningpo: 15·123 peculs in 1874 (pecul = 133·33 lb. avoirdupois). It is, however, not shipped to foreign countries. The oil of the Tung tree is also extremely remarkable on account of its chemical properties as shown by Cloëz (1875-1877).

---

RADIX ALTHÆÆ

Botanical Origin—Althæa officinalis L., the marshmallow, grows in moist places throughout Europe, Asia Minor, and the temperate parts of Western and Northern Asia, but is by no means universally distributed. It prefers saline localities such as in Spain the salt marshes of Saragossa, the low-lying southern coasts of France near Montpellier, Southern Russia, and the neighbourhood of salt-springs in Central Europe. In southern Siberia Althæa has been met with by Semenoff (1857) ascending as high as 3,000 feet in the Alatau mountains, south of the Balkash Lake.

In Britain it occurs in the low grounds bordering the Thames below London, and here and there in many other spots in the south of England and of Ireland.

The cultivated marshmallow thrives as far north as Throndhjem in Norway, and has been naturalized in North America (salt marshes of New England and New York) and Australia. It is largely cultivated in Bavaria and Württemberg.

History—Marshmallow had many uses in ancient medicine, and is described by Dioscorides as Άλθαία, a name derived from the Greek verb ἀλθειν, to heal.

The diffusion of the plant in Europe during the middle ages was promoted by Charlemagne who enjoined[373] its culture (a.d. 812) under the name of “Mismalvas, id est alteas quod dicitur ibischa.”

Description—The plant has a perennial root attaining about a foot in length and an inch in diameter. For medicinal use the biennial roots of the cultivated plant are chiefly employed. When fresh they are externally yellowish and wrinkled, white within and of tender fleshy texture. Previous to drying, the thin outer and a portion of the middle bark are scraped off, and the small root filaments are removed. The drug thus prepared and dried consists of simple whitish sticks 6 to 8 inches long, of the thickness of the little finger to that of a quill, deeply furrowed longitudinally and marked with brownish scars. Its central portion, which is pure white, breaks with a short fracture, but the bark is tough and fibrous. The dried root is rather flexible and easily cut. Its transverse section shows the central woody column of undulating outline separated from the thick bark by a fine dark outline shaded off outwards.

The root has a peculiar though very faint odour, and is of rather mawkish and insipid taste, and very slimy when chewed.

Microscopic Structure—The greater part of the bark consists of liber, abounding in long soft fibres, to which the toughness of the cortical tissue is due. They are branched and form bundles, each containing from 3 to 30 fibres separated by parenchymatous tissue. Of the cortical parenchyme many cells are loaded with starch granules, others contain stellate groups of oxalate of calcium, and a considerable number of somewhat larger cells are filled with mucilage. The last named on addition of alcohol is seen to consist of different layers.

The woody part is made up of pitted or scalariform vessels, accompanied by a few ligneous cells and separated by a parenchymatous tissue, agreeing with that of the bark. On addition of an alkali, sections of the root assume a bright yellow hue.

Chemical Composition—The mucilage in the dry root amounts to about 25 per cent. and the starch to as much more. The former appears from the not very accordant analysis of Schmidt and of Mulder to agree with the formula C₁₂H₂₀O₁₀, thus differing from the mucilage of gum arabic by one molecule less of water. It likewise differs in being precipitable by neutral acetate of lead. At the same time it does not show the behaviour of cellulose, as it does not turn blue by iodine when moistened with sulphuric acid, and it is not soluble in ammoniacal solution of oxide of copper.

The root also contains pectin and sugar (cane-sugar according to Wittstock), and a trace of fatty oil. Tannin is found in very small quantity in the outer bark alone.

In 1826 Bacon, a pharmacien of Caen, obtained from althæa root crystals of a substance at first regarded as peculiar, but subsequently identified with Asparagin, C₄H₈N₂O₃, H₂O. It had been previously prepared (1805) by Vauquelin and Robiquet from Asparagus, and is now known to be a widely diffused constituent of plants.[374] Marshmallow root does not yield more than 0·8 to 2·0 per cent. Asparagin crystallizes in large prisms or octohedra of the rhombic system; it is nearly tasteless, and appears destitute of physiological action. Its relation to succinic acid may be thus represented:—

Succinic acid: C₂H₄		COOH
		COOH;
Asparagin: C₂H₃(NH₂)		CONH₂
		COOH.

Asparagin is quite permanent whether in the solid state or dissolved, but it is easily decomposed if the solution contains the albuminoid constituents of the root, which act as a ferment. Leguminous seeds, yeast or decayed cheese induce the same change, the final product of which is succinate of ammonium, the asparagin taking the elements of water and hydrogen set free by the fermentation, thus—

C₄H₈N₂O₃	+ H₂O + 2H =	2NH₄, C₄H₄O₄
Asparagin.		Succinate of Ammonium.

Under the influence of acids or bases, or even by the prolonged boiling of its aqueous solution, asparagin is converted into Aspartate of Ammonium, C₄H₆(NH₄)NO₄, of which the hydrated asparagin contains the elements.

These transformations, especially the former, are undergone by the asparagin in the root, if the latter has been imperfectly dried, or has been kept long, or not very dry. Under such conditions, the asparagin gradually disappears, and the root then yields a brownish decoction, sometimes having a disagreeable odour of butyric acid. There is no doubt that a protein-substance here acts as a ferment. The sections of the root when touched with ammonia or caustic lye should display a bright yellow, not a dingy brown, colour.

The peeled root dried at 100° C. and incinerated afforded us 4·88 of ash, rich in phosphates.

Uses—Althæa is taken as a demulcent; it is sometimes also applied as an emollient poultice. It is far more largely used on the continent than in England.

FRUCTUS HIBISCI ESCULENTI.

Botanical Origin—Hibiscus esculentus L. (Abelmoschus esculentus Guill. et Perr.) an herbaceous annual plant 2 to 3 or even 10 feet high, indigenous to the Old World.[376] It has been found growing abundantly wild on the White Nile by Schweinfurth, and also in 1861 by Col. Grant in Unyoro, 2° N. lat., near the lake Victoria Nyanza, where it is known to the natives as Bameea.

The plant is now largely cultivated in several varieties in all tropical countries.

History—The Spanish Moors appear to have been well acquainted with Hibiscus esculentus, which was known to them by the same name that it has in Persian at the present day—Bámiyah. Abul Abbas el-Nebáti, a native of Seville learned in plants, who visited Egypt in a.d. 1216, describes[377] in unmistakeable terms the form of the plant, its seeds and fruit, which last he remarks is eaten when young and tender with meat by the Egyptians. The plant was figured among Egyptian plants in 1592 by Prosper Alpinus,[378] who mentions its uses as an external emollient.

The powdered fruits as imported from Arabia Felix were known for some time (about the year 1848) in Europe as Nafé of the Arabs. They are noticed in the present work from the circumstance that they have a place in the Pharmacopœia of India.

Description—The fruit is a thin capsule, 4 to 6 or more inches long and about an inch in diameter, oblong, pointed, with 5 to 7 ridges corresponding to the valves and cells, each of which latter contains a single row of round seeds. It is covered with rough hairs and is green or purplish when fresh; it has a slightly sweet mucilaginous taste and a weak herbaceous odour. Like many other plants of the order, Hibiscus esculentus abounds in all its parts with insipid mucilage.

Microscopic Structure—A characteristic part for microscopic examination are the hairs of the fruit. They exhibit at the base one large cell, but their elongated and often slightly curved end is built up at a considerable number of small cells, without any solid contents. The middle and outer zone of the pericarp shows enormous holes filled up with colourless mucilage. In polarized light it is easily seen to be composed of successive layers.

Chemical Composition—It is probable that the fruits contain the same mucilage as Althæa, but we have had no opportunity of investigating the fact. Landrin[379] says it turns violet with iodine and yields no mucic acid when treated with nitric acid. Popp, who examined the green fruits in Egypt, states[380] that they abound in pectin, starch and mucilage. He found that when dried they afforded 2 to 2·4 per cent. of nitrogen, and an ash rich in salts of lime, potash and magnesia. The ripe seeds gave 2·4-2·5 per cent. of nitrogen; their ash 24 per cent. of phosphoric acid.

Uses—The fresh or dried, unripe fruits are used in tropical countries as a demulcent like marshmallow, or as an emollient poultice, for which latter purpose the leaves may also be employed. They are more important from an economic point of view, being much employed for thickening soups or eaten boiled as a vegetable. The root has been recommended as a substitute for that of Althæa.[381] The stems of the plant yield a good fibre.

---

OLEUM CACAO.

Botanical Origin—Cacao seeds (from which Cacao Butter is extracted) are furnished by Theobroma Cacao L., and apparently also by Th. leiocarpum Bernoulli, Th. pentagonum Bern., and Th. Salzmannianum Bern.[382] These trees are found in the northern parts of South America and in Central America as far as Mexico, both in a wild state and in cultivation.

History—Cacao seeds were first noticed by Capitan Gonzalo Fernandez de Oviedo y Valdés (1514-1523), who stated[383] that they had been met with by Columbus, being used among the inhabitants of Yucatan instead of money. They were likewise pointed out to Charles V., by Cortes in one of his letters to the Emperor, dated Temixtitan, Sept. 3rd 1526.[384] The tree as well as the seeds and their uses, were at length described by Benzoni,[385] who lived in the new world from 1541 to 1555. Clusius figured the seeds in his “Notæ in Garciæ Aromatum historiam,” Antwerpiæ, 1582.

Cacao butter was prepared and described by Homberg[386] as early as 1695, at which time it appears to have had no particular application, but in 1719 it was recommended by D. de Quelus[387] both for ointments and as an aliment.

An essay published at Tübingen in 1735[388] called attention to it as “novum atque commendatissimum medicamentum.” A little later it is mentioned by Geoffroy[389] who says that it is obtained either by boiling or by expressing the seeds, that it is recommended as the basis of cosmetic pomades and as an application to chapped lips and nipples, and to hæmorrhoids.

Production—Cacao butter is procured for use in pharmacy from the manufacturers of chocolate, who obtain it by pressing the warmed seeds. These in the shelled state yield from 45 to 50 per cent. of oil. The natural seeds consist of about 12 per cent. of shell (testa) and 88 of kernels (cotyledons).

Description—At ordinary temperatures cacao butter is a light yellowish, opaque, dry substance, usually supplied in the form of oblong tablets having somewhat the aspect of white Windsor soap. Though unctuous to touch, it is brittle enough to break into fragments when struck, exhibiting a dull waxy fracture. It has a pleasant odour of chocolate, and melts in the mouth with a bland agreeable taste. Its sp. gr. is 0·961; its fusing point 20° to 30° C.

Examined under the microscope by polarized light, cacao butter is seen to consist of minute crystals. It is dissolved by 20 parts of boiling absolute alcohol, but on cooling separates to such an extent that the liquid retains not more than 1 per cent. in solution. The fat separated after refrigeration is found to have lost most of its chocolate flavour. Litmus is not altered by the hot alcoholic solution.

Cacao butter in small fragments is slowly dissolved by double its weight of benzol in the cold (10° C.), but by keeping partially separates in crystalline warts.

Chemical Composition—The fat under notice is composed, in common with others, of several bodies which by saponification furnish glycerin and fatty acids. Among the latter occurs also oleic acid,[390] contained in that part of the cacao butter which remains dissolved in cold alcohol as above stated. In fact by evaporating that solution a soft fat is obtained. But the chief constituents of cacao butter appear to be stearin, palmitin, and another compound of glycerin containing probably an acid of the same series richer in carbon,—perhaps arachic acid, C₂₀H₄₀O₂, or “theobromic acid” C₆₄H₁₂₈O₂, as suggested in 1877 by Kingzett.

Uses—Cacao butter, which is remarkable for having but little tendency to rancidity, has long been used in continental pharmacy; it was introduced into England a few years ago as a convenient basis for suppositories and pessaries.

Adulteration—The description given of the drug sufficiently indicates the means of ascertaining its purity.

---

SEMEN LINI.

Botanical Origin—Linum usitatissimum L., Common Flax, is an annual plant, native of the Old World, where it has been cultivated from the remotest times. It sows itself as a weed in tilled ground, and is now found in all temperate and tropical regions of the globe. Heer regards it as a variety evolved by cultivation from the perennial L. angustifolium Huds.

History—The history of flax, its textile fibre and seed, is intimately connected with that of human civilisation. The whole process of converting the plant into a fibre fit for weaving into cloth is frequently depicted on the wall-paintings of the Egyptian tombs.[391] The grave-clothes of the old Egyptians were made of flax, and the use of the fibre in Egypt may be traced back, according to Unger,[392] as far as the 23rd century b.c. The old literature of the Hebrews[393] and Greeks contains frequent reference to tissues of flax; and fabrics woven of flax have actually been discovered together with fruits and seeds of the plant in the remains of the ancient pile-dwellings bordering the lakes of Switzerland.[394]

The seed in ancient times played an important part in the alimentation of man. Among the Greeks, Alcman in the 7th century b.c., and the historian Thucydides, and among the Romans Pliny, mention linseed as employed for human food. The roasted seed is still eaten by the Abyssinians.[395]

Theophrastus expressly alludes to the mucilaginous and oily properties of the seed. Pliny and Dioscorides were acquainted with its medical application both external and internal. The latter, as well as Columella, exhaustively describes flax under its agricultural aspect. In an edict of the Emperor Diocletian De pretiis rerum venalium[396] dating a.d. 301, linseed is quoted 150 denarii, sesamé seed 200, hemp seed 80, and poppy seed 150, the modius castrensis, equal to about 880 cubic inches.[397] The propagation of flax in Northern Europe as of so many other useful plants was promoted by Charlemagne.[398] It seems to have reached Sweden and Norway before the 12th century.[399]

Description—The capsule which is globose splits into 5 carpels, each containing two seeds separated by a partition. The seeds are of flattened, elongated ovoid form with an acute edge, and a slightly oblique point blunt at one end. They have a brown, glossy, polished surface which under a lens is seen to be marked with extremely fine pits. The hilum occupies a slight hollow in the edge just below the apex. The testa which is not very hard encloses a thin layer of albumen surrounding a pair of large cotyledons having at their pointed extremity a straight embryo. The seeds of different countries vary from ¼ to ⅙ of an inch in length, those produced in warm regions being larger than those grown in cold. We find that 6 seeds of Sicilian linseed, 13 of Black Sea and 17 of Archangel linseed weigh respectively one grain.

When immersed in water, the seeds become surrounded by a thin, slippery, colourless, mucous envelope, which quickly dissolves as a neutral jelly, while the seed slightly swells and loses its polish. The seed when masticated has a mucilaginous oily taste.

Microscopic Structure—On examining the testa under almond oil or oil of turpentine, the outlines of the epidermal cells are not distinctly visible. But under dilute glycerin or in water the epidermis quickly swells up to 3 or 4 times its original thickness; on warming, the entire epidermis is resolved into mucilage, except a thin skeleton of cell-walls, which withstands even the action of caustic lye. The formation of the mucilage may be conveniently studied by the use of a solution of ferrous sulphate, with which thin sections of the testa should be moistened. Other structural peculiarities may be seen if they are imbued with concentrated sulphuric acid, washed and then moistened with a solution of iodine. The application of polarized light is also useful. By the latter means crystalloid granules of albuminoid matter become visible if the sections are examined under oil. The tissue of the albumen and the cotyledons abounds in drops of fatty oil.

Chemical Composition—The constituent of chief importance is the fixed oil which the seed contains to about ⅓ of its weight. The proportion obtained by pressure on a large scale is 20 to 30 per cent. varying with the quality of the seed. The oil when pressed without heat and when fresh has but little colour, is without unpleasant taste, and does not solidify till cooled to -20° C. The commercial oil however is dark yellow, and has a sharp repulsive taste and odour. On exposure to the air, especially after having been heated with oxide of lead, it quickly dries up to a transparent varnish consisting chiefly of Linoxyn, C₃₂H₅₄O₁₁. The crude oil increases in weight 11 to 12 per cent., although at the same time its glycerin is destroyed by oxidation.

By saponification, linseed oil yields glycerin, and 95 per cent. of fatty acids, consisting chiefly of Linoleic Acid, C₁₆H₂₆O₂, accompanied by some oleic, palmitic, and myristic acid. The action of the air transforms linoleic acid into the resinoid Oxylinoleic Acid, C₁₆H₂₆O₅. Linoleic acid appears to be contained in all drying oils, notably in that of poppy seed. It is not homologous either with ordinary fatty acids or with the oleic acid of oil of almonds, C₁₈H₃₄O₂. The chemistry of the drying oils, especially those of linseed and poppy, has been particularly investigated by Mulder.[400]

The viscid mucilage of linseed cannot be filtered till it has been boiled. It contains in the dry state more than 10 per cent. of mineral substances, when freed from which and dried at 110° C. it corresponds, like althæa-mucilage, to the formula C₁₂H₂₀O₁₀. The seeds by exhaustion with cold or warm water afford of it about 15 per cent. By boiling nitric acid it yields crystals of mucic acid; by dilute mineral acids it is broken up into dextrogyre gum and sugar and cellulose.[401]

Linseed contains about 4 per cent. of nitrogen corresponding to about 25 per cent. of protein-substances. After expression of the oil these substances remain in the cake so completely that the latter contains 5 per cent. of nitrogen, and constitutes a very important article for feeding cattle.

In the ripe state linseed is altogether destitute of starch, though this substance is found in the immature seed in the very cells which subsequently yield the mucilage. The latter may be regarded as in analogous cases to be a product of the transformation of starch.

The amount of water retained by the air-dry seed is about 9 per cent.

The mineral constituents of linseed, chiefly phosphates of potassium, magnesium, and calcium, amount on an average to 3 per cent., and pass into the mucilage. By treating thin slices of the testa and its adhering inner membrane with ferrous sulphate, it is seen that this integument is the seat of a small amount of tannin.

Production and Commerce—Flax is cultivated on the largest scale in Russia, from which country there was imported into the United Kingdom in 1872 linseed to the value of 3 millions sterling. The shipments were made in about equal proportion from the northern and the southern ports of Russia.

The imports from India in the same year amounted in value to £1,144,942, and from Germany and Holland to £144,108. The total import in 1872 was 1,514,947 quarters, value £4,513,842.

The cultivation of flax in Great Britain appears to be declining. The area under this crop in 1870 was 23,957 acres; in 1871, 17,366 acres; in 1872, 15,357 acres; and in 1873, 14,683 acres. The last named area reckoning the yield at 2 to 2½ quarters of seed per acre would represent a production of about 30,000 to 38,000 quarters.

In English price-currents, eight sorts of linseed are enumerated, namely, English, Calcutta, Bombay, Egyptian, Black Sea and Azof, Petersburg, Riga, Archangel. The first three appear to fetch the highest prices.

Uses—In medicine, linseed is chiefly used in the form of poultice which may be made either of the seed simply ground or of the pulverized cake. In either case the powder should not be long stored, as the oil in the comminuted seed is rapidly oxidized and fatty acids produced. An infusion of the seeds called Linseed Tea is a common popular demulcent remedy.

Adulteration—Linseed is very liable to adulteration with other seeds, especially when the commodity is scarce. The admixture in question is due in part to careless harvesting and in part to intentional additions. In 1864 the impure condition of the linseed shipped to the English market had become so detrimental to the trade that the importers and crushers founded an association called The Linseed Association of London, by which they bound themselves to refuse all linseed containing more than 4 per cent. of foreign seeds, and this step very rapidly improved the quality of the article.[402]

As the druggist has to purchase linseed meal, he must of necessity rely to some extent on the character of the oil-presser from whom he derives his supplies. The presence of the seeds of Cruciferæ (as rape and mustard) which is common, may be recognized by the pungent odour of the essential oil which they develope in contact with water. The introduction of cereals would also be easily discovered by iodine, which strikes no blue colour in a decoction of linseed. The microscope will also afford important aid in the examination of linseed cake or meal.

---

LIGNUM GUAIACI.

Botanical Origin—This wood is furnished by two West Indian species of Guaiacum, namely:—

1. G. officinale L., a middle-sized or low evergreen tree, with light blue flowers, parapinnate leaves having ovate, very obtuse leaflets in 2, less often in 3 pairs, and 2-celled fruits. It grows in Cuba, Jamaica (abundantly on the arid plains of the south side of the island), Les Gonaives in the N.W. of Hayti (plentiful), St. Domingo, Martinique, St. Lucia, St. Vincent, Trinidad, and the northern coast of the South American continent. This tree affords the Lignum Vitæ of Jamaica (of which very little is imported), a portion of that shipped from the ports of Hayti, and probably the small quantity exported by the United States of Colombia.

2. G. sanctum L., a tree much resembling the preceding, but distinguishable by its leaves having 3 to 4 pairs of leaflets which are very obliquely obovate or oblong, passing into rhomboid-ovate, and mucronulate; and a 5-celled fruit. It is found in Southern Florida, the Bahama Islands, Key West, Cuba, St. Domingo (including the part called Hayti) and Puerto Rico, and is certainly the source of the small but excellent Lignum Vitæ exported from the Bahamas as well as of some of that shipped from Hayti.

History—There can be no doubt but that the earliest importations of Lignum Vitæ were obtained from St. Domingo, of which island, Oviedo[403] who landed in America in 1514 mentions the tree, under the name of Guayacan, as a native. He points out its fruits as yellow and resembling two joined lupines, which could only be said with reference to G. officinale, and would not apply to the ovoid five-cornered fruits of G. sanctum. Oviedo appears however to have been aware of two species, one of which he found in Española (St. Domingo) as well as in Nagrando (Nicaragua) and the other in the island of St. John (Puerto Rico), whence it was called Lignum sanctum.

The first edition of Oviedo was printed in 1526; but some years before this the wood must have been known in Germany, as is evident by the treatises written in 1517, 1518, and 1519 by Nicolaus Poll,[404] Leonard Schmaus[405] and Ulrich von Hutten.[406] The last which gives a tolerable description of the tree, its wood, bark, and medicinal properties, was translated into English in 1533 by Thomas Paynel, canon of Merton Abbey, and published in London in 1536 under the title—“Of the wood called Guaiacum that healeth the Frenche Pockes and also helpeth the gout in the feete, the stoone, the palsey, lepree, dropsy, fallynge euyll, and other dyseases.” It was several times reprinted.

In the old pharmacy the products of destructive distillation of guaiacum wood were known as Oleum ligni sancti. It must have consisted of the substances which we mention further on in the following article.

Description—The wood (always known in commerce as Lignum Vitæ) as imported consists of pieces of the stem and thick branches, usually stripped of bark, and often weighing a hundredweight each. It is remarkably heavy and compact. Its sp. gr. which exceeds that of most woods is about 1·3.

Lignum Vitæ is mostly imported for turnery,[407] and the chips, raspings and shavings are the only form in which it is commonly seen in pharmacy. A stem 7 to 8 inches in diameter cut transversely exhibits a light-yellowish zone of sapwood about an inch wide, enclosing a sharply defined heartwood of a dark greenish brown. Both display alternate lighter and darker layers, which especially in the sapwood are further distinguished by groups of vessels. In this manner are formed a large number of circles resembling annual rings, the general form of which is evident, though the individual rings are by no means well defined. More than 20 such rings may be counted in the sapwood of a log such as we have mentioned, and more than 30 in the heartwood. The pithless centre is usually out of the axis. The medullary rays are not visible to the naked eye, but may be seen by a lens to be very numerous and equidistant. The pores of the heartwood may be distinguished as containing a brownish resin, while those of the outermost layer of sapwood are empty.

In the thickest pieces sapwood is wanting, and even in stems of about a foot in diameter it is reduced to ⅕ of an inch. It is of looser texture than the heartwood and floats on water, whereas the latter sinks. Both sapwood and heartwood owe their tenacity to an extremely peculiar zigzag arrangement[408] of the woody bundles. The sapwood is tasteless. The heartwood has a faintly aromatic and slightly irritating taste, and when heated or rubbed emits a weak agreeable odour.

The bark which was formerly officinal but is now almost obsolete, is very rich in oxalate of calcium and affords upon incineration not less than 23 per cent. of ash. It contains a resin distinct from that of the wood, and also a bitter acrid principle.[409]

The Lignum Vitæ of Jamaica (G. officinale) and that of the Bahamas (G. sanctum), of which authentic specimens have been kindly placed at our disposal by Mr. G. Shadbolt, display the same appearance as well as microscopic structure.[410]

Microscopic Structure—The wood consists for the most part of pointed, not very long, ligneous cells (libriform), traversed by one-celled rows of medullary rays. There are also thin layers of parenchymatous tissue, to which the zones apparent in a transverse section of the drug are due. The pitted vessels are comparatively large but not very numerous. The structure of the sapwood is the same as that of the heartwood, but in the latter the ligneous cells are filled with resin. The parenchymatous cells contain crystals of oxalate of calcium.

Chemical Composition—The only constituent of any interest is the resin which the heartwood contains to the extent of about a fourth of its weight. The sapwood afforded us 0·91 and the heartwood 0·60 per cent. of ash.

Commerce—Lignum Vitæ varies much in estimation, according to size, soundness, and the cylindrical form of the logs. The best is exported from the city of Santo Domingo, whither it is brought from the interior of the island. The quantity shipped from this port during 1871 was 1494 tons;[411] 220 tons were exported in 1877 from Puerto Plata on the northern coast of the island. The wood obtained from the Haytian ports (of the western part of the same island) is much less esteemed in the London market.

Some small wood of good quality comes from the Bahamas, and an ordinary quality, also small, from Jamaica. From the latter island, the quantity exported in 1871 was only 14 tons;[412] from the Bahamas in the same year 199 tons.[413] Lignum Vitæ was shipped from Santa Marta in 1872 to the extent of 115 tons.[414]

Hamburg is also an important place for the wood under notice; in 1877 there were imported 22,404 centners from S. Domingo and 3551 centners from Venezuela.

Uses—Guaiacum wood is only retained in the pharmacopœia as an ingredient of the Compound Decoction of Sarsaparilla. It is probably inert, at least in the manner in which it is now administered.[415]

Adulteration—In purchasing guaiacum chips it is necessary to observe that the non-resinous sapwood is absent, and still more that there is no admixture of any other wood. A spurious form of the drug seems to be by no means rare in the United States.[416]

RESINA GUAIACI.

Guaiacum Resin; F. Résine de Gaïac; G. Guaiakharz.

Botanical Origin—Guaiacum officinale L., see preceding article.

History—Hutten[417] in 1510 stated that guaiacum wood when set on fire exudes a blackish resin which quickly hardens, but of which he knew no use. The resin was in fact introduced into medicine much later than the wood. The first edition of the London Pharmacopœia in which we find the former named is that of 1677.

Production[418]—In the island of St. Domingo, whence the supplies of guaiacum resin are chiefly derived, the latter is collected from the stems of the trees, in part as a natural exudation, and in part as the result of incisions made in the bark. In some districts as in the island of Gonave near Port-au-Prince, another method of obtaining it is adopted. A log of the wood is supported in a horizontal position above the ground by two upright bars. Each end of the log is then set on fire, and a large incision having been previously made in the middle, the melted resin runs out therefrom in considerable abundance. 36,350 lbs. of it have been exported in 1875 from Port-au-Prince.

The resin is collected chiefly from G. officinale, which affords it in greater plenty than G. sanctum.

Description—The resin occurs in globular tears ½ an inch to 1 inch in diameter, but much more commonly in the form of large compact masses, containing fragments of wood and bark. The resin is brittle, breaking with a clean, glassy fracture; in thin pieces it is transparent and appears of a greenish brown hue. The powder when fresh is grey, but becomes green by exposure to light and air. It has a slight balsamic odour and but little taste, yet leaves an irritating sensation in the throat.

The resin has a sp. gr. of about 1·2. It fuses at 85° C., emitting a peculiar odour somewhat like that of benzoin. It is easily soluble in acetone, ether, alcohol, amylic alcohol, chloroform, creosote, caustic alkaline solutions, and oil of cloves; but is not dissolved or only partially by other volatile oils, benzol or bisulphide of carbon. By oxidizing agents it acquires a fine blue colour, well shown when a fresh alcoholic solution is allowed to dry up in a very thin layer and this is then sprinkled with a dilute alcoholic solution of ferric chloride. Reducing agents of all kinds, and heat produce decoloration. An alcoholic solution may be thus blued and decolorized several times in succession, but it loses at length its susceptibility. This remarkable property of guaiacum was utilized by Schönbein in his well-known researches on ozone.

Chemical Composition—The composition of guaiacum resin was ascertained by Hadelich (1862) to be as follows:—

Guaiaconic Acid,	70·3	per cent.
Guaiaretic Acid,	10·5	”
Guaiac Beta-resin,	9·8	”
Gum,	3·7	”
Ash constituents,	0·8	”
Guaiacic Acid, colouring matter
(Guaiac-yellow), and impurities,	4·9	”

If the mother-liquor obtained in the preparation of the potassium salt of guaiaretic acid (vide infra) is decomposed by hydrochloric acid, and the precipitate washed with water, ether will extract from the mass Guaiaconic Acid, a compound discovered by Hadelich, having the formula C₃₈H₄₀O₁₀. It is a light brown, amorphous substance, fusing at 100° C. It is without acid reaction but decomposes alkaline carbonates, forming uncrystallizable salts easily soluble in water or alcohol. It is insoluble in water, benzol, or bisulphide of carbon, but dissolves in ether, chloroform, acetic acid or alcohol. With oxidizing agents it acquires a transient blue tint.

Guaiaretic Acid, C₂₀H₂₆O₄, discovered by Hlasiwetz in 1859, may be extracted from the crude resin by alcoholic potash or by quicklime. With the former it produces a crystalline salt; with the latter an amorphous compound: from either the liquid, which contains chiefly a salt of guaiaconic acid, may be easily decanted. Guaiaretic acid is obtained by decomposing one of the salts referred to with hydrochloric acid, and crystallizing from alcohol. The crystals, which are soluble also in ether, benzol, chloroform, carbon bisulphide or acetic acid, but neither in ammonia nor in water, melt below 80° C., and may be volatilized without decomposition. The acid is not coloured blue by oxidizing agents.

By exhausting guaiacum resin with boiling bisulphide of carbon a slightly yellowish solution is obtained (containing chiefly guaiaretic acid?), which, on addition of concentrated sulphuric acid, turns beautifully red.

After the extraction of the guaiaconic acid there remains a substance insoluble in ether to which the name Guaiac Beta-resin has been applied. It dissolves in alcohol, acetic acid or alkalis, and is precipitated by ether, benzol, chloroform or carbon bisulphide in brown flocks, the composition of which appears not greatly to differ from that of guaiaconic acid.

Guaiacic Acid, C₁₂H₁₆O₆, obtained in 1841 by Thierry from guaiacum wood or from the resin, crystallizes in colourless needles. Hadelich was not able to obtain more than one part from 20,000 of guaiacum resin.

Hadelich’s Guaiac-yellow, the colouring matter of guaiacum resin, first observed by Pelletier, crystallizes in pale yellow quadratic octohedra, having a bitter taste. Like the other constituents of the resin, it is not a glucoside.

The decomposition-products of guaiacum are of peculiar interest. On subjecting the resin to dry distillation in an iron retort and rectifying the distillate, Guaiacene (Guajol of Völckel), C₅H₈O, passes over at 118° C. as a colourless neutral liquid having a burning aromatic taste.

At 205°-210° C., there pass over other products, Guaiacol, C₆H₄·OCH₃·OH, (methylic ether of pyrocatechin), and Kreosol C₆H₃·OH(CH₃)₂. Both are thickish, aromatic, colourless liquids, which become green by caustic alkalis, blue by alkaline earths, and are similar in their chemical relations to eugenic acid. Guaiacol has been prepared synthetically by Gorup-Besanez (1868) by combining iodide of methyl, CH₃I, with pyrocatechin, C₆H₄(OH)₂.

After the removal by distillation of the liquids just described, there sublime upon the further application of heat pearly crystals of Pyroguaiacin, C₃₈H₄₄O₆, an inodorous substance melting at 180° C. The same compound is obtained together with guaiacol by the dry distillation of guaiaretic acid. Pyroguaiacin is coloured green by ferric chloride, and blue by warm sulphuric acid. The similar reactions of the crude resin are probably due to this substance (Hlasiwetz).

Beautiful coloured reactions are likewise exhibited by two new acids which Hlasiwetz and Barth obtained (1864) in small quantity together with traces of fatty volatile acids, by melting purified resin of guaiacum with potassium hydrate. One of them is isomeric with pyrocatechuic acid.

Uses—Guaiacum resin is reputed diaphoretic and alterative. It is frequently prescribed in cases of gout and rheumatism.

Adulteration—The drug is sometimes imported in a very foul condition and largely contaminated with impurities arising from a careless method of collection.

---

FRUCTUS LIMONIS.

Botanical Origin—Citrus Limonum Risso (C. Medica var. β Linn.), a small tree 10 to 15 feet in height, planted here and there in gardens in many subtropical countries, but cultivated as an object of industry on the Mediterranean coast between Nice and Genoa, in Calabria, Sicily, Spain, and Portugal.

The tree which is supposed to represent the wild state of the lemon and lime, and as it seems to us after the examination of numerous specimens in the herbarium of Kew, of the citron (Citrus Medica Risso) also, is a native of the forests of Northern India, where it occurs in the valleys of Kumaon and Sikkim.

The cultivated lemon-tree is of rather irregular growth, with foliage somewhat pallid, sparse, and uneven, not forming the fine, close head of deep green that is so striking in the orange tree. The young shoots are of a dull purple; the flowers, which are produced all the year except during the winter, and are in part hermaphrodite and in part unisexual, have the corolla externally purplish; internally white, and a delicate aroma distinct from that of orange blossom. The fruit is pale yellow, ovoid, usually crowned by a nipple.

History—The name of the lemon in Sanskrit is Nimbuka; in Hindustani, Limbu, Limu, or Ninbu. It is probably originally a Cashmere word, which was transferred to the Sanskrit in comparatively modern times, not in the antiquity.[453] From these sounds the Arabians formed the word Limun, which has passed into the languages of Europe.

The lemon was unknown to the inhabitants of ancient Greece and Rome; but it is mentioned in the Book of Nabathæan Agriculture,[454] which is supposed to date from the 3rd or 4th century of our era. The introduction of the tree to Europe is due to the Arabians, yet at what precise period is somewhat doubtful. Arance and Limone are mentioned by an Arabic poet living in the 11th century, in Sicily, quoted by Falcando.[455] The geographer Edrisi,[456] who resided at the court of Roger II., king of Sicily, in the middle of the 12th century, mentions the lemon (limouna) as a very sour fruit of the size of an apple which was one of the productions of Mansouria on the Mahrân or Indus; and he speaks of it in a manner that leads one to infer it was not then known in Europe. This is the more probable from the fact that there is no mention either of lemon or orange in a letter written a.d. 1239 concerning the cultivation of the lands of the Emperor Frederick II. at Palermo,[457] a locality in which these fruits are now produced in large quantity.

On the other hand the lemon is noticed at great length by Ibn Baytar of Malaga, who flourished in the first half of the 13th century, but of its cultivation in Spain at that period there is no actual mention.[458] In 1369 at least citron trees, “arbores citronorum,” were planted in Genoa,[459] and there is evidence that also the lemon-tree was grown on the Riviera di Ponente about the middle of the 15th century, since Limones and also Citri are mentioned in the manuscript Livre d’Administration of the city of Savona, under date 1486.[460] The lemon was cultivated as early as 1494 in the Azores, whence the fruit used to be largely shipped to England; but since the year 1838 the exportation has totally ceased.[461]

Description—The fruit of Citrus Limonum as found in the shops[462] is from about 2 to 4 inches in length, egg-shaped with a nipple more or less prominent at the apex; its surface, of a pale yellow, is even or rugged, covered with a polished epidermis. The parenchyme within the latter abounds in large cells filled with fragrant essential oil. The roughness of the surface of the rind is due to the oil-cells. The peel, which varies considerably in thickness but is never so thick as that of the citron, is internally white and fibrous, and is adherent to the pale yellow pulp. The latter is divided into 10 or 12 segments each containing 2 or 3 seeds. It abounds in a pale yellow acid juice having a pleasant sour taste and a slight peculiar odour quite distinct from that of the peel. When removed from the pulp by pressure, the juice appears as a rather turbid yellowish fluid having a sp. gr. which varies from 1·040 to 1·045, and containing in each fluid ounce from 40 to 46 grains of citric acid, or about 9½ per cent.[463] In Italy all the fine and perfect fruit is exported; the windfalls and the damaged fruit are used for the production of the essential oil and the juice. About 13,000 lemons of this kind yield one pipe (108 gallons) of raw juice. Sicilian juice in November will contain about 9 ounces of citric acid per gallon, but 6 ounces when afforded by the fruit collected in April. The juice is boiled down in copper vessels, over an open fire, till its specific gravity is about 1·239.[464] Lemon juice (Succus limonis) for administration as a medicine should be pressed as wanted from the recent fruit whenever the latter is obtainable.

The peel (Cortex limonis) cut in somewhat thin ribbons from the fresh fruit is used in pharmacy, and is far preferable to that sold in a dried state.

Microscopic Structure of the Peel.—The epidermis exhibits numerous stomata; the parenchyme of the pericarp encloses large oil-cells, surrounded by small tabular cells. The inner spongy tissue is built up of very remarkable branched cells, separated by large intercellular spaces. A solution of iodine in iodide of potassium imparts to the cell-walls a transient blue coloration. The outer layers of the parenchymatous tissue contain numerous yellowish lumps of a substance which assumes a brownish hue by iodine, and yields a yellow solution if potash be added. Alkaline tartrate of copper is reduced by this substance, which probably consists of hesperidin. There also occur large crystals of oxalate of calcium, belonging to the monoclinic system. The interior tissue is irregularly traversed by small vascular bundles.

Chemical Composition—The peel of the lemon abounds in essential oil, which is a distinct article of commerce, and will be described hereafter.

Lemons, as well as other fruits of the genus Citrus, contain a bitter principle, Hesperidin, of which E. Hoffmann[465] obtained 5 to 8 per cent. from unripe bitter oranges. He extracted them with dilute alcohol, after they had previously been exhausted by cold water. The alcohol should contain about 1 per cent. of caustic potash; the liquid on cooling is acidulated with hydrochloric acid, when it yields a yellowish crystalline deposit of hesperidin, which may be obtained colourless and tasteless by recrystallization from boiling alcohol. By dilute sulphuric acid (1 per cent.) hesperidin is broken up as follows:—

C₂₂H₂₆O₁₂  =	C₁₆H₁₄O₆	+ C₆H₁₂O₆.
Hesperidin.	Hesperetin.	Glucose.

Hesperidin is very little soluble even in boiling water or in ether, but dissolves readily in hot acetic acid, also in alkaline solutions, the latter then turning soon yellow and reddish. Pure hesperidin, as presented to one of us by Hoffmann, darkens when it is shaken with alcoholic perchloride of iron, and turns dingy blackish brown when gently warmed with the latter.

Hesperetin forms crystals melting at 223° C., soluble both in alcohol or ether, not in water; they taste sweet. They are split up by potash in Phloroglucin and Hesperetic acid, C₁₀H₁₀O₄.

On addition of ferric chloride, thin slices of the peel are darkened, owing probably to some derivative of hesperidin, or to hesperidin itself.

The name hesperidin had also been applied to yellow crystals extracted from the shaddock, Citrus decumana L., the dried flowers of which afford about 2 per cent. of that substance. It is, as shown in 1879 by E. Hoffmann, quite different from hesperidin as described above; he calls it Naringin and assigns to it the formula C₂₃H₂₆O₁₂+4OH₂. Naringin is readily soluble in hot water or in alcohol, not in ether or chloroform. Its solutions turn brown-red on addition of ferric chloride.

Lemon juice, some of the characters of which have been already noticed, is an important article in a dietetic point of view, being largely consumed on shipboard for the prevention of scurvy. In addition to citric acid it contains 3 to 4 per cent. of gum and sugar, and 2·28 per cent. of inorganic salts, of which according to Stoddart only a minute proportion is potash. Cossa[466] on the other hand, who has recently studied the products of the lemon tree with much care, has found that the ash of dried lemon juice contains 54 per cent. of potash, besides 15 per cent. of phosphoric acid.

Stoddart has pointed out the remarkable tendency of citric acid to undergo decomposition,[467] and has proved that in lemons kept from February to July this acid generally decreases in quantity, at first slowly, but afterwards rapidly, until at the end of the period it entirely ceases to exist, having been all split up into glucose and carbonic acid. At the same time the sp. gr. of the juice was found to have undergone but slight diminution:—thus it was 1·044 in February, 1·041 in May, and 1·027 in July, and the fruit had hardly altered in appearance. Lemon juice may with some precautions be kept unimpaired for months or even years. Yet it is capable of undergoing fermentation by reason of the sugar, gum, and albuminoid matters which it contains.

Commerce—Lemons are chiefly imported from Sicily, to a smaller extent from the Riviera of Genoa and from Spain. From the published statistics of trade, in which lemons are classed together with oranges under one head, it appears that these fruits are being imported in increasing quantities. The value of the shipments to the United Kingdom in 1872 (largely exceeding those of any previous year) was £1,154,270. Of this sum, £986,796 represents the value of the oranges and lemons imported from Spain, Portugal, the Canary Islands and Azores; £155,330 the shipments of the same fruit from Italy; and £3,825 those from Malta.

Of concentrated lemon juice there were exported in 1877 from Messina 1,631,332 kilogrammes, valued at 2,446,996 lire. The value of concentrated lime juice exported in 1874 from Montserrat was £3,390. From Dominica, 11,285 gallons, value £1,825, were shipped in 1875.

Uses—Lemon peel is used in medicine solely as a flavouring ingredient. Freshly prepared lemon juice is often administered with an alkaline bicarbonate in the form of an effervescing draught, or in a free state.

Concentrated lemon juice is imported for the purpose of making citric acid; it is derived not only from the lemon, but also, to a smaller extent, from the lime and bergamot. Lime juice of the West Indies is chiefly used as a beverage; small quantities of it are also exported for the manufacture of citric acid. The culture of Citrus Limetta Risso, the lime, was introduced in Montserrat in 1852.

OLEUM LIMONIS.

Botanical Origin—Citrus Limonum Risso (see p. 114).

History—The chemists of the 16th century were well acquainted with the method of extracting essential oils by distillation. Besson in his work L’art et moyen parfaict de tirer huyles et eaux de tous medicaments simples et oleogineux, published at Paris in 1571, mentions lemon-(citron) and orange-peel among the substances subjected to this process. Giovanni Battista Porta,[468] a learned Neapolitan writer, describes the method of preparing Oleum ex corticibus Citri to consist in removing the peel of the fruit with a rasp and distilling it so comminuted with water; and adds that the oils of lemon and orange may be obtained in the same manner. Essence of lemon of two kinds, namely expressed and distilled, was sold in Paris in the time of Pomet, 1692.

Production—Essential oil of lemon is manufactured in Sicily, at Reggio in Calabria, and at Mentone and Nice in France.

The lemons are used while still rather green and unripe, as being richer in oil than when quite mature. Only the small and irregular fruit, such as is not worth exporting, is employed for affording the essence.

The process followed in Sicily and Calabria may be thus described;[469] it is performed in the months of November and December.

The workman first cuts off the peel in three thick longitudinal slices, leaving the central pulp of a three-cornered shape with a little peel at either end. This central pulp he cuts transversely in the middle, throwing it on one side and the pieces of peel on the other. The latter are allowed to remain till the next day and are then treated thus: the workman seated holds in the palm of his left hand a flattish piece of sponge, wrapping it round his forefinger. With the other he places on the sponge one of the slices of peel, the outer surface downwards, and then presses the zest-side (which is uppermost) so as to give it for the moment a convex instead of a concave form. The vesicles are thus ruptured, and the oil which issues from them is received in the sponge with which they are in contact. Four or five squeezes are all the workman gives to each slice of peel, which done he throws it aside. Though each bit of peel has attached to it a small portion of pulp, the workman contrives to avoid pressing the latter. As the sponge gets saturated the workman wrings it forcibly, receiving its contents in a coarse earthen bowl provided with a spout; in this rude vessel, which is capable of holding at least three pints, the oil separates from the watery liquid which accompanies it and is then decanted.

The yield is stated to be very variable, 400 fruits affording 9 to 14 ounces of essence. The prisms of pulp and the exhausted pieces of peel are submitted to pressure in order to extract from them lemon juice, and are said to be also subjected to distillation. The foregoing is termed the sponge-process; it is also applied to the orange. It appears rude and wasteful, but when honestly performed it yields an excellent product.

Essence of lemon is prepared at Mentone and Nice by a different method. The object being to set free and to collect the oil contained in the vesicles of the peel, an apparatus is employed, which may be thus described:—a stout saucer or shallow basin of pewter, about 8½ inches in diameter with a lip on one side for convenience of pouring. Fixed in the bottom of this saucer are a number of stout, sharp, brass pins, standing up about half an inch; the centre of the bottom is deepened into a tube about an inch in diameter and five inches in length, closed at its lower end. This vessel, which is called an écuelle à piquer, has therefore some resemblance to a shallow, dish-shaped funnel, the tube of which is closed below.

The workman takes a lemon in the hand, and rubs it over the sharp pins, turning it round so that the oil-vessels of the entire surface may be punctured. The essential oil which is thus liberated is received in the saucer whence it flows down into the tube; and as this latter becomes filled, it is poured into another vessel that it may separate from the turbid aqueous liquid that accompanies it. It is finally filtered and is then known as Essence de Citron au zeste. A small additional produce is sometimes obtained by immersing the scarified lemons in warm water and separating the oil which floats off.

A second kind of essence termed Essence de Citron distillée is obtained by rubbing the surface of fresh lemons, or of those which have been submitted to the process just described, on a coarse grater of tinned iron, by which the portion of peel richest in essential oil is removed. This grated peel is subjected to distillation with water, and yields a colourless essence of very inferior fragrance, which is sold at a low price.

Description[470]—The oil obtained by the sponge-process and that of the écuelle à piquer are mobile liquids of a faint yellow colour, of exquisite fragrance and bitterish aromatic taste.

The different specimens which we have examined are readily miscible with bisulphide of carbon, but dissolve sparingly in spirit of wine (0·830). An equal weight of the oil and of spirit of wine forms a turbid mixture. No peculiar coloration is produced by mixture with perchloride of iron.

The oils are dextrogyre, but differ in their rotatory power, as may be illustrated by the following results, which we obtained by examining them in a column 50 millimetres long in the polaristrobometer of Wild. The oil of Signori Panuccio, due to the sponge-process (p. 118, note 2), deviated 20·9°, that of Monsieur Médecin (Essence de Citron au zeste) obtained by the éculle à piquer deviated 33·4° and his distilled oil 28·3°.

Chemical Composition—The prevailing portion of most essential oils of the Aurantiaceæ agrees with the formula C₁₀H₁₆; the differences which they exhibit chiefly concern their optical properties, odour, and colour. The boiling point mostly varies from about 170° to 180° C., the sp. gr. between 0·83 and 0·88. These oils are a mixture of isomeric hydrocarbons, and also contain a small amount of cymene, C₁₀H₁₄, and of oxygenated oils, not yet well known; of these we may infer the presence either from analytical results or simply from the fact that the crude oils are altered by metallic sodium. If they are purified by repeated rectification over that metal, they are finally no longer altered by it. Oils thus purified cease to possess their original fragrance, and often resemble oil of turpentine, with which they agree in composition and general chemical behaviour.

As to essential oil of lemons, its chief constituent is the terpene, C₁₀H₁₆, which, like oil of turpentine, easily yields crystals of terpin, C₁₀H₁₆ 3OH₂. There is further present, according to Tilden (1879) another hydrocarbon, C₁₀H₁₆, which already boils at 160° C., whereas the foregoing boils at 176° C. Lastly a small amount of cymene and of a compound acetic ether, C₂H₃O(C₁₀H₁₇O), would appear to occur also in oil of lemons. The crude oil of lemons already yields the crystalline compound C₁₀H₁₆ + 2HCl, when saturated with anhydrous hydrochloric gas, whereas by the same treatment oil of turpentine affords the solid compound C₁₀H₁₆ + HCl.

Essential oil of lemons (not the distilled) when long kept deposits a greasy mass, from which we have obtained small crystals apparently of Bergaptene (p. 123).

Commerce—Essence of lemons is shipped chiefly from Messina and Palermo, packed in copper bottles called in Italian ramiere and by English druggists “jars” holding 25 to 50 kilo. or more; sometimes in tin bottles of smaller size. The quantity of essences of lemon, orange and bergamot exported from Sicily in 1871 was 368,800 lb., valued at £144,520, of which about two-thirds were shipped to England.[471] In 1877 the export of these essential oils from Messina amounted to 306,948 kilogrammes, valued at 6,130,960 lire.

Uses—Essence of lemon is used in perfumery, and as a flavouring ingredient; and though much sold by druggists is scarcely employed in medicine.

Adulteration—Few drugs are more rarely to be found in a state of purity than essence of lemon. In fact it is stated that almost all that comes into the market is more or less diluted with oil of turpentine or with the cheaper distilled oil of lemons. Manufacturers of the essence complain that the demand for a cheap article forces them to this falsification of their product.

OLEUM BERGAMOTTÆ.

Botanical Origin—Citrus Bergamia var. vulgaris Risso et Poiteau,[472] a small tree closely resembling in flowers and foliage the Bitter Orange. Its fruit is 2½ to 3 inches in diameter, nearly spherical, or slightly pear-shaped, frequently crowned by the persistent style; it is of a pale golden yellow like a lemon,[473] with the peel smooth and thin, abounding in essential oil of a peculiar fragrance; the pulp is pale yellowish green, of a bitterish taste, and far less acid than that of the lemon.

The tree is cultivated at Reggio in Calabria, and is unknown in a wild state.

History—The bergamot is one of the cultivated forms which abound in the genus Citrus, and which constitute the innumerable varieties of the orange, lemon and citron. Whether it is most nearly related to the lemon or to the orange is a point discussed as early as the beginning of the last century. Gallesio[474] remarks that it so evidently combines the characters of the two that it should be regarded as a hybrid between them. The bergamot first appeared in the latter part of the 17th century. It is not mentioned in the grand work on orange trees of Ferrari,[475] published at Rome in 1646, nor in the treatise of Commelyn[476] (1676), nor in the writings of Lanzoni (1690),[477] or La Quintinie (1692).[478] So far as we know, it is first noticed in a little book called Le Parfumeur François, printed at Lyons in 1693. The author who calls himself Le Sieur Barbe, parfumeur, says that the Essence de Cedra ou Bergamotte is obtained from the fruits of a lemon-tree which has been grafted on the stem of a bergamot pear; he adds that it is got by squeezing small bits of the peel with the fingers in a bottle or globe large enough to allow the hand to enter.

Volkamer of Nuremberg, who produced a fine work on the Citron tribe in 1708, has a chapter on the Limon Bergamotta, which he describes as gloria limonum et fructus inter omnes nobilissimus. He states that the Italians prepare from it the finest essences, which are sold at a high price.[479]

But, as shown by one of us,[480] the essential oil of bergamot had already, in 1688, a place among the stores of an apothecary of the German town of Giessen.

The name Bergamotta was originally applied to a large kind of pear, called in Turkish “beg-ârmûdî,” i.e. prince’s pear.[481]

Production—The bergamot is cultivated at Reggio, on low ground near the sea, and in the adjacent villages. The trees are often intermixed with lemon and orange trees, and the soil is well irrigated and cropped with vegetables.

The essential oil (Oleum Bergamottæ) is obtained from the full-grown but still unripe and more or less green fruits, gathered in the months of November and December. They are richer in oil than any one of the allied fruits. It was formerly made like that of lemon by the sponge-process, but during the last 20 years this method has been generally superseded by the introduction of a special machine for the extraction of the essential oil. In this machine the fruits are placed in a strong, saucer-like, metallic dish, about 10 inches in diameter, having in the centre a raised opening which with the outer edge forms a broad groove or channel; the dish is fitted with a cover of similar form. The inner surface both of the dish and cover is rendered rough by a series of narrow, radiating metal ridges of blades which are about ¼ of an inch high and resemble the backs of knifes. The dish is also furnished with some small openings to allow of the outflow of essential oil; and both dish and cover are arranged in a metallic cylinder, placed over a vessel to receive the oil. By a simple arrangement of cog-wheels moved by a handle, the cover, which is very heavy, is made to revolve rapidly over the dish, and the fruit lying in the groove between the two is carried round, and at the same time is subjected to the action of the sharp ridges, which, rupturing the oil-vessels, cause the essence to escape, and set it free to flow out by the small openings in the bottom of the dish. The fruits are placed in the machine, 6, 8, or more at a time, according to their size, and subjected to the rotatory action above described for about half a minute, when the machine is stopped, they are removed, and fresh ones substituted. About 7,000 fruits can thus be worked in one of these machines in a day. The yield of oil is said to be similar to that of lemon, namely 2½ to 3 ounces from 100 fruits.

Essence of bergamot made by the machine is of a greener tint than that obtained by the old sponge-process. During some weeks after extraction it gradually deposits a quantity of white greasy matter (bergaptene), which, after having been exhausted as much as possible by pressure, is finally subjected to distillation with water in order to separate the essential oil it still contains.

The fruits from which the essence has been extracted are submitted to pressure, and the juice, which is much inferior in acidity to lemon juice, is concentrated and sold for the manufacture of citric acid. Finally, the residue from which both essence and juice have been removed, is consumed as food by oxen.

Description[482]—Essential oil of bergamot is a thin and mobile fluid of peculiar and very fragrant odour, bitterish taste, and slightly acid reaction. It has a pale greenish yellow tint, due to traces of chlorophyll, as may be shown by the spectroscope. Its sp. gr. is 0·86 to 0·88; its boiling point varies from 183° to 195° C.

The oil is miscible with spirit of wine (0·83 sp. gr.), absolute alcohol, as well as with crystallizable acetic acid. Four parts dissolve clearly one part of bisulphide of carbon, but the solution becomes turbid if a larger proportion of the latter is added. Bisulphide of carbon itself is incapable of dissolving clearly any appreciable quantity of the oil. A mixture of 10 drops of the oil, 50 drops of bisulphide of carbon and one of strong sulphuric acid has an intense yellow hue. Perchloride of iron imparts to bergamot oil dissolved in alcohol a dingy brown colour.

Panuccio’s oil of bergamot examined in the same way as that of lemon (p. 120) deviates 7° to the right, and has therefore a dextrogyre power very inferior to that of other oils of the same class.[483] But it probably varies in this respect, for commercial specimens which we judged to be of good quality deviated from 6·8° to 10·4° to the right.

Chemical Composition—If essential oil of bergamot is submitted to rectification, the portions that successively distill over do not accord in rotatory power or in boiling point, a fact which proves it to be a mixture of several oils, as is further confirmed by analysis. It appears to consist of hydrocarbons, C₁₀H₁₆, and their hydrates, neither of which have as yet been satisfactorily isolated. Oil of bergamot, like that of turpentine, yields crystals of the composition C₁₀H₁₆ + 3H₂O, if 8 parts are allowed to stand some weeks with 1 part of spirit of wine, 2 of nitric acid (sp. gr. 1·2) and 10 of water, the mixture being frequently shaken. No solid compound is produced by saturating the oil with anhydrous hydrochloric gas.

The greasy matter that is deposited from oil of bergamot soon after its extraction, and in small quantity is often noticeable in that of commerce, is called Bergaptene or Bergamot Camphor. We have obtained it in fine, white, acicular crystals, neutral and inodorous, by repeated solution in spirit of wine. Its composition according to the analysis of Mulder (1837) and of Ohme (1839) answers to the formula C₉H₆O₃, which in our opinion requires further investigation. Crystallized bergaptene is abundantly soluble in chloroform, ether, or bisulphide of carbon; the alcoholic solution is not altered by ferric salts.

Commerce—Essence of bergamot, as it is always termed in trade, is chiefly shipped from Messina and Palermo in the same kind of bottles as are used for essence of lemon.

Uses—Much employed in perfumery, but in medicine only occasionally for the sake of imparting an agreeable odour to ointments.

Adulteration—Essence of bergamot, like that of lemon, is extensively and systematically adulterated, and very little is sent into the market entirely pure. It is often mixed with oil of turpentine, but a finer adulteration is to dilute it with essential oil of the leaves or with that obtained by distillation of the peel or of the residual fruits. Some has of late been adulterated with petroleum.

The optical properties, as already mentioned, may afford some assistance in detecting fraudulent admixtures, though as regards oil of turpentine it must be borne in mind that there are levogyre as well as dextrogyre varieties. This latter oil and likewise that of lemon is less soluble in spirit of wine than that of bergamot.

CORTEX AURANTII.

Botanical Origin—Citrus vulgaris Risso (C. Aurantium var. a amara Linn., C. Bigaradia Duhamel).

The Bitter or Seville or Bigarade Orange, Bigaradier[484] of the French, is a small tree extensively cultivated in the warmer parts of the Mediterranean region, especially in Spain, and existing under many varieties.

Northern India is the native country of the orange tree. In Gurhwal, Sikkim, and Khasia there occurs a wild orange which is the supposed parent of the cultivated orange, whether Sweet or Bitter.

The Bitter Orange reproduces itself from seed, and is regarded, at least by cultivators, as quite distinct from the Sweet Orange, from which however it cannot be distinguished by any important botanical characters. Generally speaking, it differs from the latter in having the fruit rugged on the surface, of a more deep or reddish-orange hue, with the pulp very sour and bitter. The peel, as well as the flowers and leaves, are more aromatic than the corresponding parts of the Sweet Orange, and the petiole is more broadly winged.

History—The orange was unknown to the ancient Greeks and Romans; and its introduction to Europe is due to the Arabs, who, according to Gallesio,[485] appear to have established the tree first in Eastern Africa, Arabia, and Syria, whence it was gradually conveyed to Italy, Sicily, and Spain. In the opinion of the writer just quoted, the bitter orange was certainly known at the commencement of the 10th century to the Arabian physicians, one of whom, Avicenna,[486] employed its juice in medicine.

There is strong evidence to show that the orange first cultivated in Europe was the Bitter Orange or Bigarade. The orange tree at Rome, said to have been planted by St. Dominic about a.d. 1200, and which still exists at the monastery of St. Sabina, bears a bitter fruit; and the ancient trees standing in the garden of the Alcazar at Seville are also of this variety. Finally, the oranges of Syria (ab indigenis Orenges nuncupati) described by Jacques de Vitri, Bishop of Acon (ob. a.d. 1214) were acidi seu pontici saporis.[487]

The Sweet Orange began to be cultivated about the middle of the 15th century, having been introduced from the East by the Portuguese. It has probably long existed in Southern China, and may have been taken thence to India. In the latter country there are but few districts in which its cultivation is successful, and the Bitter Orange is hardly known at all. The name it has long borne of China[488] or Portugal Orange indicates what has been the usual opinion as to its origin. It probably alludes more exactly to a superior variety brought about 1630 from China to Portugal.[489]

One of the first importations of oranges into England occurred in a.d. 1290, in which year a Spanish ship came to Portsmouth, of the cargo of which the queen of Edward I. bought one frail of Seville figs, one of raisins or grapes, one bale of dates, 230 pomegranates, 15 citrons, and 7 oranges (“poma de orenge”).[490]

Description—The Bitter Orange known in London as the Seville Orange is a globular fruit, resembling in size, form, and structure the common Sweet Orange, but having the peel much rougher, and when mature of a somewhat deeper hue. The pulp of the fruit is filled with an acid bitter juice. The ripe fruit is imported into London; the peel is removed from it with a sharp knife in one long spiral strip, and quickly dried, or it is sold in the fresh state. It is the more esteemed when cut thin, so as to include as little as possible of the white inner layer.

Well-dried orange peel should be externally of a bright tint and white on its inner surface; it should have a grateful aromatic smell and bitter taste. The peel is also largely imported into London ready dried, especially from Malta. We have observed it from this latter place of three qualities, namely in elliptic pieces or quarters, in broad curled strips, and lastly a very superior kind, almost wholly free from white zest, in strips less than ⅛ of an inch in width, cut apparently by a machine. Such needless subdivision as this last has undergone must greatly favour an alteration and waste of the essential oil. Foreign-dried orange peel fetches a lower price than that dried in England.

Microscopic Structure—There is no difference between the tissues of this drug and those of lemon peel.

Chemical Composition—The essential oil to which the peel of the orange owes its fragrant odour, is a distinct article of commerce, and will be noticed hereafter under a separate head. The other constituents of the peel probably agree with those of lemon peel. The substance mentioned under the name of Hesperidin (p. 116) particularly abounds in unripe bitter oranges.

Uses—Bitter orange peel is much used in medicine as an aromatic tonic.

OLEUM NEROLI.

Botanical Origin—Citrus vulgaris Risso. (See page 124.)

History—Porta, the Italian philosopher of the 16th century referred to (p. 118), was acquainted with the volatile oil of the flowers of the citron tribe (“Oleum ex citriorum floribus”), which he obtained by the usual process of distillation, and describes as possessing the most exquisite fragrance. That distilled from orange flowers acquired a century later (1675-1685) the name of Essence of Neroli from Anne-Marie de la Trémoille-Noirmoutier, second wife of Flavio Orsini, duke of Bracciano and prince of Nerola or Neroli. This lady employed it for the perfuming of gloves, hence called in Italy Guanti di Neroli.[491] It was known in Paris to Pomet, who says[492] the perfumers have given it the name of Neroli, and that it is made in Rome and in Provence.

Production—Oil of Neroli is prepared from the fresh flowers of the Bigarade or Bitter Orange by the ordinary process of distillation with water, conducted in small copper stills. The flowers of all the allied plants are far less aromatic. The water which distills over with the oil constitutes, after the removal of the latter from its surface, the Orange Flower Water (Aqua aurantii florum vel Aqua Naphæ)[493] of commerce. The manufacture is carried on chiefly in the south of France at Grasse, Cannes, and Nice. The yield is about 0·6 to 0·7 per cent. of oil from fresh flowers, as stated by Poiteau et Risso.[494] The flowers of the sweet orange afford but half that amount of oil.

Description and Chemical Composition—Oil of Neroli as found in commerce is seldom pure, for it generally contains an admixture of the essential oil of orange-leaf called Essence of Petit Grain.

By the kind assistance of Mr. F. G. Warrick of Nice, we have obtained a sample of Bigarade Neroli of guaranteed purity, to which the following observations relate. It is of a brownish hue, most fragrant odour, bitterish aromatic taste, and is neutral to test-paper. Its sp. gr. at 11° C. is 0·889. When mixed with alcohol, it displays a bright violet fluorescence, quite distinct from the blue fluorescence of a solution of quinine. In oil of Neroli the phenomenon may be shown most distinctly by pouring a little spirit of wine on to the surface of the essential oil, and causing the liquid to gently undulate. The oil is but turbidly miscible with bisulphide of carbon. It assumes a very pure, intense, and permanent crimson hue if shaken with a saturated solution of bisulphide of sodium. Examined in a column of 100 mm. we observed the oil to deviate the ray of polarized light 6° to the right.

Subjected to distillation, the larger part of the oil passes over at 185°-195° C.; we found this portion to be colourless, yet to display in a marked manner the violet fluorescence and also to retain the odour of the original oil. The portion remaining in the retort was mixed with about the same volume of alcohol (90 per cent.) and some drops of water added, yet not sufficient to occasion turbidity. A very small amount of the crystalline Neroli Camphor then made its appearance, floating on the surface of the liquid; by re-solution in boiling alcohol it was obtained in crystals of rather indistinct form. The redistilled oil gave no camphor whatever.

Neroli Camphor was first noticed by Boullay in 1828. According to our observations it is a neutral, inodorous, tasteless substance, fusible at 55° C., and forming on cooling a crystalline mass. The crystallization should be effected by cooling the hot alcoholic solution, no good crystals being obtainable by slow evaporation or by sublimation. The produce was extremely small, about 60 grammes of oil having yielded not more than 0·1 gramme. Perhaps this scantiness of produce was due to the oil being a year and a half old, for according to Plisson[495] the camphor diminishes the longer the oil is kept.[496] We were unable to obtain any similar substance from the oils of bergamot, petit grain, or orange peel.

Orange Flower Water is a considerable article of manufacture among the distillers of essential oils in the south of Europe, and is imported thence for use in pharmacy. According to Boullay[497] it is frequently acid to litmus when first made,—is better if distilled in small than in large quantities, and if made from the petals per se, rather than from the entire flowers. He also states that only 2 lb. of water should be drawn from 1 lb. of flowers, or 3 lb. if petals alone are placed in the still. As met with in commerce, orange flower water is colourless or of a faintly greenish yellow tinge, almost perfectly transparent, with a delicious odour and a bitter taste. Acidulated with nitric acid, it acquires a pinkish hue more or less intense, which disappears on saturation by an alkali.

Uses—Oil of Neroli is consumed almost exclusively in perfumery. Orange flower water is frequently used in medicine to give a pleasant odour to mixtures and lotions.

Adulteration—The large variation in value of oil of Neroli as shown by price-currents[498] indicates a great diversity of quality. Besides being very commonly mixed, as already stated, with the distilled oil of the leaves (Essence de Petit Grain)[499], it is sometimes reduced by addition of the less fragrant oil obtained from the flowers of the Portugal or Sweet Orange. In some of these adulterations we must conclude that orange flower water participate: metallic contamination of the latter is not unknown.

Other Products of the genus Citrus.

Essence or Essential Oil of Petit Grain—was originally obtained by subjecting little immature oranges to distillation (Pomet—1692); but it is now produced, and to a large extent, by distillation of the leaves and shoots either of the Bigarade or Bitter Orange, or of the Portugal or Sweet Orange. The essence of the former is by far the more fragrant, and commands double the price. Poiteau and Risso[500] state that the leaves of the Brigaradier with bitter fruit are by far the richest in essential oil among all the allied leaves; they are obtained in the lemon-growing districts of the Mediterranean where the essence is manufactured. Lemon-trees being mostly grafted on orange-stocks, the latter during the summer put forth shoots, which are allowed to grow till they are often some feet in length. The cultivator then cuts them off, binds them in bundles, and conveys them to the distiller of Petit Grain. The strongest shoots are frequently reserved for walking-sticks. The leaves of the two sorts of orange are easily distinguished by their smell when crushed. Essence of Petit Grain, which in odour has a certain resemblance to Neroli, is used in perfumery and especially in the manufacture of Eau de Cologne.

According to Gladstone (1864) it consists mainly of a hydrocarbon probably identical with that from oil of Neroli.

Essential Oil of Orange Peel—is largely made at Messina and also in the south of France. It is extracted by the sponge-, or by the écuelle-process, and partly from the Bigarade and partly from the Sweet or Portugal Orange, the scarcely ripe fruit being in either case employed. The oil made from the former is much more valuable than that obtained from the latter, and the two are distinguished in price-currents as Essence de Bigarade and Essence de Portugal.

These essences are but little consumed in England, in liqueur-making and in perfumery. For what is known of their chemical nature, the reader can consult the works named at foot[501].

Essence of Cedrat—The true Citron or Cedrat tree is Citrus medica Risso, and is of interest as being the only member of the Orange tribe the fruit of which was known in ancient Rome. The tree itself, which appears to have been cultivated in Palestine in the time of Josephus, was introduced into Italy in about the 3rd century. In a.d. 1003 it was much grown at Salerno near Naples, whence its fruits were sent as presents to the Norman princes[502].

At the present day, the citron appears to be nowhere cultivated extensively, the more prolific lemon tree having generally taken its place. It is however scattered along the Western Riviera, and is also grown on a small scale about Pizzo and Paola on the western coast of Calabria, in Sicily, Corsica, and Azores. Its fruits, which often weigh several pounds, are chiefly sold for being candied. For this purpose the peel, which is excessively thick, is salted and in that state shipped to England and Holland. The fruit has a very scanty pulp[503].

Essence of Cedrat which is quoted in some price-lists may be prepared from the scarcely ripe fruit by the sponge-process; but as it is more profitable to export the fruit salted, it is very rarely manufactured, and that which bears its name is for the most part fictitious.

FRUCTUS BELÆ.

Botanical Origin—Ægle Marmelos[504] Correa (Cratæva Marmelos L.), a tree found in most parts of the Indian peninsula, which is often planted in the neighbourhood of temples, being esteemed sacred by the Hindus. It is truly wild in the forests of the Coromandel Ghâts and of the Western Himalaya, ascending often to 4,000 feet and growing gregarious when wild.

It attains a height of 30-40 feet, is usually armed with strong sharp thorns and has trifid leaves, the central leaflet being petiolate and larger than the lateral. The fruit is a large berry, 2 to 4 inches in diameter, variable in shape, being spherical or somewhat flattened like an orange, ovoid, or pyriform[505], having a smooth hard shell; the interior divided into 10-15 cells each containing several woolly seeds, consists of a mucilaginous pulp, which becomes very hard in drying. In the fresh state the fruit is very aromatic, and the juicy pulp which it contains has an agreeable flavour, so that when mixed with water and sweetened, it forms a palatable refrigerant drink. The fruit is never eaten as dessert, though its pulp is sometimes made into a preserve with sugar.

The fruit of the wild tree is described as small, hard, and flavourless, remaining long on the tree. The bark of the stem and root, the flowers and the expressed juice of the leaves are used in medicine by the natives of India.

History—The tree under the name of Bilva[506] is constantly alluded to as an emblem of increase and fertility in ancient Sanskrit poems, some of which as the Yajar Veda are supposed to have been written not later than 1000 b.c.—Constantinus Africanus was acquainted with the fruit under notice.

Garcia de Orta, who resided in India as physician to the Portuguese viceroy at Goa in the 16th century, wrote an account of the fruit under the name of Marmelos de Benguala (Bengal Quince) Cirifole or Beli[507], describing its use in dysentery.

In the following century it was noticed by Bontius, in whose writings edited by Piso[508] there is a bad figure of the tree as Malum Cydonium. It was also figured by Rheede,[509] and subsequently under the designation of Bilack or Bilack tellor by Rumphius.[510] The latter states that it is indigenous to Gujarat, the eastern parts of Java, Sumbawa and Celebes, and that it has been introduced into Amboina.

But although Ægle Marmelos has thus been long known and appreciated in India, the use of its fruit as a medicine attracted no attention in Europe till about the year 1850. The dried fruit which has a place in the British Pharmacopœia is now not unfrequently imported.

Description—We have already described the form and structure of the fruit, which for medicinal use should be dried when in a half ripe state. It is found in commerce in dried slices having on the outer side a smooth greyish shell enclosing a hard, orange or red, gummy pulp in which are some of the 10 to 15 cells existing in the entire fruit. Each cell includes 6 to 10 compressed oblong seeds nearly 3 lines in length, covered with whitish woolly hairs. When broken the pulp is seen to be nearly colourless internally, the outside alone having assumed an orange tint. The dried pulp has a mucilaginous, slightly acid taste, without aroma, astringency, or sweetness.

There is also imported Bael fruit which has been collected when ripe, as shown by the well-formed seeds. Such fruits arrive broken irregularly and dried, or sawn into transverse slices and then dried, or lastly entire, in which case they retain some of their original fragrance resembling that of elemi.

Microscopic Structure—The rind of the fruit is covered with a strong cuticle, and further shows two layers, the one exhibiting not very numerous oil-cells, and the other an inner made up of sclerenchyme. The tissue of the pulp, which, treated with water, swells into an elastic mass, consists of large cells with considerable cavities between them. The seeds when moistened yield an abundance of mucilage nearly in the same way as White Mustard or Linseed. In the epidermis of the seeds certain groups of cells are excessively lengthened, and thus constitute the curious woolly hairs already noticed. They likewise afford mucilage in the same way as the seed itself.

Chemical Composition—We are unable to confirm the remarkable analyses of the drug alluded to in the Pharmacopœia of India;[511] nor can we explain by any chemical examination upon what constituent the alleged medicinal efficacy of bael depends.

The pulp moistened with cold water yields a red liquid containing chiefly mucilage, and (probably) pectin which separates if the liquid is concentrated by evaporation. The mucilage may be precipitated by neutral acetate of lead or by alcohol, but is not coloured by iodine. It may be separated by a filter into a portion truly soluble (as proved by the addition of alcohol or acetate of lead), and another, comprehending the larger bulk, which is only swollen like tragacanth, but is far more glutinous and completely transparent.

Neither a per-nor a proto-salt of iron shows the infusion to contain any appreciable quantity of tannin,[512] nor is the drug in any sense possessed of astringent properties.

Uses—Bael is held in high repute in India as a remedy for dysentery and diarrhœa; at the same time it is said to act as a laxative where constipation exists.

Adulteration—The fruit of Feronia Elephantum Correa, which has a considerable external resemblance to that of Ægle Marmelos and is called by Europeans Wood Apple, is sometimes supplied in India for bael. It may be easily distinguished: it is one-celled with a large five-lobed cavity (instead of 10 to 15 cells) filled with numerous seeds. The tree has pinnate leaves with 2 or 3 pairs of leaflets. We have seen Pomegranate Peel offered as Indian Bael.[513]

---

LIGNUM QUASSIÆ.

Botanical Origin—Picræna excelsa Lindl. (Quassia excelsa Swartz, Simaruba excelsa DC., Picrasma excelsa Planchon), a tree 50 to 60 feet in height, somewhat resembling an ash and having inconspicuous greenish flowers and black shining drupes the size of a pea. It is common on the plains and lower mountains of Jamaica, and is also found in the islands of Antigua and St. Vincent. It is called in the West Indies Bitter Wood or Bitter Ash.

History—Quassia wood was introduced into Europe about the middle of the last century. It was derived from Quassia amara L., a shrub or small tree with handsome crimson flowers, belonging to the same order, native of Panama, Venezuela, Guiana, and Northern Brazil. It was subsequently found that the Bitter Wood of Jamaica which Swartz and other botanists referred to the same genus, possessed similar properties, and as it was obtainable of much larger size, it has since the end of the last century been generally preferred. The wood of Q. amara, called Surinam Quassia, is however still used in France and Germany.[514]

The first to give a good account of Jamaica quassia was John Lindsay,[515] a medical practitioner of the island, who writing in 1791 described the tree as long known not only for its excellent timber, but also as a useful medicine in putrid fevers and fluxes. He adds that the bark is exported to England in considerable quantity—“for the purposes of the brewers of ale and porter.”

Quassia, defined as the wood, bark, and root of Q. amara L., was introduced into the London Pharmacopœia of 1788; in the edition of 1809, it was superseded by the wood of Picræna excelsa. In the stock-book of a London druggist (J. Gurney Bevan, of Plough Court, Lombard Street) we find it first noticed in 1781 (as rasuræ), when it was reckoned as having cost 4s. 2d. per lb.

Description—The quassia wood of commerce consists of pieces of the stem and larger branches, some feet in length, and often as thick as a man’s thigh. It is covered with bark externally of a dusky grey or blackish hue, white and fibrous within, which it is customary to strip off and reject. The wood, which is of a very light yellowish tint, is tough and strong, but splits easily. In transverse section it exhibits numerous fine close medullary rays, which intersect the rather obscure and irregular rings resembling those of annual growth of our indigenous woody stems. The centre is occupied by a cylinder of pith of minute size. In a longitudinal section, whether tangential or radial, the wood appears transversely striated by reason of the small vertical height of the medullary rays.

The wood often exhibits certain blackish markings due to the mycelium of a fungus; they have sometimes the aspect of delicate patterns, and at others appear as large dark patches.

Quassia has a strong, pure bitter taste, but is devoid of odour. It is always supplied to the retail druggist in the form of turnings or raspings, the former being obtained in the manufacture of the Bitter Cups, now often seen in the shops.

Microscopic Structure—The wood consists for the most part of elongated pointed cells (libriform), traversed by medullary rays, each of the latter being built up of about 15 vertical layers of cells. The single layers contain from one to three rows of cells. The ligneous rays thus enclosed by medullary parenchyme, are intersected by groups of tissue constituting the above-mentioned irregular rings. On a longitudinal section this parenchyme exhibits numerous crystals of oxalate of calcium, and sometimes deposits of yellow resin. The latter is more abundant in the large vessels of the wood. Oxalate and resin are the only solid matters perceptible in the tissues of this drug.

Chemical Composition—The bitter taste of quassia is due to Quassiin, which was first obtained, no doubt, from the wood of Quassia amara, by Winckler in 1835. It was analysed by Wiggers,[516] who assigned it the formula C₁₀H₁₂O₃, now regarded as doubtful. According to the latter, quassiin is an irresolvable, neutral substance, crystallizable from dilute alcohol or from chloroform. It requires for solution about 200 parts of water, but is not soluble in ether; it forms an insoluble compound with tannic acid. Quassia wood is said to yield about ⅒ per cent. of quassiin. A watery infusion of quassia, especially if a little caustic lime has been added to the drug, displays a slight fluorescence, due apparently to quassiin. Goldschmiedt and Weidel (1877) failed in obtaining quassiin. They isolated the yellow resin which we mentioned above, and stated that it yields protocatechuic acid when melted with potash. Quassia wood dried at 100° C. yielded us 7·8 per cent. of ash.

Commerce—The quantity of Bitter Wood shipped from Jamaica in 1871 was 56 tons.[517]

Uses—The drug is employed as a stomachic and tonic. It is poisonous to flies, and is not without narcotic properties in respect to the higher animals.

Substitutes—The wood of Quassia amara L., the Bitter Wood of Surinam, bears a close resemblance, both external and structural, to the drug just noticed; but its stems never exceed four inches in diameter and are commonly still thinner. Their thin, brittle bark is of a greyish yellow, and separates easily from the wood. The latter is somewhat denser than the quassia of Jamaica, from which it may be distinguished by its medullary rays being composed of a single or less frequently of a double row of cells, whereas in the wood of Picræna excelsa, they consist of two or three rows, less frequently of only one.

Surinam Quassia Wood is exported from the Dutch colony of Surinam. The quantity shipped thence during the nine months ending 30th Sept, 1872, was 264,675 lb.[518]

The bark of Samadera indica Gärtn., a tree of the same natural order, owes its bitterness to a principle[519] which agrees perhaps with quassiin. The aqueous infusion of the bark is abundantly precipitated by tannic acid, a compound of quassiin probably being formed. A similar treatment applied to quassia would possibly easier afford quassiin than the extraction of the wood by means of alcohol, as performed by Wiggers.

---

OLIBANUM.

Botanical Origin—Olibanum is obtained from the stem of several species of Boswellia, inhabiting the hot and arid regions of Eastern Africa, near Cape Gardafui and of the southern coast of Arabia. Notwithstanding the recent elaborate and valuable researches of Birdwood,[521] the olibanum trees are still but imperfectly known, as will be evident in the following enumeration:—

1. Boswellia Carterii Birdw.—This includes the three following forms, which may be varieties of a single species, or may belong to two or more species,—a point impossible to settle until more perfect materials shall have been obtained.

a. Boswellia No. 5, Oliver, Flora of Tropical Africa, I. (1868) 324, Mohr meddu or Mohr madow of the natives; meddu, according to Playfair and Hildebrandt, means black. The leaflets are crenate, undulate, and pubescent on both sides.

This tree is found in the Somali Country, growing a little inland in the valleys and on the lower part of the hills, never on the range close to the sea. It yields the olibanum called Lubân Bedowi or Lubân Sheheri (Playfair).

Hildebrandt describes the Mohr meddu as a tree 12 to 15 feet high, with a few branches, indigenous to the limestone range of Ahl or Serrut, in the northern part of the Somali Country, where it occurs in elevations of from 3000 to 5000 feet. To this tree belongs the figure 58 in Bentley and Trimen’s Medicinal Plants (Part 20, 1877).

b. Boswellia No. 6, Oliver, op. cit., Birdwood, Linn. Trans. xxvii., tab. 29.—Sent by Playfair among the specimens of the preceding, and with the same indications and native name. This form, the “Mohr meddu” of the Somalis, has obscurely serrulate or almost entire leaflets, velvety and paler below, glabrous above. The figure (which is not given in the reprint) is very much the same as that of the following.

c. Maghrayt d’sheehaz of the Maharas, Birdwood, l. c. tab. 30, reprinted in Cooke’s report, plate I; Carter, Journ. of Bombay Branch of R. Asiat. Soc. ii., tab. 23; B. sacra Flückiger, Lehrbuch der Pharmakognosie des Pflanzenreiches, 1867. 31.—Ras Fartak, S.E. coast of Arabia, growing in the detritus of limestone cliffs and close to the shore,[522] also near the village of Merbat (Carter, 1844-1846).

Birdwood’s figure refers to a specimen propagated in the Victoria Gardens, Bombay, from cuttings sent there from the Somali country by Playfair.

2. B. Bhau-Dajiana Birdw. l. c. tab. 31, or plate III. of the reprint.—Somali Country (Playfair); cultivated in Victoria Gardens, Bombay, where it flowered in 1868. The differences between this species and B. Carterii are not very obvious.

3. Boswellia No. 4, Oliver, op. cit.—Bunder Murayah, Somali Country (Playfair). Grows out of the rock, but sometimes in the detritus of limestone; never found on the hills close to the sea, but further inland and on the highest ground. Yields Lubân Bedowi and L. Sheheri; was received at Kew as Mohr add, a name applied by Birdwood also to B. Bhau-Dajiana.

From the informations due to Captains Miles[523] and Hunter and to Haggenmacher[524] it would appear that the Beyo or Beyu of the Somalis (Boido, Capt. Hunter) is agreeing with this tree.

4. Boswellia neglecta, S. Le M. Moore, in Journ. of Botany, xv.(1877) 67 and tab. 185. This tree has been collected by Hildebrandt in the limestone range, Ahl or Serrut, in the northern part of the Somali Country. It occurs in elevations of 1000 to 1800 metres, and attains a height of 5 to 6 metres. Its exudation, according to Hildebrandt, is collected in but small quantity and mixed with the other kinds of olibanum. Moore gives Murlo as the vernacular name of this tree, Hildebrandt calls it Mohr add.

In addition to the foregoing, from which the olibanum of commerce is collected, it may be convenient to mention also the following:—

1. Boswellia Frereana Birdw., a well-marked and very distinct species of the Somali Country, which the natives call Yegaar. It abounds in a highly fragrant resin collected and sold as Lubân Meyeti or Lubân Mati, which we regard to be the substance originally known as Elemi (see this article).

2. B. papyrifera Richard (Plösslea floribunda Endl.), the “Makar” of Sennaar and the mountainous region ascending to 4000 feet above the level of the sea on the Abyssinian rivers Takazze and Mareb. It appears not to grow in the outer parts of north-eastern Africa. Its resin is not collected, and stated by Richard[525] to be transparent; it consists no doubt merely of resin (and essential oil?) without gum.[526]

3. B. thurifera Colebr. (B. glabra et B. serrata Roxb.), the Salai tree of India, produces a soft odoriferous resin which is used in the country as incense but is not the olibanum of commerce. The tree is particularly abundant on the trap hills of the Dekhan and Satpura range. Berg, in “Offizinelle Gewächse,” xiv. c. gives a good figure of this species.

History—The use of olibanum goes back to a period of extreme antiquity, as proved by the numerous references[527] in the writings of the Bible to incense, of which it was an essential ingredient. It is moreover well known that many centuries before Christ, the drug was one of the most important objects of the traffic which the Phœnicians[528] and Egyptians carried on with Arabia.

Professor Dümichen[529] of Strassburg has discovered at the temple of Dayr el Báhri in Upper Egypt, paintings illustrating the traffic carried on between Egypt and a distant country called Punt or Pount as early as the 17th century b.c. In these paintings there are representations not only of bags of olibanum, but also of olibanum trees planted in tubs or boxes, being conveyed by ship from Arabia to Egypt. Inscriptions on the same building, deciphered by Professor D., describe with the utmost admiration the shipments of precious woods, heaps of incense, verdant incense trees,[530] ivory, gold, stimmi (sulphide of antimony), silver, apes, besides other productions not yet identified. The country Pount was first thought to be southern Arabia, but is now considered to comprehend the Somali coast, together with a portion of the opposite Arabian coast. Punt possibly refers to “Opone,” an old name for Hafoon, a place south of Cape Gardafui.

A detailed account of frankincense is given by Theophrastus[531] (b.c. 370-285) who relates that the commodity is produced in the country of the Sabæans, one of the most active trading nations of antiquity, occupying the southern shores of Arabia. It appears from Diodorus that the Sabæans sold their frankincense to the Arabs, through whose hands it passed to the Phœnicians who disseminated the use of it in the temples throughout their possessions, as well as among the nations with whom they traded. The route of the caravans from south-eastern Arabia to Gaza in Palestine, has recently (1866) been pointed out by Professor Sprenger. Plutarch relates that when Alexander the Great captured Gaza, 500 talents of olibanum and 100 talents of myrrh were taken, and sent thence to Macedonia.

The libanotophorous region of the old Sabæans is in fact the very country visited by Carter in 1844 and 1846, and lying as he states on the south coast of Arabia between long. 52° 47′ and 52° 23′ east.[532] It was also known to the ancients, at least to Strabo and Arrian, that the opposite African coast likewise produced olibanum,[533] as it is now doing almost exclusively; and the latter states that the drug is shipped partly to Egypt and partly to Barbaricon at the mouth of the Indus.

As exemplifying the great esteem in which frankincense was held by the ancients, the memorable gifts presented by the Magi to the infant Saviour will occur to every mind. A few other instances may be mentioned: Herodotus[534] relates that the Arabians paid to Darius, king of Persia, an annual tribute of 1000 talents of frankincense.

A remarkable Greek inscription, brought to light in modern times[535] on the ruins of the temple of Apollo at Miletus, records the gifts made to the shrine by Seleucus II., king of Syria (b.c. 246-227), and his brother Antiochus Hierax, king of Cilicia, which included in addition two vessels of gold and silver, ten talents of frankincense (λιβανωτοός) and one of myrrh.

The emperor Constantine made numerous offerings to the church under St. Silvester, bishop of Rome a.d. 314-335, of costly vessels and fragrant drugs and spices,[536] among which mention is made in several instances of Aromata and Aromata in incensum, terms under which olibanum is to be understood.[537]

With regard to the consumption of olibanum in other countries, it is an interesting fact that the Arabs in their intercourse with the Chinese, which is known to have existed as early as the 1Oth century, carried with them olibanum, myrrh, dragon’s blood, and liquid storax,[538] drugs which are still imported from the west into China. The first-named is called Ju-siang, i.e. milk perfume, a curious allusion to its Arabic name Lubân signifying milk. In the year 1872, Shanghai imported[539] of this drug no less than 1,360 peculs (181,333 lb.).

Collection—The fragrant gum-resin is distributed through the leaves and bark of the trees, and even exudes as a milky juice also from the flowers; its fragrance is stated to be already appreciable in a certain distance. Cruttenden,[540] who visited the Somali Country in 1843, thus describes the collecting of olibanum by the Mijjertheyn tribe, whose chief port is Bunder Murayah (lat. 11° 43′ N.)[541]:—

“During the hot season the men and boys are daily employed in collecting gums, which process is carried on as follows:—About the end of February or beginning of March, the Bedouins visit all the trees in succession and make a deep incision in each, peeling off a narrow strip of bark for about 5 inches below the wound. This is left for a month when a fresh incision is made in the same place, but deeper. A third month elapses and the operation is again repeated, after which the gum is supposed to have attained a proper degree of consistency. The mountain sides are immediately covered with parties of men and boys, who scrape off the large clear globules into a basket, whilst the inferior quality that has run down the tree is packed separately. The gum when first taken from the tree is very soft, but hardens quickly.... Every fortnight the mountains are visited in this manner, the trees producing larger quantities as the season advances, until the middle of September, when the first shower of rain puts a close to the gathering that year.”

The informations due to J. M. Hildebrandt, who visited the Somali in 1875, are in accordance with Cruttenden’s statements. The former says, that the latest crops are greatly injured by the rains, the drug being partly dissolved by the water.

Carter[542] describing the collection of the drug in southern Arabia, writes thus:—“The gum is procured by making longitudinal incisions through the bark in the months of May and December, when the cuticle glistens with intumescence from the distended state of the parts beneath; the operation is simple, and requires no skill on the part of the operator. On its first appearance the gum comes forth white as milk, and according to its degree of fluidity, finds its way to the ground, or concretes on the branch near the place from which it first issued, from whence it is collected by men and boys employed to look after the trees by the different families who possess the land in which they grow.” According to Captain Miles,[543] the drug is not collected by the people of the country, but by Somalis who cross in numbers from the opposite coast, paying the Arab tribes for the privilege. The Arabian Lubân, he says, is considered inferior to the African.

It would even appear that the collection of the drug has ceased in Arabia, and that the names of Lubân Maheri or Mascati or Sheehaz, referring to the coast of Arabia between Ras Fartak (52° 10′ E.) and Ras Morbas (54° 34′) are now applied to the olibanum brought there from the opposite African coast.[544] Hildebrandt informed one of us (letter dated 26th Dec., 1878) that he has ascertained at Aden, that all the frankincense imported in Aden comes from Africa.

Description—Olibanum as found in commerce varies rather considerably in quality and appearance. It may in general terms be described as a dry gum-resin, consisting of detached tears up to an inch in length, of globular, pear-shaped, clavate, or stalactitic form, mixed with more or less irregular lumps of the same size. Some of the longer tears are slightly agglutinated, but most are distinct. The predominant forms are rounded,—angular fragments being less frequent, though the tears are not seldom fissured. Small pieces of the translucent brown papery bark are often found adhering to the flat pieces. The “Lubân Fasous Bedow” as exported from the Mijjertheyn district, in the eastern part of the Somali Country, is in very fine large tears.

The colour of the drug is pale yellowish or brownish, but the finer qualities consist of tears which are nearly colourless or have a greenish hue. The smallest grains only are transparent, the rest are translucent and somewhat milky, and not transparent even after the removal of the white dust with which they are always covered. But if heated to about 94° C., they become almost transparent. When broken they exhibit a rather dull and waxy surface. Examined under the polarizing microscope no trace of crystallization is observable.

Olibanum softens in the mouth; its taste is terebinthinous and slightly bitter, but by no means disagreeable. Its odour is pleasantly aromatic, but is only fully developed when the gum-resin is exposed to an elevated temperature. At 100° C. the latter softens without actually fusing, and if the heat be further raised decomposition begins.

Chemical Composition—Cold water quickly changes olibanum into a soft whitish pulp, which when rubbed down in a mortar forms an emulsion. Immersed in spirit of wine, a tear of olibanum is not altered much in form, but it becomes of an almost pure opaque white. In the first case the water dissolves the gum, while in the second the alcohol removes the resin. We find that pure olibanum treated with spirit of wine leaves 27 to 35 of gum,[545] which forms a thick mucilage with three parts of water. Dissolved in 5 parts of water it yields a neutral solution, which is precipitated by perchloride of iron as well as by silicate of sodium, but not by neutral acetate of lead. It is consequently a gum of the same class as gum arabic, if not identical with it. Its solution contains the same amount of lime as gum arabic affords.

The resin of olibanum has been examined by Hlasiwetz (1867), according to whom it is a uniform substance having the composition C₂₀H₃₀O₃. We find that it is not soluble in alkalis, nor have we succeeded in converting it into a crystalline body by the action of dilute alcohol. It is not uniformly distributed throughout the tears; if they are broken after having been acted upon by dilute alcohol, it now and then happens that a clear stratification is perceptible, showing a concentric arrangement.

Olibanum contains an essential oil, of which Braconnot (1808) obtained 5 per cent., Stenhouse (1840) 4 per cent., and Kurbatow (1871-1874) 7 per cent. According to Stenhouse it has a sp. gr. of 0·866, a boiling point of 179·4° C., and an odour resembling that of turpentine but more agreeable. Kurbatow separated this oil into two portions, the one of which has the formula C₁₀H₁₆, boils at 158° C., and combines with HCl to form crystals; the other contains oxygen. The bitter principle of olibanum forms an amorphous brown mass.

The resin of olibanum submitted to destructive distillation affords no umbelliferone. Heated with strong nitric acid it develops no peculiar colour, but at length camphretic acid (see Camphor) is formed, which may be also obtained from many resins and essential oils if submitted to the same oxidizing agent.

Commerce—The olibanum of Arabia is shipped from several small places along the coast between Damkote and Al Kammar, but the quantity produced in this district is much below that furnished by the Somali Country in Eastern Africa. The latter is brought to Zeyla, Berbera, Bunder Murayah, and many smaller ports, whence it is shipped to Aden or direct to Bombay. The trade is chiefly in the hands of Banians, and the great emporium for the drug is Bombay. A certain portion is shipped through the straits of Bab-el-Mandeb to Jidda,—Von Kremer[546] says to the value of £12,000 annually. The quantity exported from Bombay in the year 1872-73 was 25,100 cwt., of which 17,446 cwt. were shipped to the United Kingdom, and 6,184 cwt. to China.[547]

Uses—As a medicine olibanum is nearly obsolete, at least in Britain. The great consumption of the drug is for the incense used in the Roman Catholic and Greek Churches.

MYRRHA.

Botanical Origin—Ehrenberg who visited Egypt, Nubia, Abyssinia, and Arabia in the years 1820-26, brought home with him specimens of the myrrh trees found at Ghizan (Gison or Dhizân), a town on the strip of coast-region called Tihâma, opposite the islands of Farsan Kebir and Farsan Seghir, and a little to the north of Lohaia, on the eastern side of the Red Sea, in latitude 16° 40′, and also on the neighbouring mountains of Djara (or Shahra) and Kara. Here the myrrh trees form the underwood of the forests of Acacia, Moringa, and Euphorbia. Nees von Esenbeck who examined these specimens, drew up from them a description of what he called Balsamodendron Myrrha, which he figured in 1828.[548]

After Ehrenberg’s herbarium had been incorporated in the Royal Herbarium of Berlin, Berg examined these specimens, and came to the conclusion that they consist of two species, namely that described and figured by Nees, and a second to which was attached (correctly we must hope) two memoranda bearing the following words:—“Ipsa Myrrhæ arbor ad Gison,—Martio,” and “Ex huic simillima arbore ad Gison ipse Myrrham effluentem legi.[549] Hæc specimina lecta sunt in montibus Djara et Kara Februario.” This plant Berg named B. Ehrenbergianum.[550] Oliver in his Flora of Tropical Africa (1868)[551] is disposed to consider Berg’s plant the same as B. Opobalsamun Kth., a tree or shrub yielding myrrh, found by Schweinfurth on the Bisharrin mountains in Abyssinia, not far from the coast between Suakin and Edineb. But Schweinfurth himself does not admit the identity of the two plants.[552] It is certain, however, that the myrrh of commerce is chiefly of African origin.

Captain F. M. Hunter, Assistant Resident of Aden, informed us[553] that the Arabian myrrh tree, the Didthin, is found not only in the southern provinces of Arabia, Yemen, and Hadramant, probably also in the southern part of Oman, but likewise on the range of hills which, on the African shore, runs parallel to the Somali coast. The Somalis who gather the myrrh in Arabia allege that the Arabian “Didthin” is identical with that of their own district. Its exudation is the true myrrh, “Mulmul” of the Somalis, the “Mur” of the Arabs, or “Heerabole”[554] of the Indians.

Another myrrh tree, according to Captain Hunter, is growing in Ogadain and the districts round Harrar, that is between the 7th and 10th parallels, N. lat., and 43° to 50° E. long. This is the “Habaghadi” of the Somalis, which is not found in Arabia, nor in the coast range of the Somali country, but only at a considerable distance from the sea-shore. Its exudation is the coarse myrrh, habaghadi of the Somalis and Arabs and “Baisabole” of the Indians.

Hildebrandt has collected the didthin, or didin as he writes, in the coast range alluded to, that is in the Ahl or Serrut Mountains, where the tree is growing on sunny slopes in elevations of 500 to 1,500 metres. He has ascertained that it is identical with Ehrenberg’s tree, Balsamodendron Myrrha Nees. It is a low tree of crippled appearance, attaining not more than 3 metres. This species must therefore be pointed out as the source of true myrrh of the European commerce.

History—(See also further on, Bissabol). Myrrh has been used from the earliest times together with olibanum as a constituent of incense,[555] perfumes, and unguents. It was an ingredient of the holy oil used in the Jewish ceremonial as laid down by Moses: and it was also one of the numerous components of the celebrated Kyphi of the Egyptians, a preparation used in fumigations, medicine, and the process of embalming, and of which there were several varieties.

In the previous article we have pointed out (p. 137) several early references to myrrh in connection with olibanum, in which it is observable that the myrrh (when weights are mentioned) is always in the smaller quantity. Of the use of the drug in mediæval Europe there are few notices, but they tend to show that the commodity was rare and precious. This myrrh is recommended in the Anglo-Saxon Leech-books[556] to be used with frankincense in the superstitious medical practice of the 11th century. In a manuscript of the Monastery of Rheinau, near Schaffhausen, Switzerland, we also find that, apparently in the 11th century, myrrh as well as olibanum were used in ordeals in the “judicium aquæ bullientis.”[557] The drug was also used by the Welsh “Physicians of Myddfai” in the 13th century. In the Wardrobe accounts of Edward I. there is an entry under date 6th January, 1299, for gold, frankincense, and myrrh, offered by the king in his chapel on that day, it being the Feast of Epiphany.[558] Myrrh again figures in the accounts of Geoffroi de Fleuri,[559] master of the wardrobe (argentier) to Philippe le Long, king of France, where record is made of the purchase of—“4 onces d’estorat calmite” (see Styrax) “et mierre (myrrh) ... encenz et laudanon,” (Ladanum, the resin of Cistus creticus L.)—for the funeral of John, posthumous son of Louis X., a.d. 1316.

Gold, silver, silk, precious stones, pearls, camphor, musk, myrrh, and spices are enumerated[560] as the presents which the Khan of Cathay sent to Pope Benedict XII. at Avignon about the year 1342. The myrrh destined for this circuitous route to Europe[561] was doubtless that of the Arabian traders, with whom the Chinese had constant intercourse during the middle ages. Myrrh in fact is still somewhat largely consumed in China.[562]

The name Myrrh is from the Hebrew and Arabic Mur, meaning bitter, whence also the Greek σμύρνα. The ancient Egyptian Bola or Bal, and the Sanskrit Vola are preserved in the Persian and Indian words Bol, Bola, and Heerabol, well-known names for myrrh.

Stacte (στακτὴ), a substance often mentioned by the ancients, is said by Pliny to be a spontaneous liquid exudation of the myrrh tree, more valuable than myrrh itself. The author of the Periplus of the Erythrean Sea represents it as exported from Muza in Arabia[563] together with myrrh. Theophrastus[564] a.d. 314-335.[565]

The myrrh of the ancients was not always obtained from Arabia. The author of the Periplus,[566] who wrote about a.d. 64, records it to have been an export of Abalites, Malao, and Mosyllon (the last named the modern Berbera), ancient ports of the African coast outside the straits of Bab-el-Mandeb; and he even mentions that it is conveyed by small vessels to the opposite shores of Arabia.

Secretion—Marchand[567] who examined and figured the sections of a branch of three years’ growth of B. Myrrha, represents the gum-resin as chiefly deposited in the cortical layers, with a little in the medulla.

Collection—By the Somal tribe myrrh is largely collected as it flows out, incisions, according to Hildebrandt, being never practised. From the information given by Ehrenberg to Nees von Esenbeck,[568] it appears that myrrh when it first exudes is of an oily and then of a buttery appearance, yellowish white, gradually assuming a golden tint and becoming reddish as it hardens. It exudes from the bark like cherry-tree gum, and becomes dark and of inferior value by age. Although Ehrenberg says that the myrrh he saw was of fine quality, he does not mention it being gathered by the natives.

With regard to the localities[569] in which the drug is collected, Cruttenden,[570] who visited the Somali coast in 1843, says that myrrh is brought from the Wadi Nogâl, south west of Cape Gardafui, and from Murreyhan, Ogadain and Agahora; and that some few trees are found on the mountains behind Bunder Murayah. Major Harris[571] saw the myrrh tree in the Adel desert and in the jungle of the Háwash, on the way from Tajura to Shoa.

Vaughan[572] states that the Somali Country and the neighbourhood of Hurrur (or Harar or Adari, 9° 20′ N., 42° 17′ E.) south west of Zeila are the chief producing districts. It is generally brought to the great fair of Berbera held in November, December, and January, where it is purchased by the Banians of India, and shipped for Bombay.

It appears that all these informations rather refer to the Bisabol or Habaghadi variety of myrrh; only the first notice, due to Hildebrandt, applies to true myrrh.

Myrrh trees abound on the hills about Shugra and Sureea in the territory of the Fadhli or Fudthli tribe, lying to the eastward of Aden; myrrh is collected from them by Somalis who cross from the opposite coast for the purpose and pay a tribute for the privilege to the Arabs, who appear to be scarcely acquainted with this drug.[573] But a sample of it, received by one of us from Vaughan in 1852, and others we have since seen in London (and easily, recognized), proved it to be somewhat different from typical myrrh, and it is probably afforded by another species than Balsamodendron Myrrha.

It would thus appear that there are three different trees affording myrrh, namely that just alluded to, secondly the “Habaghadi,” and thirdly that growing east of Aden.

Description—Myrrh consists of irregular roundish masses, varying in size from small grains up to pieces as large as an egg, and occasionally much larger. They are of an opaque reddish-brown with dusty dull surface. When broken, they exhibit a rough or waxy fracture, having a moist and unctuous appearance, especially when pressed, and a rich brown hue. The fractured, translucent surface often displays characteristic whitish marks which the ancients compared to the light mark at the base of the finger-nails. Myrrh has a peculiar and agreeable fragrance with an aromatic, bitter, and acrid taste. It cannot be finely powdered until deprived by drying of some of its essential oil and water; nor when heated does it melt like colophony.

Water disintegrates myrrh, forming a light brown emulsion, which viewed under the microscope appears made up of colourless drops, among which are granules of yellow resin. Alcohol dissolves the resin of myrrh, leaving angular non-crystalline particles of gum[574] and fragments of bark.

Chemical Composition—Myrrh is a mixture, in very varying proportions, of resin, mucilaginous matters, and essential oil. A fine specimen of myrrh from the Somali coast, with which Captain Hunter, in 1877, kindly presented one of us, yielded 27 per cent. of resin. The undissolved portion is partly soluble in water.

The resin dissolves completely in chloroform or alcohol, and the colour of the latter solution is but slightly darkened by perchloride of iron. It is but partially soluble in alkalis or in bisulphide of carbon. Brückner (1867) found this portion to yield 75·6 per cent. of carbon and 9·5 of hydrogen. The resin which the bisulphide refuses to dissolve, is freely soluble in ether. It contains only 57·4 per cent. of carbon. The resin of myrrh to which, when moistened with alcohol, a small quantity of concentrated nitric or hydrochloric acid is added, assumes a violet hue, but far less brilliant than that displayed by resin of galbanum when treated in a similar manner. But a most intensely violet liquid may be obtained by adding bromine to the resin dissolved in bisulphide of carbon. If the resin of myrrh as afforded by alcohol is warmed with petroleum (boiling at 70° C.), only a small amount of resin is dissolved. This liquid becomes turbid if vapours of bromine are added; a violet flocculent matter deposits, whereas the just above-mentioned solution in the bisulphide continues clear on addition of bromine.

The resin of myrrh is not capable of affording umbelliferone like that of galbanum. By melting it with potash, pyrocatechin and protocatechuic acid are produced in small amount.

Myrrh yields on distillation a volatile oil which in operating on 25 lb. of the drug, we obtained to the extent of ¾ per cent.[575] It is a yellowish, rather viscid liquid, neutral to litmus, having a powerful odour of myrrh and sp. gr. 0·988 at 13° C.[576] In a column 50 mm. long, it deviates a ray of light 30·1° to the left. By submitting it to distillation, we obtained before the oil boiled, a few drops of a strongly acid liquid having the smell of formic acid. Neutralized with ammonia, this liquid produced in solution of mercurous nitrate a whitish precipitate which speedily darkened, thus indicating formic acid, which is developed in the oil. Old myrrh is in fact said to yield an acid distillate. The oil begins to boil at about 266° C., and chiefly distills over between 270° and 290°.

On combustion in the usual way it afforded carbon 84·70, hydrogen 9·98. Having been again rectified in a current of dry carbonic acid, it had a boiling point of 262-263° C., and now afforded[577] carbon 84·70, hydrogen 10·26, which would nearly answer to the formula C₂₂H₃₂O. The results of Ruickholdt’s analysis (1845) of essential oil of myrrh assign it the formula C₁₀H₁₄O, which is widely different from that indicated by our experiments.

The oil which we rectified displays a faintly greenish hue; it is miscible in every proportion with bisulphide of carbon, the solution exhibiting at first no peculiar coloration when a drop of nitric or sulphuric acid is added. Yet the mixture to which nitric acid (1·20) has been added, assumes after an hour or two a fine violet hue which is very persistent, enduring even if the liquid is allowed to dry up in a large capsule. If to the crude oil dissolved in bisulphide of carbon bromine be added, a violet hue is produced; and if the solution is allowed to evaporate, and the residue diluted with spirit of wine, it assumes a fine blue which disappears on addition of an alkali. The oil is not much altered by boiling with alcoholic potash, nor does it combine with alkaline bisulphites.

The Bitter principle of myrrh is contained in the resin as extracted by alcohol. By exhausting the resin with warm water an acid brown solution is obtained, from which a dark, viscid, neutral mass separates if the liquid is concentrated; it is contaminated with a large amount of inorganic matter, from which it may be purified by means of ether. Yet the latter affords also but an amorphous, somewhat brittle brown substance, softening at 80°-90° C. This bitter principle reminds us of that mentioned in our article Elemi, page 151; it is but sparingly soluble in water; the yellowish solution is intensely bitter. The bitter principle of myrrh appears to be a glucoside. We have not succeeded in preparing it in a more satisfactory state.

Commerce—Myrrh is chiefly shipped by way of Berbera to Aden, and thence either to Europe or to Bombay. The exports of Aden in the fiscal year 1875 to 1876 were 1439 cwt.; one-half of which went to Bombay, one third to the United Kingdom.[578]

The bags or bales which contain the myrrh are opened in Bombay, and the drug is sorted. The better portion goes to Europe, the refuse to China, where it is probably used as an incense.[579]

Uses—Myrrh, though much used, does not appear to possess any very important medicinal powers, and is chiefly employed on account of its bitter, aromatic properties.

Other Varieties of Myrrh—Though the myrrh of commerce exhibits some diversity of appearance, the drug-brokers and druggists of London are not in the habit of applying any special designations to the different qualities. There are however two varieties which deserve notice.

1. Bissa Bol (Bhesabol, Bysabole), Habaghadi or Hebbakhade of the Somalis, formerly called East India Myrrh.[580]

This drug is of African origin, but of the plant which yields it nothing is known. Vaughan[581] who sent a sample from Aden to one of us in 1852, was told by the natives that the tree from which it is collected resembles that affording Heera Ból or true myrrh, but that it is nevertheless distinct. The drug is exported from the whole Somali coast to Mokha, Jidda, Aden, Makulla, the Persian Gulf, India and even China.[582] Bombay official returns show that the quantity imported thither in the year 1872-73, was 224 cwt, all shipped from Aden.

Some myrrh, no doubt that from the interior of north-eastern Africa, the Habaghadi or Baisabole, finds its way by the country of the Wagadain (Ugahden or Ogadain) to the small port of Brava (Barawa, Braoua), about 1° N. lat., and to Zanzibar.[583] This is, possibly, also the “Mirra fina” which is stated, about the year 1502, by Tomé Lopez to be collected (?) in the island of “Monzambiche.”[584]

According to Vaughan, Bissa Bôl is mixed with the food given to milch cows and buffaloes in order to increase the quantity and improve the quality of their milk, and that it is also used as size to impart a bright gloss to whitewashed walls.

Miles mentions[585] that myrrh, called there hodthai, is only used in the Somali country, by men to whiten their shields (by means of an emulsion made with the drug), by women to cleanse their hair. Probably hodthai and habaghadi is one and the same thing.

Bissa Bôl differs from myrrh in its stronger, almost acrid taste and in odour, which, when once familiar is easily recognizable; fine specimens of the former have the outward characters of myrrh and perhaps are often passed off for it. A good sample of “coarse” habaghadi myrrh as sent in 1877 by Captain Hunter from Aden proved to contain but very little resin. This resin is manifestly different from that of myrrh as already shown by its paler, more reddish colour. The resin of Bissa Bôl moreover is but very sparingly soluble in bisulphide of carbon; this solution is not altered by bromine, that of true myrrh, as above stated, assuming a most intense violet colour on addition of bromine. Nor is the resin of habaghadi soluble in petroleum ether. Of the gummy substance, which is by far the prevailing constituent of this drug, a small portion only is soluble in water. These extremely marked differences no doubt depend upon a widely discrepant composition of the resins of the two kinds of myrrh as well as upon a different proportion of gum and resin. The Bissa Bôl usually seen is an impure and foul substance, which is regarded by London druggists as well as by the Banian traders in India as a very inferior dark sort of myrrh.

2. Arabian Myrrh—The drug we have mentioned at p. 143 as collected to the eastward of Aden, is of interest as substantiating the statement of Theophrastus that both olibanum and myrrh grow in Southern Arabia.

The drug, which is not distinguished by any special name in English trade, is in irregular masses seldom exceeding 1½ inches long, and having a somewhat gummy-looking exterior. The larger lumps seem formed by the cohesion of small, rounded, translucent, externally shining tears or drops. The fracture is like that of common myrrh, but less unctuous and wants the whitish markings. The odour and taste are those of the ordinary drug. Pieces of a semi-transparent papery bark are attached to some of the lumps. We extracted the resin of a sample of this myrrh from the territory of the Fadhli, as sent to us by Captain Hunter. Its solution in bisulphide of carbon or petroleum ether was coloured by bromine as stated above, (p. 144) with regard to typical myrrh (Heerabol) from the Somali Country. The name applies to myrrh from the vicinity of Ras Morbat in the same region. But the resin of another kind of Arabian myrrh, for which we are likewise indebted to Captain Hunter, is not coloured when treated in the same way. This is the myrrh “Hodaidia Jebeli” from north and north-western Yenen.

ELEMI.

Resina Elemi; Elemi; F. Résine Elemi; G. Elemiharz.

Botanical Origin—The resin known in pharmacy as Elemi is derived from a tree growing in the Philippines, which Blanco,[586] a botanist of Manila, described in 1845 under the name of Icica Abilo, but which is completely unknown to the botanists of Europe. Blanco’s description is such that, if correct, the plant cannot be placed in either of the old genera Icica or Elaphrium, comprehended by Bentham and Hooker in that of Bursera, nor yet in the allied genus Canarium; in fact even the order to which it belongs is somewhat doubtful.[587]

The tree grows in the province of Batangas in the island of Luzon (south of Manila), where its name in the Tagala language is ábilo; the Spaniards call it Arbol a brea, i.e. pitch-tree, from the circumstance that its resin is used for the caulking of boats.

History—The explicit statements of Theophrastus in the 3rd century b.c. relative to olibanum have already been mentioned. The same writer narrates[588] that a little above Coptus on the Red Sea, no tree is found except the acacia (ἀκάνθη) of the desert ... but that on the sea there grow laurel (δάϕνη) and olive (ἐλαία), from the latter of which exudes a substance much valued to make a medicine for the staunching of blood.

This story appears again in Pliny[589] who says that in Arabia the olive tree exudes tears which are an ingredient of the medicine called by the Greeks Enhæmon, from its efficacy in healing wounds.

Dioscorides[590] briefly notices the Gum of the Ethiopian olive, which he likens to scammony; and the same substance is named by Scribonius Largus[591] who practised medicine at Rome during the 1st century.

The writers who have commented on Dioscorides have generally adopted the opinion that the exudation of the so-called olive tree of Arabia and Ethiopia was none other than the substance known to them as Elemi, though, as remarked by Mattioli,[592] the oriental drug thus called by no means well accords with the description left by that author.

As to that name, the earliest mention of it appears in the middle of the 15th century. Thus in a list of drugs sold at Frankfort about 1450, we find Gommi Elempnij.[593] Saladinus,[594] who lived about this period, enumerates Gumi Elemi among the drugs kept by the Italian apothecaries, but we have not met with the name in any other writer of the school of Salerno. The Arbolayre,[595] a herbal supposed to have been printed about 1485, gives some account of Gomme Elempni, stating that it is the gum of the lemon tree and not of fennel as some think,—that it resembles Male Incense,—and makes an excellent ointment for wounds.

The name Enhæmon[596] of Pliny, also written Enhæmi, is probably the original form of the word Animi, another designation for the same drug, though also applied as at the present day to a sort of copal. It is even possible that the word Elemi has the same origin.[597]

This primitive Elemi is in our opinion identical with a peculiar sort of olibanum known as Luban Meyeti, afforded by Boswellia Frereana Birdwood (p. 135). It has a remarkable resemblance both in external appearance and in odour to the substance in after-times imported from America, and which were likened to the elemi and animi of the Old World. The description of “gummi elemnia” given by Valerius Cordus,[598] the most careful observer of his period, could in our opinion well apply to Luban Meyeti. (See p. 153 further on.)

The first reference to Elemi as a production of America comes from the pen of Monardes[599] who has a chapter on Animi and Copal. He describes animi as of a more oily nature than copal, of a very agreeable odour, and in grains resembling olibanum but of larger size, and adds that it differs from the animi of the Old World in being less white and clear.

At a somewhat later period this resin and some similar substances began to be substituted for Elemi which had become scarce.[600] Pomet,[601] who as a dealer in drugs was a man of practical knowledge, laments that this American drug was being sold by some as Elemi, and by others as Animi or as Tacamaca. It was however introduced in great plenty, and at length took the place of the original elemi which became completely forgotten.

American Elemi was in turn discarded in favour of another sort imported from the Philippines. The first mention of this substance is to be found among the descriptions accompanied by drawings sent by Father Camellus to Petiver of London, of the shrubs and trees of Luzon,[602] in the year 1701. Camellus states that the tree, which from his drawing preserved in the British Museum appears to us to be a species of Canarium, is very tall and large, that it is called by the Spaniards Arbol de la brea, and that it yields an abundance of odorous resin which is commonly used for pitching boats. Living specimens of the tree together with samples of the resin were brought to Paris from Manila by the traveller Perrottet about the year 1820. For the last twenty years the resin has been common, and is now imported in large quantities[603] for use in the arts, so displacing all other kinds. It has been adopted as the Elemi of the British Pharmacopœia (1867), and is in fact the only variety of elemi now found in English commerce.

Description—Manila elemi is a soft, resinous substance, of granular consistence not unlike old honey, and when recent and quite pure is colourless; more often it is found contaminated with carbonaceous matter which renders it grey or blackish, and it is besides mixed with chips and similar impurities. By exposure to the air it becomes harder and acquires a yellow tint. It has a strong and pleasant odour suggestive of fennel and lemon, yet withal somewhat terebinthinous. When moistened with spirit of wine, it disintegrates, and examined under the microscope is seen to consist partly of acicular crystals. At the heat of boiling water the hardened drug softens, and at a somewhat higher temperature fuses into a clear resin.

Chemical Composition—Manila elemi is rich in essential oil. On submitting 28 lb. of it to distillation with water, we obtained 2 lb. 13 oz. (equivalent to 10 per cent.) of a fragrant, colourless, neutral oil, of sp. gr. 0·861 at 15° C. Observed in Wild’s polaristrobometer we found it to be strongly dextrogyre.[604] H. Sainte Claire Deville[605] on the other hand has examined an oil of elemi that was strongly levogyre. This discrepancy shows that there are among the oils of various kinds of elemi, differences similar to those existing in the oils of turpentine and copaiba. By the action of dry hydrochloric acid gas, Deville obtained from his oil of elemi a solid crystalline substance, C₁₀H₁₆ + 2 HCl. We failed to produce any such compound from the oil of Manila elemi. Our oil of elemi dissolves in bisulphide of carbon; when mixed with concentrated sulphuric acid, it becomes thick and assumes a deep orange colour.

By submitting the crude oil to fractional distillation, we separated it into six portions, of which the first five were dextrogyre in gradually diminishing degree, while the sixth displayed a weak deviation to the left.[606] The first portion having been dissolved in four times its weight of strong sulphuric acid, washed and again distilled, exhibit a deviation to the left.[607]

If the essential oil of elemi (8 parts) is shaken with alcohol, 0·816 sp. gr. (2 parts), nitric acid, 1·2 sp. gr. (1 part) and water (5 parts), the mixture, on exposure to air in a shallow capsule soon yields large crystals, which were found to agree crystallographically[608] perfectly with terpin, C₁₀H₂₀O₂ + OH₂ from oil of turpentine.

Maujean,[609] a French pharmacien, examined Manila elemi as long ago as 1821 and proved it to contain two resins, the one soluble in cold, the other only in hot spirit of wine. The former, which appears to constitute by far the prevailing part of all varieties of elemi, has not yet been satisfactorily examined. Bonastre[610] a little latter made a more complete analysis, showing that the less soluble resin which he obtained to the extent of 25 per cent. is easily crystallizable, and apparently identical with a substance obtainable in a similar manner from what he regarded as true elemi, which the Manila resin was not then held to be. Baup (1851) gave it the name of Amyrin. According to our experiments, it is readily isolated to the extent of 20 per cent. when Manila elemi is treated with cold spirit of wine, in which the crystals of amyrin are but slightly soluble. If the elemi is pure, the amyrin may be thus obtained (by washing with spirit and pressure between bibulous paper) in a cake of snowy whiteness, which may be further purified by crystallization from boiling alcohol. The fusing point of the crystals is 177° C.; their composition has been ascertained by Buri[611] to agree with the formula C₂₅H₄₂O, which may be written thus: (C₅H₈)₅ OH₂. Amyrin at 16° C. dissolves in 27·5 parts of alcohol 0·816 sp. gr., being readily soluble also in all the usual solvents for resins. The alcoholic solution is slightly dextrogyre. Amyrin is a neutral substance, and may be sublimed in small quantities by very carefully heating it.

By heating amyrin with zinc dust Ciamician[612] obtained chiefly toluol, methyl-ethyl-benzol and ethyl-naphtalin.

By allowing an alcoholic solution of the amorphous resin of Manila elemi[613] to evaporate, Baup obtained in very small quantity crystals of Bréine, a substance fusing at 187° C., which he considered to be distinct from amyrin. In our opinion it was impure amyrin; it is extremely difficult, or rather practically impossible to extract all the crystallizable resin from the amorphous. If the latter, perfectly transparent, is kept for several years, an elegant crystallization at last begins to make its appearance throughout the bulk of the resin.

Baup further extracted from Manila elemi a crystallizable substance soluble in water to which he gave the name of Bryoidin,[614] and in smaller quantity a second also soluble in water which he called Bréidine. From the experiments of Baup it appears that bryoidin is soluble in 360 parts of water at 10° C., and melts at 135° C.; whereas bréidine requires for solution 260 parts of water and fuses at a temperature not much over 100° C.

We have also obtained Bryoidin[615] by operating in the following manner: the watery liquid left in the still after the distillation of 28 lb. of Manila elemi was poured off from the mass of hard resin, and having been duly concentrated, it deposited together with a dark extractiform matter, colourless acicular crystals of bryoidin. The deposit in question having been drained and allowed to dry, the bryoidin may be separated by boiling water or by cold ether. We found the latter the more convenient; it readily takes up the bryoidin contaminated only with a little resin. The ethereal solution should be allowed to evaporate and the residual crystalline mass boiled in water, when the solution (which is colourless), poured off from the resin, will deposit upon cooling brilliant tufts of acicular crystals of bryoidin. The boiling in water requires to be several times repeated before the whole of the bryoidin can be removed; the latter sometimes crystallizes as a mossy arborescent growth. Bryoidin is a neutral substance, of bitter taste, scarcely soluble in cold water, but dissolving easily in boiling water, or in alcohol or ether. When a little is placed in a watch-glass, covered with a plate of glass, and then gently heated over a lamp, it sublimes in delicate needles. To obtain it perfectly pure, it is best to sublime it in a current of dry carbonic acid. Thus purified its fusing point is 133·5 C.; after fusion it concretes as a transparent, amorphous mass, which if immersed in glycerin and raised to the temperature of 135° C., suddenly crystallizes.

We have observed that if the filtered mother-liquor of bryoidin after complete cooling and standing for a day or two is warmed, it becomes turbid and that in a few minutes there separate from it long white flocks like bits of paper or wool, which do not disappear either by warming or by cooling the liquid; under the microscope they are seen to consist partly of thread-like, partly of acicular crystals. It is possible this substance is Baup’s Bréidine; we found it to fuse at 135° C., to be neutral, and to crystallize from weak alcohol exactly like bryoidin. Both it and bryoidin look very voluminous in water, but are extremely small in weight, and are present in the drug in but a very small amount. The composition of bryoidin agrees with the formula C₂₀H₃₈O₃, which might be written thus (C₅H₈)₄+3OH₂. But it contains no water of crystallization. In the vapour of dry hydrochloric gas, bryoidin assumes a fine red colour, turning violet, then blue, and lastly green. This behaviour is not at all displayed by amyrin.

The liquids from which bryoidin is obtained contain an amorphous brown substance of intensely bitter taste, at the same time somewhat aromatic. It is decomposed by dilute mineral acids, evolving a very peculiar strong odour.

Buri[616] isolated from Manila Elemi an extremely small amount of Elemic acid, C₃₅H₅₆O₄. It is in very brilliant crystals, much larger than those of the other constituents of elemi. Although we have before us some prisms of the acids several millimetres long, it has been found impossible to ascertain their crystallographic character, each of the prisms being formed of very intimately aggregated crystals. Elemic acid melts at 215° C.; its alcoholic solution decidedly reddens litmus. Elemate of potassium is a crystalline salt.

The relations of the substances hitherto isolated from elemi may perhaps be given thus:—

Essential oil,	C₅H₈.
Amyrin,	(C₅H₈)₅	+   OH₂
Amorphous resin (?)	(C₅H₈)₂	+   OH₂
Bryoidin,	(C₅H₈)₄	+ 3OH₂
Elemic acid,	(C₅H₈)₇	+   O₄

Uses—Elemi is scarcely used in British medicine except in the form of an ointment, sometimes prescribed as a stimulating application to old wounds.

Other sorts of Elemi—1. Mexican Elemi, Vera Cruz Elemi—This drug, which used to be imported into London about thirty years ago, but which has now disappeared from commerce, is the produce of a tree named by Royle Amyris elemifera growing at Oaxaca in Mexico.[617] It is a light yellow, or whitish, brittle resin occurring in semi-cylindrical scraped pieces, or in irregular fragments which are sometimes translucent but more often dull and opaque. It easily softens in the mouth so that it may be masticated, and has an agreeable terebinthinous odour. Treated with cold spirit of wine (·828), it breaks down into a white magma of acicular crystals (Amyrin?).

2. Brazilian Elemi—Was described as long ago as 1658 by the traveller Piso, as a substance completely resembling the elemi of the Old World and applicable to the same purposes. It is the produce of several trees described as species of Icica, as I. Icicariba DC.,[618] I. heterophylla DC., I. heptaphylla Aublet, I. guianensis Aubl., I. altissima Aubl.—In New Granada a similar exudation[619] is furnished by I. Caranna H.B.K.

A specimen in our possession from Pernambuco[620] is a translucent, greenish yellow, fragrant, terebinthinous resin, which by cold spirit of wine may be separated into two portions, the one soluble, the other a mass of colourless acicular crystals. The resin spontaneously exuded and collected from the trunks, is often opaque and white, grey, or yellowish, looking not unlike fragments of old mortar. The microscope shows it to be made up of minute acicular crystals.[621]

3. Mauritius Elemi—Fine specimens of this substance and of Colophonia Mauritiana DC. the tree affording it, were sent to one of us (H.) in 1855 by Mr. Emile Fleurot of Mauritius. The resin accords in its general characters with Manila elemi, like which it leaves after treatment with cold spirit of wine, an abundance of crystals resembling amyrin.

4. Luban Meyeti[622] or Luban Mati.—This substance, which we claim to be the Oriental or African Elemi of the older writers, and also one of the resins anciently designated Animi,[623] is the exudation of Boswellia Frereana Birdwood, a remarkable tree gregarious on the bare limestone hills near Bunder Murayah to the west of Cape Gardafui. The tree which is called Yegaar by the natives, is of small stature, and differs from the other species of Boswellia growing on the same coast in having glabrous, glaucous leaves with obtuse leaflets, crisped at the margin.[624] The bark is smooth, papery, and translucent, and easily stripped off in thin sheets which are used for writing on. Though growing wild, the trees are said by Capt. Miles[625] to be carefully watched and even sometimes propagated. The resin exudes after incision in great plenty, soon hardens, and is collected by the Somali tribes who dispose of it to traders for shipment to Jidda and ports of Yemen: occasionally a package reaches London among the shipments of olibanum. It is used in the East for chewing like mastich.

In modern times Luban Mati has been mentioned by Wellsted in his “Travels in Arabia” (1838).

Luban Meyeti occurs in the form of detached droppy tears and fragments, occasionally in stalactitic masses several ounces in weight. It breaks very easily with a brilliant conchoidal fracture, showing an internal substance of a pale amber yellow and perfectly transparent. Externally it is more or less coated with a thin opaque white crust, which seen under the microscope appears non-crystalline. Many of the tears have pieces of the thin, brown, papery bark adhering to them. The resin has an agreeable odour of lemon and turpentine, and a mild terebinthinous taste.

Treated with alcohol (·838) it is almost entirely dissolved; the very small undissolved portion is not crystalline. The former agrees with the formula C₂₀H₃₀O₂. 20 lb. of Luban Mati yielded us 10 ounces of a volatile oil (= 3·1 per cent.) having a fragrant odour suggestive of elemi and sp. gr. 0·856 at 17° C. The oil examined in a column 50 millim. long, deviates the ray 2°·5 to the left. By fractional distillation we found it to consist of dextrogyre hydrocarbon, C₁₀H₁₆, mixed with an oxygenated oil which we did not succeed in isolating; the latter is evidently lævogyre, and exists in proportion more than sufficient to overcome the weak dextrogyre power of the hydrocarbon.

There is no gum in this exudation; it is therefore essentially different from olibanum, the product of closely allied species of Boswellia.[626]

---

FRUCTUS RHAMNI.

Botanical Origin—Rhamnus cathartica L., a robust diœcious shrub with spreading branches, the smaller of which often terminate in a stout thorn. It is indigenous to Northern Africa, the greater part of Europe, and stretches eastward to the Caucasus and into Siberia. We have seen stems 50 years old, having a diameter of 8 inches, sent from the government of Cherson, Southern Russia. In England the buckthorn though generally distributed is abundant only in certain districts; in Scotland it occurs wild in but a single locality. Yet in Norway, Sweden, and Finland it grows much further north.

The fruit which ripens in the autumn is collected for use chiefly in the counties of Hertfordshire, Buckinghamshire, Oxfordshire, and also from Wiltshire. The collectors usually prefer to supply the juice as expressed by themselves.

History—The Buckthorn was well known to the Anglo-Saxons, and is mentioned as Hartsthorn or Waythorn in their medical writings and glossaries dating before the Norman conquest. The Welsh physicians of Myddfai (“Meddygon Myddvai”) in the 13th century prescribed the juice of the fruit of buckthorn boiled with honey as an aperient drink.

As Spina Cervina the shrub is referred to by Piero de’ Crescenzi of Bologna[643] about a.d. 1305.

The medicinal use of the berries was familiar to all the writers on botany and materia medica of the 16th century. Syrup of buckthorn first appeared in the London Pharmacopœia of 1650; it was aromatized by means of aniseed, cinnamon, mastich and nutmeg.

Description—The fruits, which are only used in the fresh state, are small, juicy, spherical drupes the size of a pea, black and shining, bearing on the summit the remnants of the style, and supported below by a slender stalk expanded into a disc-like receptacle. Before ripening the fruit is green and distinctly 4-lobed, afterwards smooth and plump. It contains 4 one-seeded nuts[644] meeting at right angles in the middle. The seed is erect with a broad furrow on the back: in transverse section the albumen and cotyledons are seen to be curved into a horseshoe form with the ends directed outwards.

The fresh juice is green, has an acid reaction and a sweetish, afterwards disagreeably bitter taste, and repulsive odour. It is coloured dingy green by ferric chloride, yellow by alkalis, red by acids. According to Umney[645] it should have a sp. gr. of 1·070 to 1·075, but is seldom sold pure. By keeping the juice gradually turns red.

Microscopic Structure—The epidermis consists of small tabular cells, followed by a row of large cubic cells and then by several layers of tangentially-extended cells rich in chlorophyll. This thick epicarp passes into the loose thin-walled and large-celled sarocarp. Besides chlorophyll it exhibits numerous cells each containing a kind of sac, which may be squeezed out of the cell. These sacs are violet, turning blue with alkalis. Similar, yet much more conspicuous bodies occur also in the pulp of the Locust Bean (Ceratonia Siliqua L.).

Chemical Composition—The berries of buckthorn and other species of Rhamnus contain interesting colouring matters, which have been the subject of much chemical research and controversy. Winckler in 1849 extracted from the juice Rhamnocathartin, a yellowish uncrystallizable bitter substance, soluble in water but not in ether. Alkalis colour it golden yellow; perchloride of iron, dark greenish brown.

In 1840 Fleury, a pharmacien of Pontoise, discovered in buckthorn juice a yellow substance forming cauliflower-like crystals to which he gave the name of Rhamnine. This body has been recently studied by Lefort,[646] who identified it with the Rhamnetine of Galletly (1858) and the Chrysorhamnine of Schützenberger and Bertèche (1865). Though obtainable from the berries of all kinds of Rhamnus used in dyeing (including the common buckthorn), it is got most easily and abundantly from Persian Berries. When pure, and crystallized from absolute alcohol, it is described as forming minute yellow translucent tables. It is scarcely soluble in cold water, though colouring it pale yellow; is soluble in hot alcohol, insoluble in ether or bisulphide of carbon. It is very soluble in caustic alkalis, forming uncrystallizable reddish-yellow solutions. From alkaline solutions it is precipitated by a mineral acid in the form of a glutinous magma resembling hydrated silica. Lefort assigns to it the formula C₁₂H₁₂O₅ + 2H₂O.

This chemist has likewise found in the berries of Rhamnus, though not with certainty in those of R. cathartica, a neutral substance isomeric with rhamnine, to which he has given the name of Rhamnegine. Unlike rhamnine it is very soluble in cold water, but in all other respects it agrees with that body in chemical and physical properties. The two substances have the same taste, almost the same tint, the same crystalline form, and lastly they give rise to the same reactions with chemical agents.

The conclusions of Lefort have been contested by Stein (1868) and by Schützenberger (1868), the latter of whom succeeded in decomposing rhamnegine and proving it a glucoside having the formula C₂₄H₃₂O₁₄. Its decomposition gives rise to a body named Rhamnetin, C₁₂H₁₀O₅, and a crystallizable sugar isomeric with mannite. Schützenberger admits that the berries contain an isomeric modification of rhamnegine; but in addition another colouring matter insoluble in water, which appears to be the Rhamnine of Lefort, but to which he assigns a different formula, namely, C₁₈H₂₂O₁₀. This is also a glucoside capable of being split into rhamnetin and a sugar. There are thus, according to Schützenberger, two forms of rhamnegine which may be distinguished as α and β, and there is the substance insoluble in water, named by Lefort Rhamnine.

The question of the purgative principles of buckthorn, it will be observed, has not been touched by all these researches.

Uses—From the juice of the berries is prepared a syrup having strongly purgative properties, much more used as a medicine for animals than for man. The pigment Sap Green is also made from the juice.

---

UVÆ PASSÆ.

Passulæ majores; Raisins; F. Raisins; G. Rosinen.

Botanical Origin—Vitis vinifera L., the Common Grape-vine. It appears to be indigenous to the Caucasian provinces of Russia, that is to say, to the country lying between the eastern end of the Black Sea and the south-western shores of the Caspian; extending thence southward into Armenia. Under innumerable varieties, it is cultivated in most of the warmer and drier countries of the temperate regions of both the northern and southern hemispheres. Humboldt defines the area of the profitable culture of the vine as a zone lying between 36° and 40° of north latitude.

History—The vine is among the oldest of cultivated plants, and is mentioned in the earliest Mosaic writings. Dried grapes as distinguished from fresh were used by the ancient Hebrews, and in the Vulgate are translated Uvæ passæ.[647] During the middle ages, raisins were an article of luxury imported into England from Spain.

Description—The ovary of Vitis vinifera is 2-celled with 2 ovules in each cell; it develops into a succulent, pedicellate berry of spherical or ovoid form, in which the cells are obliterated and some of the seeds generally abortive. As the fruit is not articulated with the rachis or the rachis with the branch, it does not drop at maturity but remains attached to the plant, on which, provided there is sufficient solar heat, it gradually withers and dries: such fruits are called Raisins of the sun. Various methods are adopted to facilitate the drying of the fruit, such as dipping the bunches in boiling water or in a lye of wood ashes, or twisting or partially severing the stalk,—the effect of each operation being to arrest or destroy the vitality of the tissues. The drying is performed by exposure to the sun, sometimes supplemented by artificial heat.

The raisins commonly found in the shops are the produce of Spain and Asia Minor, and are sold either in entire bunches or removed from the stalk. The former kind, known as Muscatel Raisins and imported from Malaga, are dried and packed with great care for use as a dessert fruit. The latter kind, which includes the Valencia Raisins of Spain, and the Eleme, Chesme and stoneless Sultana Raisins of Smyrna, are used for culinary purposes. For pharmacy, Valencia raisins are generally employed.

Microscopic Structure—The outer layer or skin of the berry is made up of small tabular cells loaded with a reddish granular matter, which on addition of an alcoholic solution of perchloride of iron assumes a dingy green hue. The interior parenchyme exhibits large, thin-walled, loose cells containing an abundance of crystals (bitartrate of potassium and sugar). There are also some fibro-vascular bundles traversing the tissue in no regular order.

Chemical Composition—The pulp abounds in grape sugar and cream of tartar, each of which in old raisins may be found crystallized in nodular masses; it also contains gum and malic acid. The seeds afford 15 to 18 per cent. of a bland fixed oil, which is occasionally extracted. Fitz[648] has shown that it consists of the glycerides of Erucic Acid, C₂₂H₄₂O₂, stearic acid, and palmitic acid, the first-named acid largely prevailing. The crystals of erucic acid melt at 34° C.; by means of fused potash they may be resolved into arachic acid, C₂₀H₄₀O₂, and acetic acid, C₂H₄O₂.

The seeds further contain 5 to 6 per cent. of tannic acid, which also exists in the skin of the fruit. The latter is likewise the seat of chlorophyll and other colouring matter.

Commerce—The consumption of raisins in Great Britain is very large and is increasing. The imports into the United Kingdom have been as follows:—

1870.	1871.	1872.	1876.
365,418	427,056	617,418	583,860 cwt.
val. £593,527.	val. £707,344.	val. £1,149,337.	val. £1,058,406.

Of the quantity mentioned for 1872 there were 400,570 cwt. shipped from Spain, 176,500 cwt. from Asiatic Turkey, and the remainder from other countries.[649] It is stated that Greece, in 1874, exported about 1⅓ millions of cwt., value £28,000,000; much of this was shipped to England.

Uses—Raisins are an ingredient of Compound Tincture of Cardamoms and of Tincture of Senna. They have no medicinal properties, and are only used for the sake of the saccharine matter they impart.[650]

---

MASTICHE.

Mastix, Resina Mastiche; Mastich; F. Mastic; G. Mastix.

Botanical Origin—Pistacia Lentiscus L., the lentisk, is a diœcious evergreen, mostly found as a shrub a few feet high; but when allowed to attain its full growth, it slowly acquires the dimensions of a small tree having a dense head of foliage. It is a native of the Mediterranean shores from Syria to Spain, and is found in Portugal, Morocco and the Canaries. In some parts of Italy it is largely cut for fuel.

Mastich is collected in the southern and south-western part of the island of Scio, which was long regarded as the only region in the world capable of affording it. Experiments made in 1856 by Orphanides[651] have proved that excellent mastich might be easily obtained in other islands of the Archipelago, and probably also in Continental Greece. The same botanist remarks that the trees yielding mastich in Scio are exclusively male.

History—Mastich has been known from a very remote period, and is mentioned by Theophrastus,[652] who lived in the 4th century before the Christian era. Both Dioscorides and Pliny notice it as a production of the island of Chio, the modern Scio.

Avicenna[653] described (about the year 1000) two sorts of mastich, the white or Roman (i.e. Mediterranean or Christian), and the dark or Nabathæan,—the latter probably one of the Eastern forms of the drug mentioned at p. 165.

Benjamin of Tudela,[654] who visited the island of Scio when travelling to the East about a.d. 1160-1173, also refers to it yielding mastich, which in fact has always been one of its most important productions, and from the earliest times intimately connected with its history.

Mastich was prescribed in the 13th century by the Welsh “Meddygon Myddvai” as an ingredient of ointments.

In the middle ages the mastich of Scio was held as a monopoly by the Greek emperors, one of whom, Michael Paleologus in 1261, permitted the Genoese to settle in the island. His successor Andronicus II. conceded in 1304 the administration of the island to Benedetto Zaccaria, a rich patrician of Genoa and the proprietor of the alum works of Fokia (the ancient Phocæa), north-west of Smyrna, for ten years, renouncing all tribute during that period. The concession was very lucrative, a large revenue being derived from the Contrata del Mastico or Mastich district: and the Zaccaria family, taking advantage of the weakness of the emperor, determined to hold it as long as possible. In fact they made themselves the real sovereigns of Scio and of some of the adjacent islands, and retained their position until expelled by Andronicus III. in 1329.[655]

The island was retaken by the Genoese under Simone Vignosi in 1346; and then by a remarkable series of events became the property of an association called the Maona (the Arabic word for subsidy or reinforcement). Many of the noblest families of Genoa enrolled themselves in this corporation and settled in the island of Scio; and in order to express the community of interest that governed their proceedings, some of them relinquished their family names and assumed the general name of Giustiniani.[656] This extraordinary society played a part exactly comparable to that of the late East India Company. In Genoa it had its “Officium Chii”; it had its own constitution and mint, and it engaged in wars with the emperors of Constantinople, the Venetians and the Turks, who in turn attacked and ravaged the mastich island and adjacent possessions.

The Giustinianis regulated very strictly the culture of the lentisk and the gathering and export of its produce, and cruelly punished all offenders. The annual export of the drug was 300 to 400 quintals,[657] which were immediately assigned to the four regions with which the Maona chiefly traded. These were Romania (i.e. Greece, Constantinople and the Crimea), Occidente (Italy, France, Spain and Germany), Vera Turchia (Asia Minor), and Oriente (Syria, Egypt, and Northern Africa). In 1364, a quintal was sold for 40 lire; in 1417, the price was fixed at 25 lire. In the 16th century, the whole income from the drug was 30,000 ducats (£13,750),[658] a large sum for that period.

In 1566, the Giustinianis definitively lost their beautiful island, the Turks under Piali Pasha taking it by force of arms under pretext that the customary tribute was not duly paid.[659] A few years before that event, it was visited by the French naturalist Belon[660] who testifies from personal observation to the great care with which the lentisk was cultivated by the inhabitants.

When Tournefort[661] was at Scio in 1701, all the lentisk trees on the island were held to be the property of the Grand Signor, and if any land was sold, the sale did not include the lentisks that might be growing on it. At that time the mastich villages, about twenty in number, were required to pay 286 chests of mastich annually to the Turkish officers appointed to receive the revenue.

In the beginning of the present century, when Olivier[662] paid a visit to the island of Chios, he found 50,000 ocche (one occa = 2·82 lb. avdp. = 1·28 kilogrammes) or somewhat more to be the annual harvest of mastich.

The month of January, 1850, was memorable throughout Greece and the Archipelago for a frost of unparalleled severity which proved very destructive to the mastich trees of Scio, and occasioned a scarcity of the drug that lasted for many years.[663]

The foregoing statements show that for centuries past Scio or Chios was famed for this resin; there are however a few evidences proving that at least a little mastich used also to be collected in other islands. Amari[664] quoted an Arabic geographer of the 12th century speaking of “il mastice di Pantellaria cavato da’ lentischi e lo storace odorifero.” Pantellaria, Kossura of the ancients, is the small volcanic island south-west of Sicily, not far from Tunis. In a list enumerating the drugs to be met with in 1582 in the fair of Frankfurt[665] we find even mastich of Cyprus quoted as superior to the common. Cyprian mastich again occurs in the pharmaceutical tariffs of 1612 and 1669 of the same city, and in many others of that time.[666]

The disuse into which mastich has fallen makes it difficult to understand its ancient importance; but a glance at the pharmacopœias of the 15th, 16th, and 17th centuries shows that it was an ingredient of a large number of compound medicines.[667]

Secretion—In the bark of the stems and branches of the mastich shrub, there are resin-ducts like those in the aromatic roots of Umbelliferæ or Compositæ. In Pistacia they may even be shown in the petioles. The wood is devoid of resin,[668] so that slight incisions are sufficient to provoke the resinous exudation, the bark being not very thick, and liable to scale off.

Collection—In Scio incisions are made about the middle of June in the bark of the stems and principal branches. From these incisions which are vertical and very close together, the resin speedily flows, and soon hardens and dries. After 15 to 20 days it is collected with much care in little baskets lined with white paper or clean cotton wool. The ground below the trees is kept hard and clean, and flat pieces of stone are often laid on it that the droppings of resin may be saved uninjured by dirt. There is also some spontaneous exudation from the small branches which is of very fine quality. The operations are carried on by women and children and last for a couple of months. A fine tree may yield as much as 8 to 10 pounds of mastich.

The dealers in Scio distinguish three or four qualities of the drug, of which the two finer are called κυλιστὸ and ϕλισκάρι, that collected from the ground πῆττα, and the worst of all ϕλοῦδα.[669]

Description—The best sort of mastich consists of roundish tears about the size of small peas, together with pieces of an oblong or pear-shaped form. They are of a pale yellow or slightly greenish tint darkening by age, dusty and slightly opaque on the surface but perfectly transparent within. The mastich of late imported has been washed; the tears are no longer dusty, but have a glassy transparent appearance. Mastich is brittle, has a conchoidal fracture, a slight terebinthinous balsamic odour. It speedily softens in the mouth, and may be easily masticated and kneaded between the teeth, in this respect differing from sandarac, a tear of which breaks to powder when bitten.

Inferior mastich is less transparent, and consists of masses of larger size and less regular shape, often contaminated with earthy and vegetable impurities.

The sp. gr. of selected tears of mastich is about 1·06. They soften at 99° C. but do not melt below 108°.

Mastich dissolves in half its weight of pure warm acetone and then deviates the ray of polarized light to the right. On cooling, the solution becomes turbid. It dissolves slowly in 5 parts of oil of cloves, forming even in the cold a clear solution; it is but little soluble in glacial acetic acid or in benzol.

Chemical Composition—Mastich is soluble to the extent of about 90 per cent in cold alcohol; the residue, which has been termed Masticin or Beta-resin of Mastich, is a translucent, colourless, tough substance, insoluble in boiling alcohol or in solution of caustic alkali, but dissolving in ether or oil of turpentine. According to Johnston, it is somewhat less rich in oxygen than the following.

The soluble portion of mastich, called Alpha-resin of Mastich, possesses acid properties, and like many other resins has the formula C₂₀H₃₂O₃. Hartsen[670] asserts that it can be obtained in crystals. Its alcoholic solution is precipitated by an alcoholic solution of neutral acetate of lead. Mastich contains a very little volatile oil.

Commerce—Mastich still forms the principal revenue of Scio, from which island the export in 1871 was 28,000 lb. of picked, and 42,000 lb. of common. The market price of picked mastich was equal to 6s. 10d. per lb.—that of common 2s. 10d. The superior quality is sent to Turkey, especially Constantinople, also to Trieste, Vienna, and Marseilles, and a small quantity to England. The common sort is employed in the East in the manufacture of raki and other cordials.[671]

Uses—Mastich is not now regarded as possessing any important therapeutic virtues, and as a medicine is becoming obsolete. Even in varnish making it is no longer employed as formerly, its place being well supplied by less costly resins, such for example as dammar.

Varieties—There is found in the Indian bazaars a kind of mastich which though called Mustagi-rúmí (Roman mastich), is not imported from Europe but from Kabul, and is the produce of Pistacia Khinjuk Stocks, and the so-called P. cabulica St. trees growing all over Sind, Belúchistan and Kabul.[672] This drug, of which the better qualities closely approximate to the mastich of Scio, sometimes appears in the European market under the name of East Indian or Bombay Mastich. We find that when dissolved in half its weight of acetone or benzol, it deviates the ray of light to the right.

The solid resin of the Algerian form of P. Terebinthus L., known as P. atlantica Desf., is collected and used as mastich by the Arab tribes of Northern Africa.[673]

TEREBINTHINA CHIA

Botanical Origin—Pistacia Terebinthus L. (P. atlantica Desf., P. palæstina Boiss., P. cabulica Stocks), a tree 20 to 40 feet or more in height, in some countries only a shrub, common on the islands and shores of the Mediterranean as well as throughout Asia Minor, extending, as P. palæstina, to Syria and Palestine; and eastward, as P. cabulica, to Belúchistan and Afghanistan. It is found under the form called P. atlantica in Northern Africa, where it grows to a large size, and in the Canary Islands.

These several forms are mostly regarded as so many distinct species; but after due consideration and the examination of a large number of specimens both dried and living, we have arrived at the conclusion that they may fairly be united under a single specific name. The extreme varieties certainly present great differences of habit, as anyone would observe who had compared Pistacia Terebinthus as the straggling bush which it is in Languedoc and Provence, with the noble umbrageous tree it forms in the neighbourhood of Smyrna. But the different types are united by so many connecting links, that we have felt warranted in dissenting from the opinion usually held respecting them.

On the branches of Pistacia Terebinthus, a kind of galls is produced, which we shall briefly notice in our article Gallæe halepenses.

History—The terebinth was well known to the ancients; it is the τέρμινθος of Theophrastus, τερέβινθος of other authors, and the Alah of the Old Testament.[674] Among its products, the kernels were regarded by Dioscorides as unwholesome, though agreeable in taste. By pressing them, the original Oil of Turpentine, τερεβίνθινον ἔλαιον, a mixture of essential and fat oil was obtained, as it is in the East to the present day. The resinous juice of the stem and branches, the true, primitive turpentine, ῤητίνη τερμινθίνη, was celebrated as the finest of all analogous products, and preferred both to mastich and the pinic resins. To the latter however the name of turpentine was finally applied.[675]

Collection—The resinous juice is secreted in the bark, according to Unger,[676] and Marchand,[677] in special cells precisely as mastich in P. Lentiscus. That found in commerce is collected in the island of Scio. To some extent it exudes spontaneously, yet in greater abundance after incisions made in the stems and branches. This is done in spring, and the resin continues to flow during the whole summer; but the quantity is so small that not more that 10 or 11 ounces are obtained from a large tree in the course of a year. The turpentine, hardened by the coolness of the night, is scraped from the stem down which it has flowed, or from flat stones placed at the foot of the tree to receive it. As it is, when thus collected, always mixed with foreign substances, it is purified to some extent by straining through small baskets, after having been liquefied by exposure to the sun.

When Tournefort[678] visited Scio in 1701, the island was said to produce scarcely 300 okes or ocche (one occa = 2·82 lb. avdp.); a century later Olivier[679] stated, that the turpentine was becoming very scarce, 200 ocche only, or even less, being the annual yield. It was then carefully collected by means of little earthen vessels tied to the incised stems. The trade is asserted to be now almost exclusively in the hands of the Jews, who dispose of the drug in the interior part of the Turkish Empire.[680]

Description—A specimen collected by Maltass near Smyrna in 1858 was, after ten years, of a light yellowish colour, scarcely fluid though perfectly transparent, nearly of the odour of melted colophony or mastich, and without much taste. We found it readily soluble in spirit of wine, amylic alcohol, glacial acetic acid, benzol, or acetone, the solution in each case being very slightly fluorescent. The alcoholic solution reddens litmus, and is neither bitter nor acrid. Two parts of this genuine turpentine dissolved in one of acetone deviate a ray of polarized light 7° to the right[681] in a column 50 mm. long.

Chian turpentine as found in commerce and believed to be genuine, is a soft solid, becoming brittle, by exposure to the air; viewed in mass it appears opaque and of a dull brown hue. If pressed while warm between two slips of glass, it is seen to be transparent, of a yellowish-brown, and much contaminated by various impurities in a state of fine division. It has an agreeable, mild terebinthinous odour and very little taste. The whitish powder with which old Chian turpentine becomes covered, shows no trace of crystalline structure when examined under the microscope.

Chemical Composition—Chian turpentine consists of resin and essential oil. The former is probably identical with the Alpha-resin of mastich. The Beta-resin or Masticin appears to be absent, for we find that Chian turpentine deprived of its essential oil by a gentle heat, dissolves entirely (impurities excepted) in alcohol sp. gr. 0·815, which is by no means the case with mastich.

The essential oil which we obtained by distilling with water 64 ounces of Chian turpentine of authentic origin, amounted to nearly 14½ per cent. It has the odour of the drug; sp. gr. 0·869; boiling point 161° C.; it deviates the ray of polarized light 12·1° to the right. In common with turpentine oils of the Coniferæ, it contains a small amount of an oxygenated oil, and is therefore vividly attacked by sodium. When this reaction is over and the oil is again distilled, it boils at 157° C. and has a sp. gr. of 0·862. It has now a more agreeable odour, resembling a mixture of cajuput, mace, and camphor, and nearly the same rotatory power (11·5° to the right). By saturation with dry hydrochloric acid, it yields a solid compound after some weeks. After treatment with sodium and rectification, the oil was found[682] to consist of C 88·75, H 11·40 per cent., which is the composition of oil of turpentine.

Uses—Chian Turpentine appears to have exactly the properties of the pinic turpentines; in British medicine it is almost obsolete. In Greece it is sometimes added to wine or used to flavour cordials, in the same manner as turpentine of the pine, or mastich.

GALLÆ CHINENSES SEU JAPONICÆ.

Botanical Origin—The plant which bears this important kind of gall, is Rhus semialata Murray (Rh. Bucki-amela Roxb.), a tree attaining 30 to 40 feet, common in Northern India, China and Japan, ascending in the outer Himalaya and the Kasia hills to elevations of 2,500 to 6,000 feet.[683]

History—In China these galls are probably known and used both medicinally and in dyeing since very long; they are mentioned in the herbal Puntsaou, written in the middle of the 16th century. They also occur in Cleyer’s “Specimen medicinæ sinicæ,” Frankfort, 1682, No. 225, under the name u poi çu.[684] Kämpfer[685] also mentions a tree “Baibokf, vulgo Fusi,” growing on the hills, the pinnate leaves of which he found often provided with an excrescence: “Ἐπίϕνσι foliorum informi, tuberosa, multiplici, tenui, dura, cava, Gallæ nostratis usu praestante.” No doubt this refers to the galls under notice; they began to be imported into Europe about 1724, and are noticed by Geoffroy[686] as Oreilles des Indes, but they seem to have soon disappeared from the market. Pereira directed attention to them in 1844, since which time they have formed a regular and abundant article of import both from China and Japan.

Formation—Chinese galls are vesicular protuberances formed on the leafstalks and branches of the above-mentioned tree, by the puncture of an insect, identified and figured by Doubleday[687] as a species of Aphis, and subsequently named provisionally by Jacob Bell[688] A. chinensis. We have no account by any competent observer of their growth; and as to their development, we can only imagine it from the analogous productions seen in Europe. According to Doubleday, it is probable that the female aphis punctures the upper surface of a leaf (more probably leafstalk), the result of the wound being the growth of a hollow expansion in the vegetable tissue. Of this cavity the creature takes possession and brings forth a progeny which lives by puncturing the inner surface of their home, thus much increasing the tendency to a morbid expansion of the soft growing tissue in an outward direction. Meanwhile the neck of the sac-like gall thickens, the aperture contracts and finally closes, imprisoning all the inmates. Here they live and multiply until, as in the case of the pistacia gall of Europe, the sac ruptures and allows of their escape. This, we may imagine, takes place at the period when, after some generations all wingless and perhaps all female (for the female aphis produces for several generations without impregnation), a winged generation is brought forth of both sexes. These may then fly to other spots, and deposit eggs for a further propagation of their race.

The galls are collected when their green colour is changing into yellow; they are then scalded.[689]

Description—The galls are light and hollow, varying in length from 1 to 2½ inches, and of extremely diverse and irregular form. The simplest are somewhat egg-shaped, the smaller end being attached to the leafstalk; but the form is rarely so regular, and more often the body of the gall is distorted by numerous knobby or horn-like protuberances or branches; or the gall consists of several lobes uniting in their lower part and gradually attenuated to the point by which the excrescence is attached to the leaf.[690] But though the form is thus variable, the structure of these bodi4s is very characteristic. They are striated towards the base, and completely covered on other parts with a thick, velvety, grey down, which rubbed off on the prominences, displays the reddish-brown colour of the shell itself. The latter is ⅒ to ¹/₂₀ of an inch in thickness, translucent and horny, but brittle with a smooth and shining fracture. It is rather smoother on the inner surface and of lighter colour than on the outer.

The galls when broken are generally found to contain a white, downy-looking substance, together with the minute, dried-up bodies of the killed insect.[691]

The drug as imported from Japan is usually a little smaller and paler; it mostly fetches a better price in the market.

Microscopic Structure—The tissue of the galls is made up of thin-walled, large cells irregularly traversed by small vascular bundles and laticiferous vessels. The latter are mostly not branched. The parenchyme is loaded with lumps of tannic matter and starch, the latter having mostly lost by the treatment with boiling water its granular appearance. The epidermis of the galls is covered with little tapering hairs, consisting each of 1-5 cells, to which is due the velvety down of the drug.

Chemical Composition—Chinese or Japanese galls contain about 70 per cent. of a tannic acid, which has been first shown by Stein in 1849 to be identical with that derived from oak galls (see Gallæ halepenses), the so-called gallo-tannic or common tannic acid.[692] It is remarkable that this substance, which is by no means widely distributed, is also present in Rhus coriaria, a species indigenous in the Mediterranean region. Its leaves and shoots are the well-known dyeing and tanning material Sumach.

Stein, however, pointed out at the same time, that in Chinese galls gallo-tannic acid is accompanied by a small amount, about 4 per cent., of a different tannic matter.

Commerce—At present the supplies arrive chiefly from Hankow, from which great trading city the export, in 1872, was no less than 30,949 peculs, equal to 36,844 cwt; 21,611 peculs, value 136,214 taels (one tael about 6s.) in 1874. In 1877 all China exported not more than 17,515 peculs. A little is also shipped from Canton and Ningpo.[693] The quantity imported from China into the United Kingdom in 1872 was 8621 cwts., valued at £20,098. In the China trade returns, the drug is always miscalled “Nut galls,” or “gallnuts.” Only those called “Wu-pei-tze” are the galls under examination. There are also oak galls exported from China resembling those from Western Asia. Japanese galls, “Kifushi,” are shipped in increasing quantities at Hiogo.[694]

Uses—The galls under notice are employed, chiefly in Germany, for the manufacture of tannic acid, gallic acid, and pyrogallol.

---
